Here you will find all available parts and drawings of the 'Festool 485900 (OF650)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Festool 485900 (OF650)
Spare parts list of model Festool 485900 (OF650)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| ARMATURE 230V OF 1010 Q 230V ET-BG | ||||
| 1 | 492039 | 147.02 | 177.89 | |
| Switch attachme ET 2 E | ||||
| 3 | 486317 | 15.00 | 18.15 | |
| CABLE WITH PLUG ZKS-22 DIN-H07RN-F | ||||
| 4 | 457603 | 24.81 | 30.02 | |
| Cable conduit RTR 1409 | ||||
| 5 | 432436 | 1.51 | 1.83 | |
| Oval head screw PT-3,5x10-KT15 | ||||
| 6 | 219031 | 7.32 | 8.86 | |
| No longer available, no replacement | ||||
| 7 | 451430 | |||
| Oval head screw M4x20-TAPTITE-T15 | ||||
| 8 | 228569 | 1.51 | 1.83 | |
| Oval head screw PT-3,5x10-KT15 | ||||
| 9 | 219031 | 7.32 | 8.86 | |
| BRUSH HOLDER OF 1000 EB | ||||
| 10 | 488579 | 11.52 | 13.94 | |
| No information available, not orderable | ||||
| 11 | 487836 | |||
| SPACER 15,8x21,8x0,2 L+MN 1100 | ||||
| 12 | 228759 | 1.51 | 1.83 | |
| Groove Ball Bearing 608 D1 MC3 E U152 J2 HA1 | ||||
| 13 | 10775821 | 5.54 | 6.70 | |
| WIRE RTM-EA VOLLST. | ||||
| 15 | 434527 | 2.90 | 3.51 | |
| Oval head screw PT-4,0x50-KT15 | ||||
| 16 | 228707 | 1.51 | 1.83 | |
| Air guide washe RTM-EA | ||||
| 17 | 434430 | 2.30 | 2.78 | |
| No information available, not orderable | ||||
| 18 | xxx | |||
| Circlip DIN 471-17x1 | ||||
| 19 | 401191 | 1.51 | 1.83 | |
| No longer available, no replacement | ||||
| 20 | 488771 | |||
| Bush 16x18x10 GGB 1610 DP4 | ||||
| 21 | 400994 | 1.51 | 1.83 | |
| SPRING DIN 2098-1,60x17,20x16,5 | ||||
| 22 | 440729 | 1.51 | 1.83 | |
| KNOB (REAR HALF KF 4 E M8x12 | ||||
| 23 | 436192 | 11.09 | 13.42 | |
| KNOB (FRONT HAL KF 4 E | ||||
| 24 | 436189 | 5.18 | 6.27 | |
| Pressure ring KF 4 E | ||||
| 25 | 436301 | 2.66 | 3.22 | |
| Bush 12x14x12 GGB 1212 DP4 | ||||
| 26 | 210031 | 1.51 | 1.83 | |
| Cover OFK 700 EQ | ||||
| 27 | 494788 | 13.67 | 16.54 | |
| Dowel pin DIN 1481-2x12-ST | ||||
| 28 | 200747 | 1.51 | 1.83 | |
| Cover OFK 700 EQ | ||||
| 29 | 473550 | 7.70 | 9.32 | |
| Compr. spring DIN 2098-0,70x7,50x14,7 | ||||
| 30 | 444754 | 1.51 | 1.83 | |
| Bolt KF 4 E | ||||
| 31 | 436305 | 10.01 | 12.11 | |
| CAP OF 1000 EB | ||||
| 32 | 450206 | 1.51 | 1.83 | |
| Collet | ||||
| 33 | 488755 | 72.13 | 87.28 | |
| Collet | ||||
| 33 | 488761 | 52.00 | 62.92 | |
| FOAM RUBBER STR AXT 55 | ||||
| 34 | 434716 | 1.51 | 1.83 | |
| CAPACITOR AXT 50 LA ET | ||||
| 35 | 492778 | 18.15 | 21.96 | |
| Cable clamp RS 3 | ||||
| 36 | 439288 | 1.51 | 1.83 | |
| Oval head screw PT-3,5x16-KT15 | ||||
| 37 | 228663 | 1.51 | 1.83 | |
| HANDLE SEGMENT KF 4 E | ||||
| 38 | 451403 | 7.27 | 8.80 | |
| Oval head screw PT-4.0x20-KT15 | ||||
| 39 | 228567 | 1.51 | 1.83 | |
| WIRE RTM-EA VOLLST. | ||||
| 40 | 434865 | 2.81 | 3.40 | |
| Circlip DIN 471-13x1 | ||||
| 41 | 216770 | 1.51 | 1.83 | |
| SHIM RING DIN 988-13X19X0.5 | ||||
| 42 | 228503 | 1.51 | 1.83 | |
| Adjusting wheel OF 2 E | ||||
| 43 | 439282 | 5.54 | 6.70 | |
| Compens. washer 13,2x18,8x0,2 | ||||
| 44 | 436828 | 1.51 | 1.83 | |
| Disc DIN 125-A-4,3-140 HV | ||||
| 45 | 200576 | 1.51 | 1.83 | |
| Oval head screw M4x8-TAPTITE-T15 | ||||
| 46 | 228570 | 9.17 | 11.10 | |
| Ball bearing 6003 DDW CM DIN 625 NSK | ||||
| 47 | 462795 | 10.51 | 12.72 | |
| Circlip DIN 471-17x1 | ||||
| 48 | 401191 | 1.51 | 1.83 | |
| No information available, not orderable | ||||
| 49 | xxx | |||
| No information available, not orderable | ||||
| 50 | xxx | |||
| Countersink M4x10-TAPTITE-T15 | ||||
| 51 | 228581 | 1.51 | 1.83 | |
| Collet | ||||
| 52 | 488755 | 72.13 | 87.28 | |
| Button KF 4 E D 23 M6x10 blau | ||||
| 53 | 436195 | 1.80 | 2.18 | |
| Guide OF 1 E | ||||
| 54 | 483449 | 6.26 | 7.57 | |
| Limit stop OF 1010 | ||||
| 55 | 10035623 | 19.48 | 23.57 | |
| SPRING DIN2098-1,25x11,50x255,0 | ||||
| 56 | 436377 | 1.66 | 2.01 | |
| Button KF 4 E D 23 M6x10 blau | ||||
| 57 | 436195 | 1.80 | 2.18 | |
| GRADUATED BRACK OF 1 E VOLLST. | ||||
| 58 | 437197 | 19.12 | 23.14 | |
| Ch. head screw DIN 84 M6x8-4.8-TUF | ||||
| 59 | 437999 | 1.51 | 1.83 | |
| Countersink M4x8-TAPTITE-T15 | ||||
| 60 | 219043 | 1.51 | 1.83 | |
| Round guide KF 4 E | ||||
| 61 | 451754 | 7.63 | 9.23 | |
| Rest OF 1 E | ||||
| 62 | 437478 | 1.51 | 1.83 | |
| Countersink PT-4,0x10-KT15 | ||||
| 63 | 219102 | 1.51 | 1.83 | |
| ACRYLIC CHIP GU OF 1 E | ||||
| 64 | 437307 | 7.70 | 9.32 | |
| No information available, not orderable | ||||
| 65 | xxx | |||
| No information available, not orderable | ||||
| 66 | xxx | |||
| Flat head screw DIN 85-M5x25-4.8-LONG | ||||
| 67 | 436812 | 2.02 | 2.44 | |
| Ch. head screw DIN 912-M6x25-8.8-TUF | ||||
| 68 | 400859 | 1.51 | 1.83 | |
| Disc DIN 125-B-6,4-140 HV | ||||
| 69 | 200578 | 1.51 | 1.83 | |
| Bush KF 4 E | ||||
| 70 | 436300 | 1.94 | 2.35 | |
| Flat head screw DIN 85-M5x30-4.8-LONG | ||||
| 71 | 436813 | 2.38 | 2.88 | |
| Flat head screw DIN 85-M5x20-4.8-LONG | ||||
| 72 | 436811 | 1.73 | 2.09 | |
| Limit stop KF 4 E | ||||
| 73 | 436520 | 13.67 | 16.54 | |
| Ball DIN 5401-7-100CR6 | ||||
| 74 | 783305 | 1.51 | 1.83 | |
| SPRING DIN 2098-0,50x6,50x15,0 | ||||
| 75 | 436528 | 2.04 | 2.47 | |
| Plate KF 5 | ||||
| 76 | 497763 | 89.30 | 108.05 | |
| Bush OF 1010 R | ||||
| 77 | 10364663 | 1.80 | 2.18 | |
| Countersink M4x8-TAPTITE-KT15 | ||||
| 78 | 228737 | 1.51 | 1.83 | |
| Plate OF 1 E | ||||
| 79 | 436477 | 14.16 | 17.13 | |
| No information available, not orderable | ||||
| 80 | xxx | |||
