Here you will find all available parts and drawings of the 'Festool 10890580 ( DF500RQUS )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Festool 10890580 ( DF500RQUS )

Spare parts list of model Festool 10890580 ( DF500RQUS )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
SWITCH ROD DF 500 Q
3 494014 30.86 37.34
HANDGREEPBOVEND DF 500 R
6 10960058 6.55 7.93
Screw DF 700 EQ
7 401076 4.36 5.28
HANGREEPONDERDE DF 500 R
9 10960059 6.77 8.19
Grub screw DF 700 EQ
10 478995 14.88 18.00
Segment DF 500 Q
12 493779 12.03 14.56
Pin DF 500 Q
13 469141 10.10 12.22
TAFEL DF 500 R
14 10880163 48.64 58.85
Grub screw DIN 913-M4x4-45H-PR30
15 401104 11.75 14.22
Oval head screw M3x6-DUO-TAPTITE-TORX
16 400983 12.41 15.02
SCHAAL DF 700
17 10962858 5.62 6.80
SLEDE DF 500 R ET-BG
18 11125886 69.76 84.41
FLEXIBLE KNIFE CS 70 EB 2208.006
19 400286 11.22 13.58
Grub screw DIN 915-M4x12-45H-TUF
20 203387 4.56 5.52
Segment DF 700
23 10001040 13.43 16.25
Oval head screw DIN 7380-M4x12-10.9
25 470216 5.94 7.19
Oval head screw DIN 7985-M5x12-8.8
29 400901 4.09 4.95
TAFEL DF 500 R ET-BG
34 11126512 125.91 152.35
Limit stop DF 700
38 702486 11.20 13.55
SCHUIF USA INCH PICKSET
39 11105959 10.08 12.20
TREKSTANG DF 500 R
41 11035584 7.56 9.15
angle plate DF 500 Q
43 464821 4.49 5.43
Intake flange DF 500 Q
44 465203 4.94 5.98
Extractor tube DF 500 Q
45 465204 8.58 10.38
Suc. conn. piec DF 500 CT
46 10027879 7.99 9.67
Oval head screw M4x8-TAPTITE-KT15
47 467961 6.53 7.90
Cover DF 500 Q
48 493153 9.90 11.98
switch handhold DF 500 Q
49 493815 9.64 11.66
Roller DF 500 Q
50 464837 4.36 5.28
SPRING 0,70x7,80x24,7 D115H11
51 467959 4.22 5.11
LEVER DF 500 Q
52 464839 4.94 5.98
TAP DF 500 Q
53 466890 10.63 12.86
Oval head screw M4x18-TAPTITE-T20
54 400904 11.48 13.89
BEHUIZING DFC 500 ET-BG
55 11101505 99.53 120.43
Cam spindle DF 500 Q
56 465947 17.18 20.79
INSERT DF 500 Q
57 466015 5.09 6.16
Lever pendular DF 500 Q
58 464840 52.64 63.69
INSERT DF 500 Q
59 466262 5.47 6.62
SPRING DF 500
60 472015 6.79 8.22
Main girder DF 500 Q ET-BG
61 493895 111.08 134.41
Oval head screw M4x8-TAPTITE-T15
62 228570 9.17 11.10
Inside pot DF 500 Q ET-BG
63 493920 106.06 128.33
Ball bearing DF 700
64 401073 27.35 33.09
Pendular pot DF 500 Q ET-BG
65 493898 98.01 118.59
LENSKOPSCHROEF M4X30-10.9-T20-IPR-PR80
66 10946232 1.51 1.83
Washer 5,3x10x1 DIN 125 PA
67 465024 7.06 8.54
Gear DF 500 Q ET-BG
68 493897 57.84 69.99
ECCENTRIC WHEEL DF 500 Q ET-BG
69 493896 84.58 102.34
Fan RO 2 E
70 485108 7.52 9.10
Oval head screw M4x14-TAPTITE-KT15
71 445566 14.59 17.65
BEARING FLANGE DF 500 Q ET-BG
72 493893 73.69 89.16
Setting slide DF 500 Q
73 492418 9.64 11.66
Cylinder pin DIN 7-2,5m6x18-ST
74 469645 4.03 4.88
Bolt DF 500 Q
75 469643 5.47 6.62
Gear DF 500 Q
76 205156 180.77 218.73
Cutter spindle DF 500 Q
77 201683 50.03 60.54
Ball bearing 625 ZZ 1MC3 J2 EA3LN
78 479254 6.73 8.14
Lock washer Din 6799-4
79 400106 3.89 4.71
TAP DF 500 Q
80 464847 4.49 5.43
screw RS 400
81 400552 6.34 7.67
AFNEEMBARE BORS DF 500 RQ ET-BG
82 11080949 30.91 37.40
AIR GUIDING DF 500 Q
83 465193 5.68 6.87
O-ring 16x1,5-NBR-70SHORE
84 400982 3.89 4.71
Oval head screw PT-4,0x16-KT15
85 228713 5.94 7.19
Ball bearing 626 DD M5MTLY 121
86 228672 6.79 8.22
MOTORHUIS DF 500 PRINTED
87 11056902 12.65 15.31
Oval head screw PT-3,5x10-KT15
88 219031 7.32 8.86
SCHAKELAARMODUL DF 500 RQ ET-BG
89 11080942 60.92 73.71
CAP DF 500 Q
90 465032 7.26 8.78
O-ring 4x1,5-NBR-75SHORE
91 200911 5.74 6.95
AANSLAGHOEK DF 500
92 10679826 7.92 9.58
Clamping screw AW-DF500
93 469620 7.73 9.35
AANSLAG DF 500 R ET-BG
94 11155475 11.88 14.37
VERGRENDELKAP DFC 500
94 11073388 5.11 6.18
SPRING DIN 2098-0,50x6,50x15,0
95 436528 2.04 2.47
Lock bolt DF 500 Q
96 701474 16.87 20.41
BUFFER DF 700 EQ
98 478994 1.37 1.66
SLIDE SWITCH RO 2 E
99 446002 4.88 5.90
Circlip AV 12-BLS-SEEGER
100 401062 4.36 5.28
Deep Groove Ball Bearing 6901 VV C3U 246T HA1S9
101 10779006 12.83 15.52
GELEIDER DF 500 R ET-BG
102 11126516 399.78 483.73
SPANNER SW 8 DIN894
105 401739 8.18 9.90
SPANHENDEL DF 500 R
112 10866442 22.87 27.67
Clamp lever DF 700
114 498315 14.83 17.94
Indicator DF 700
116 10000925 6.34 7.67
Oval head screw DIN 7380-M4x12-10.9
118 470216 5.94 7.19
Grub screw DIN 913-M4x4-45H-PR30
119 401104 11.75 14.22
PEN DIN 8734 3M6 X 32
120 10848932 12.01 14.53
VEERPLAAT DF 500 R
123 10884559 7.56 9.15
Oval head screw M5x16-TAPTITE-T25
124 10016393 6.94 8.40
AFDEKPLAAT DF 500 R
125 10837571 7.56 9.15
VERGRENDELING DF 500 R
126 10862898 5.18 6.27
VERGRENDELING DF 500 R
127 10892043 5.18 6.27
DRUKVEER 0,50 X 5,00X 11,10X 3,50
128 467680 1.66 2.01
AFSTANDSBUIS DF 500 TRANSPORTSICHERUN
133 10575293 5.76 6.97
