Here you will find all available parts and drawings of the 'Festool 497845 (CTL48ELEEC)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Festool 497845 (CTL48ELEEC)
Spare parts list of model Festool 497845 (CTL48ELEEC)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Quick-coupl. so KD-1/4 ET-BG | ||||
| 1 | 200473 | 33.52 | 40.56 | |
| Packing set ET-BG CT 26/36 | ||||
| 2 | 496573 | 18.15 | 21.96 | |
| Distributor ET-BG Zubeh r CT 26/36 | ||||
| 3 | 499289 | 51.91 | 62.81 | |
| Cable harness EAA CT B22/EC ET-BG | ||||
| 5 | 498680 | 90.87 | 109.95 | |
| Oval head screw PT-3,5x14-T15 | ||||
| 7 | 452450 | 1.66 | 2.01 | |
| No information available, not orderable | ||||
| 8 | xxx | |||
| No information available, not orderable | ||||
| 9 | 479711 | |||
| Lock washer 6 CAMLOC NR. 06530950005 | ||||
| 10 | 460025 | 1.51 | 1.83 | |
| air filter CT N B1 ET-BG | ||||
| 11 | 200816 | 45.13 | 54.61 | |
| Oval head screw PT-4,0x25-T15 | ||||
| 12 | 400695 | 1.51 | 1.83 | |
| No information available, not orderable | ||||
| 13 | 2154 | |||
| Restrictor CTL EC ET-BG | ||||
| 14 | 10019915 | 52.39 | 63.39 | |
| Rotary knob D44_ET-BG CT26/36 | ||||
| 15 | 496247 | 19.00 | 22.99 | |
| No information available, not orderable | ||||
| 16 | 452051 | |||
| Closing Plug | ||||
| 17 | 700389 | 6.98 | 8.45 | |
| No information available, not orderable | ||||
| 18 | 479713 | |||
| No information available, not orderable | ||||
| 19 | 702479 | |||
| No information available, not orderable | ||||
| 21 | 452452 | |||
| Switch ET-BG CT26/36 | ||||
| 22 | 496246 | 19.60 | 23.72 | |
| Handle cover CT 26/36 ET-BG | ||||
| 23 | 200581 | 12.71 | 15.38 | |
| No information available, not orderable | ||||
| 24 | 454651 | |||
| Handle CT N B1 ET-BG | ||||
| 25 | 204111 | 19.36 | 23.43 | |
| Locking latch CT N B1 ET-BG | ||||
| 26 | 200873 | 12.71 | 15.38 | |
| No information available, not orderable | ||||
| 27 | 498670 | |||
| No information available, not orderable | ||||
| 28 | xxx | |||
| Flat belt cable CT B22/EC ET-BG | ||||
| 29 | 498671 | 74.42 | 90.05 | |
| Oval head screw PT-4,0x12-KT15 | ||||
| 30 | 219071 | 1.51 | 1.83 | |
| Interference fi CT B22/EC ET-BG | ||||
| 31 | 498672 | 92.08 | 111.42 | |
| Cable CT B22/EC ET-BG | ||||
| 32 | 498673 | 40.54 | 49.05 | |
| Flexible lead CT B22/EC ET-BG | ||||
| 33 | 200840 | 17.55 | 21.24 | |
| Cable harness CT N B1 ET-BG | ||||
| 34 | 200837 | 30.37 | 36.75 | |
| Cable harness CT N ET-BG | ||||
| 35 | 200628 | 11.95 | 14.46 | |
| CABLE W.CONNECT H07RN-F 3x1,5 DIN ET-BG | ||||
| 36 | 200639 | 70.42 | 85.21 | |
| Electronics CTM EC 230V FL VP | ||||
| 37 | 203981 | 389.62 | 471.44 | |
| Oval head screw PT-5,0x30-T25 | ||||
| 38 | 452447 | 1.58 | 1.91 | |
| Seal 6x6 Rechteckprofil ET-BG | ||||
| 39 | 200603 | 20.33 | 24.60 | |
| Cover plate CT N B1 ET-BG | ||||
| 40 | 200882 | 54.45 | 65.88 | |
| Signal generato CT B22/EC ET-BG | ||||
| 41 | 498674 | 52.27 | 63.25 | |
| Control electro 230V CT B22/EC ET-BG | ||||
| 42 | 498779 | 389.62 | 471.44 | |
| Flexible lead CT B22/EC Turbine ET-BG | ||||
| 43 | 200841 | 17.42 | 21.08 | |
| Seal Filterg. CT N B1 ET-BG | ||||
| 44 | 200821 | 25.29 | 30.60 | |
| Cable clamp CT MINI ET-BG | ||||
| 45 | 200536 | 14.64 | 17.71 | |
| Rubber sleeve CT N B1 ET-BG | ||||
| 46 | 200819 | 22.63 | 27.38 | |
| Adhesive label CT B22/EC ET-BG | ||||
| 47 | 498675 | 35.09 | 42.46 | |
| Oval head screw PT-5,0x80-T25 | ||||
| 48 | 452448 | 1.51 | 1.83 | |
| No information available, not orderable | ||||
| 49 | 498676 | |||
| No information available, not orderable | ||||
| 50 | 479930 | |||
| Cup seal CT N B1 ET-BG | ||||
| 51 | 200848 | 23.35 | 28.25 | |
| Plug socket CT 16A/250V ET-BG | ||||
| 52 | 200507 | 20.57 | 24.89 | |
| Cover CT Steckdose mit Rahmen | ||||
| 53 | 200504 | 13.43 | 16.25 | |
| Oval head screw PT 5,0x30 T25 | ||||
| 54 | 467456 | 1.51 | 1.83 | |
| Cable harness Wasser CT B22/EC ET-BG | ||||
| 55 | 498678 | 46.46 | 56.22 | |
| Cable harness PTC_ET-BG CT26/36 | ||||
| 56 | 496252 | 22.75 | 27.53 | |
| Reservoir seal CT N ET-BG | ||||
| 57 | 201007 | 25.05 | 30.31 | |
| Filter case CT 26/36 ET-BG | ||||
| 58 | 201794 | 90.51 | 109.52 | |
| Filter holder ET-BG CT26/36 | ||||
| 59 | 496255 | 26.86 | 32.50 | |
| Cover CT26/36 ET-BG | ||||
| 60 | 201975 | 43.80 | 53.00 | |
| Hood ET-BG CT 26/36 | ||||
| 61 | 496250 | 43.32 | 52.42 | |
| Noise abat. par Abluft CTN-B1 ET-BG | ||||
| 62 | 200879 | 16.58 | 20.06 | |
| Sound insulatio ET-BG CT26/36 | ||||
| 63 | 496258 | 37.87 | 45.82 | |
| Clamp ET-BG CT26/36 | ||||
| 64 | 496262 | 20.33 | 24.60 | |
| Seal Turbine CT N EC B1 ET-BG | ||||
| 65 | 200858 | 41.87 | 50.66 | |
| Packing set ET-BG CT26/36 | ||||
| 66 | 496263 | 25.29 | 30.60 | |
| Ch. head screw DIN 912-M4x18-8.8-TUF | ||||
| 67 | 702520 | 1.73 | 2.09 | |
| Collet CT N EC/B1 ET-BG | ||||
| 68 | 200897 | 18.63 | 22.54 | |
| Turbine 230V CT B22/EC ET-BG | ||||
| 69 | 498780 | 374.62 | 453.29 | |
| Sealing set ET-BG CT26/36 | ||||
| 70 | 496256 | 22.75 | 27.53 | |
| Cover CT26/36 ET-BG | ||||
| 71 | 201975 | 43.80 | 53.00 | |
| Oval head screw PT-4,0x16-KT15 | ||||
| 72 | 228713 | 5.94 | 7.19 | |
| Bolt CT 26/36 ET-BG | ||||
| 75 | 500314 | 18.15 | 21.96 | |
| Bolt CT 26/36 ET-BG | ||||
| 76 | 500314 | 18.15 | 21.96 | |
| Rest Filtersack CT N ET-BG | ||||
| 77 | 200591 | 10.01 | 12.11 | |
| No information available, not orderable | ||||
| 78 | xxx | |||
| Contact ET-BG CT26/36 | ||||
| 79 | 496221 | 23.72 | 28.70 | |
| Muff CT 26/36 ET-BG | ||||
| 80 | 200568 | 13.31 | 16.11 | |
| Oval head screw PT 5,0x30 T25 | ||||
| 81 | 467456 | 1.51 | 1.83 | |
| Restrictor ET-BG CT36 | ||||
| 82 | 496267 | 20.33 | 24.60 | |
| Leg CT 26/36 ET-BG | ||||
| 83 | 500317 | 27.10 | 32.79 | |
| Torsion spring CT MINI ET-BG | ||||
| 84 | 200539 | 3.82 | 4.62 | |
| Leg CT 26/36 ET-BG | ||||
| 85 | 500317 | 27.10 | 32.79 | |
| Oval head screw PT-5,0x30-T25 | ||||
| 86 | 452447 | 1.58 | 1.91 | |
| Holder Lenkrolle CT 48 ET-BG | ||||
| 87 | 200824 | 10.15 | 12.28 | |
| ROLLER CT | ||||
| 88 | 452840 | 19.48 | 23.57 | |
| Container CT B22/EC ET-BG | ||||
| 89 | 498669 | 266.93 | 322.99 | |
| Pipe Achse CT 48 ET-BG | ||||
| 90 | 200823 | 21.30 | 25.77 | |
| Wheel ET-BG CT26/36 | ||||
| 91 | 496230 | 34.24 | 41.43 | |
| Tooth ring CT 17 ET-BG | ||||
| 92 | 202484 | 3.67 | 4.44 | |
| Wheel cover D200 CT 26/36 ET-BG | ||||
| 93 | 200570 | 11.02 | 13.33 | |
| Blanking plug | ||||
| 94 | 452899 | 18.00 | 21.78 | |
| Handle | ||||
| 95 | 497295 | 136.00 | 164.56 | |
| Assembly kit SB ET-BG CT 48 | ||||
| 96 | 500253 | 66.07 | 79.94 | |
| No information available, not orderable | ||||
| 97 | 477176 | |||
