Here you will find all available parts and drawings of the 'Festool 487101 (OF900)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Festool 487101 (OF900)
Spare parts list of model Festool 487101 (OF900)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| ARMATURE 230V OF 1010 Q 230V ET-BG | ||||
| 1 | 492039 | 147.02 | 177.89 | |
| No information available, not orderable | ||||
| 2 | 492042 | |||
| Switch attachme ET 2 E | ||||
| 3 | 486317 | 15.00 | 18.15 | |
| CABLE WITH PLUG AP 85 E DIN-H05RN-F | ||||
| 4 | 457600 | 24.32 | 29.43 | |
| Cable conduit RTR 1409 | ||||
| 5 | 432436 | 1.51 | 1.83 | |
| Oval head screw PT-3,5x10-KT15 | ||||
| 6 | 219031 | 7.32 | 8.86 | |
| No longer available, no replacement | ||||
| 7 | 451430 | |||
| No information available, not orderable | ||||
| 8 | 487836 | |||
| Oval head screw PT-4,0x50-KT15 | ||||
| 9 | 228707 | 1.51 | 1.83 | |
| SPACER 15,8x21,8x0,2 L+MN 1100 | ||||
| 10 | 228759 | 1.51 | 1.83 | |
| WASHER 14x21,8x0,3 L+MN 1100 | ||||
| 10 | 203777 | 1.51 | 1.83 | |
| Groove Ball Bearing 608 D1 MC3 E U152 J2 HA1 | ||||
| 11 | 10775821 | 5.54 | 6.70 | |
| Air guide washe RTM-EA | ||||
| 12 | 434430 | 2.30 | 2.78 | |
| FAN OF 900 | ||||
| 13 | 444979 | 3.53 | 4.27 | |
| Circlip DIN 471-17x1 | ||||
| 14 | 401191 | 1.51 | 1.83 | |
| No longer available, no replacement | ||||
| 15 | 488771 | |||
| Bush 16x18x10 GGB 1610 DP4 | ||||
| 16 | 400994 | 1.51 | 1.83 | |
| SPRING DIN 2098-1,60x17,20x16,5 | ||||
| 17 | 440729 | 1.51 | 1.83 | |
| KNOB (REAR HALF KF 4 E M8x12 | ||||
| 18 | 436192 | 11.09 | 13.42 | |
| KNOB (FRONT HAL KF 4 E | ||||
| 19 | 436189 | 5.18 | 6.27 | |
| Pressure ring KF 4 E | ||||
| 20 | 436301 | 2.66 | 3.22 | |
| Bush 12x14x12 GGB 1212 DP4 | ||||
| 21 | 210031 | 1.51 | 1.83 | |
| Dowel pin DIN 1481-2x12-ST | ||||
| 22 | 200747 | 1.51 | 1.83 | |
| CAP OF 1000 EB | ||||
| 23 | 450206 | 1.51 | 1.83 | |
| Bolt KF 4 E | ||||
| 24 | 436305 | 10.01 | 12.11 | |
| Compr. spring DIN 2098-0,70x7,50x14,7 | ||||
| 25 | 444754 | 1.51 | 1.83 | |
| Cover OFK 700 EQ | ||||
| 26 | 473550 | 7.70 | 9.32 | |
| Cover OFK 700 EQ | ||||
| 27 | 494788 | 13.67 | 16.54 | |
| Oval head screw M4x20-TAPTITE-T15 | ||||
| 28 | 228569 | 1.51 | 1.83 | |
| Oval head screw PT-3,5x10-KT15 | ||||
| 29 | 219031 | 7.32 | 8.86 | |
| BRUSH HOLDER OF 1000 EB | ||||
| 30 | 488579 | 11.52 | 13.94 | |
| Cable clamp RS 3 | ||||
| 31 | 439288 | 1.51 | 1.83 | |
| Oval head screw PT-3,5x16-KT15 | ||||
| 32 | 228663 | 1.51 | 1.83 | |
| CAPACITOR AXT 50 LA ET | ||||
| 33 | 492778 | 18.15 | 21.96 | |
| FOAM RUBBER STR AXT 55 | ||||
| 34 | 434716 | 1.51 | 1.83 | |
| WIRE RTM-EA VOLLST. | ||||
| 35 | 434527 | 2.90 | 3.51 | |
| WIRE RTM-EA VOLLST. | ||||
| 37 | 434865 | 2.81 | 3.40 | |
| HANDLE SEGMENT KF 4 E | ||||
| 38 | 451403 | 7.27 | 8.80 | |
| Oval head screw PT-4.0x20-KT15 | ||||
| 39 | 228567 | 1.51 | 1.83 | |
| Circlip DIN 471-13x1 | ||||
| 40 | 216770 | 1.51 | 1.83 | |
| SHIM RING DIN 988-13X19X0.5 | ||||
| 41 | 228503 | 1.51 | 1.83 | |
| Adjusting wheel OF 2 E | ||||
| 42 | 439282 | 5.54 | 6.70 | |
| Compens. washer 13,2x18,8x0,2 | ||||
| 43 | 436828 | 1.51 | 1.83 | |
| Disc DIN 125-A-4,3-140 HV | ||||
| 44 | 200576 | 1.51 | 1.83 | |
| Oval head screw M4x8-TAPTITE-T15 | ||||
| 45 | 228570 | 9.17 | 11.10 | |
| Ball bearing 6003 DDW CM DIN 625 NSK | ||||
| 46 | 462795 | 10.51 | 12.72 | |
| Circlip DIN 471-17x1 | ||||
| 47 | 401191 | 1.51 | 1.83 | |
| Countersink M4x10-TAPTITE-T15 | ||||
| 48 | 228581 | 1.51 | 1.83 | |
| Collet | ||||
| 49 | 488755 | 72.13 | 87.28 | |
| Collet | ||||
| 50 | 488755 | 72.13 | 87.28 | |
| No information available, not orderable | ||||
| 51 | xxx | |||
| No information available, not orderable | ||||
| 52 | xxx | |||
| Button KF 4 E D 23 M6x10 blau | ||||
| 53 | 436195 | 1.80 | 2.18 | |
| Guide OF 1 E | ||||
| 54 | 483449 | 6.26 | 7.57 | |
| Round guide KF 4 E | ||||
| 55 | 451754 | 7.63 | 9.23 | |
| Limit stop OF 1010 | ||||
| 56 | 10035623 | 19.48 | 23.57 | |
| No information available, not orderable | ||||
| 57 | xxx | |||
| Rest OF 1 E | ||||
| 58 | 437478 | 1.51 | 1.83 | |
| Countersink PT-4,0x10-KT15 | ||||
| 59 | 219102 | 1.51 | 1.83 | |
| SPRING DIN2098-1,25x11,50x255,0 | ||||
| 60 | 436377 | 1.66 | 2.01 | |
| ACRYLIC CHIP GU OF 1 E | ||||
| 61 | 437307 | 7.70 | 9.32 | |
| Button KF 4 E D 23 M6x10 blau | ||||
| 62 | 436195 | 1.80 | 2.18 | |
| Plate KF 5 | ||||
| 63 | 497763 | 89.30 | 108.05 | |
| GRADUATED BRACK OF 1 E VOLLST. | ||||
| 64 | 437197 | 19.12 | 23.14 | |
| Ch. head screw DIN 84 M6x8-4.8-TUF | ||||
| 65 | 437999 | 1.51 | 1.83 | |
| Plate OF 1 E | ||||
| 66 | 436477 | 14.16 | 17.13 | |
| Countersink M4x8-TAPTITE-T15 | ||||
| 67 | 219043 | 1.51 | 1.83 | |
| No information available, not orderable | ||||
| 68 | xxx | |||
| No information available, not orderable | ||||
| 69 | xxx | |||
| Ch. head screw DIN 912-M6x25-8.8-TUF | ||||
| 70 | 400859 | 1.51 | 1.83 | |
| Disc DIN 125-B-6,4-140 HV | ||||
| 71 | 200578 | 1.51 | 1.83 | |
| Bush KF 4 E | ||||
| 72 | 436300 | 1.94 | 2.35 | |
| Flat head screw DIN 85-M5x30-4.8-LONG | ||||
| 73 | 436813 | 2.38 | 2.88 | |
| Flat head screw DIN 85-M5x25-4.8-LONG | ||||
| 74 | 436812 | 2.02 | 2.44 | |
| Flat head screw DIN 85-M5x20-4.8-LONG | ||||
| 75 | 436811 | 1.73 | 2.09 | |
| Limit stop KF 4 E | ||||
| 76 | 436520 | 13.67 | 16.54 | |
| Ball DIN 5401-7-100CR6 | ||||
| 77 | 783305 | 1.51 | 1.83 | |
| SPRING DIN 2098-0,50x6,50x15,0 | ||||
| 78 | 436528 | 2.04 | 2.47 | |
| Bush OF 1010 R | ||||
| 79 | 10364663 | 1.80 | 2.18 | |
| Countersink M4x8-TAPTITE-KT15 | ||||
| 80 | 228737 | 1.51 | 1.83 | |
