Here you will find all available parts and drawings of the 'Festool 493956 ( MODULEDRAGER )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Festool 493956 ( MODULEDRAGER )
Spare parts list of model Festool 493956 ( MODULEDRAGER )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Rotary knob D34 Exz.10 blue | ||||
| 1 | 487755 | 8.45 | 10.22 | |
| Rotary knob D34 M6/8T blue | ||||
| 2 | 440713 | 2.71 | 3.28 | |
| Stud M6x20 DIN 938 5.8 | ||||
| 3 | 464525 | 1.39 | 1.68 | |
| Disc DIN 9021-6,4-100 HV | ||||
| 4 | 228546 | 1.39 | 1.68 | |
| Ch. head screw DIN 912-M6x12-10.9 | ||||
| 5 | 200684 | 1.39 | 1.68 | |
| Support device CS 70 EB | ||||
| 6 | 489181 | 26.86 | 32.50 | |
| Spring CS 70 EB B.-NR. VD-164 | ||||
| 7 | 448064 | 1.85 | 2.24 | |
| Cup square bolt DIN 603-M6x40-4.6 | ||||
| 8 | 228534 | 1.39 | 1.68 | |
| Spacer CS 70 EB | ||||
| 9 | 448066 | 8.52 | 10.31 | |
| Clamp. element CS 70 EB | ||||
| 10 | 488433 | 40.78 | 49.34 | |
| Clamp support CS 70 | ||||
| 11 | 10031568 | 14.16 | 17.13 | |
| Dowel pin DIN 7346-6x36-ST | ||||
| 12 | 400289 | 1.39 | 1.68 | |
| Handle CS 70 EB COMPLETE | ||||
| 13 | 487893 | 7.66 | 9.27 | |
| Rotary knob BASIS 2 D34 M6/11T | ||||
| 14 | 483350 | 6.67 | 8.07 | |
| Workpiece hold CS 70 EB | ||||
| 15 | 450199 | 6.60 | 7.99 | |
| GUARD BASIS 1 A VOLLST. | ||||
| 18 | 485762 | 46.46 | 56.22 | |
| Countersink DIN 965-M6x25-4.8 | ||||
| 19 | 403038 | 1.39 | 1.68 | |
| Profile plate BASIS 2 A | ||||
| 20 | 445496 | 173.76 | 210.25 | |
| Disc DIN 125-B-6,4-140 HV | ||||
| 21 | 200578 | 1.39 | 1.68 | |
| Hexagon nut DIN 439-M6 | ||||
| 22 | 200601 | 1.39 | 1.68 | |
| Spring VL -4-1/4 | ||||
| 23 | 207813 | 1.39 | 1.68 | |
| CLAMPING PLATE BASIS 2 A VORNE | ||||
| 24 | 442222 | 21.30 | 25.77 | |
| CLAMPING PLATE BASIS 2 A VORNE AP85E | ||||
| 24 | 440262 | 15.97 | 19.32 | |
| CLAMPING PLATE BASIS 2 A | ||||
| 25 | 442223 | 16.70 | 20.21 | |
| Disc CS 70 EB | ||||
| 26 | 448471 | 3.30 | 3.99 | |
| Flat head screw CS 70 EB | ||||
| 27 | 448065 | 4.03 | 4.88 | |
| Countersink M4x8-TAPTITE-T15 | ||||
| 28 | 219043 | 1.39 | 1.68 | |
| Oval head screw M4x6-DUO-TAPTITE-PZV | ||||
| 29 | 400348 | 1.39 | 1.68 | |
| GRADUATED SCALE CS 70 EB | ||||
| 30 | 488156 | 21.78 | 26.35 | |
| Swivel Section CS 70 EB ET-BG | ||||
| 31 | 10699976 | 43.56 | 52.71 | |
| Swiv. segment CS 70 EB | ||||
| 31 | 448014 | 30.13 | 36.46 | |
| Dowel pin DIN 7346-5x12-ST | ||||
| 32 | 228692 | 1.39 | 1.68 | |
| Clamping plate CS 50 EB | ||||
| 33 | 10023711 | 4.68 | 5.66 | |
| GUIDE PROFILE CS 70 EB | ||||
| 34 | 465708 | 31.34 | 37.92 | |
| Stop Profile CS 70 ET-BG | ||||
| 35 | 10711280 | 28.19 | 34.11 | |
| GUARD SUPPORT AP 85 E | ||||
| 36 | 443042 | 53.72 | 65.00 | |
| SCREW BASIS 1 | ||||
| 37 | 436038 | 8.78 | 10.62 | |
| CHAIN BASIS 1 A | ||||
| 38 | 440158 | 3.43 | 4.15 | |
| BOLT BASIS 1 A VOLLST. | ||||
| 39 | 484615 | 45.98 | 55.64 | |
| CHAIN BASIS 2 A | ||||
| 40 | 441042 | 7.26 | 8.78 | |
| Clamp OF 1 E ET-BG | ||||
| 41 | 200498 | 8.90 | 10.77 | |
| SPRING BASIS 1 | ||||
| 42 | 436040 | 5.41 | 6.55 | |
| CLAMPING PLATE BASIS 1 | ||||
| 43 | 436039 | 5.74 | 6.95 | |
| Disc DIN 9021-4,3-100 HV | ||||
| 44 | 403100 | 1.39 | 1.68 | |
| Oval head screw M4x8-TAPTITE-T15 | ||||
| 45 | 228570 | 1.39 | 1.68 | |
