Here you will find all available parts and drawings of the 'Festool 205372 ( CTH26EHF-NAU )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Festool 205372 ( CTH26EHF-NAU )

Spare parts list of model Festool 205372 ( CTH26EHF-NAU )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Oval head screw PT-3,5x14-T15
1 452450 1.66 2.01
Plug socket CT MINI 230V Abd. ET-BG
2 200531 23.60 28.56
Cable harness CTN ET-BG
3 201717 9.29 11.24
Cylinder Screw SCHW. M6x60 ET-BG
4 10737236 2.02 2.44
Cover ET-BG CT26/36
5 496234 21.30 25.77
Rotary knob D28_ET-BG CT26/36
7 496249 20.45 24.74
Rotary knob D44_ET-BG CT26/36
9 496247 19.00 22.99
O-ring 9.3x2.4-NBR ET-BG
10 10737044 1.94 2.35
Galvanized Screw DIN 965-M4x8-6.8 ET-BG
11 10737121 1.94 2.35
Restrictor CTM 26/36 FL VP
12 203970 25.05 30.31
Switch ET-BG CT26/36
13 496246 19.60 23.72
Board segment CT 26/36 ET-BG
14 200599 5.40 6.53
Cable harness CT N ET-BG
15 200628 11.95 14.46
Electronics CTM 230V FL VP
16 203978 208.24 251.97
Clamp ET-BG CT26/36
17 496236 21.30 25.77
Hood CT 26/36 FL VP
18 204040 63.89 77.31
Cylinder head screw PT5x140 T25 ET-BG
19 10737262 2.45 2.96
Oval head screw PT-5,0x30-T25
20 452447 1.58 1.91
Housing insert ET-BG CT26/36
22 496238 36.78 44.50
Handle ET-BG CT26/36
23 496244 21.54 26.06
Casing box ET-BG CT26/36
24 496243 50.70 61.35
Cable holder CT VP
25 203722 23.60 28.56
Pan Head Screw PT-5x30-PZV ET-BG
26 10737172 2.02 2.44
CABLE W.CONNECT H07RN-F 3x1,5 DIN ET-BG
27 200639 70.42 85.21
Inlet bush
28 200590 10.30 12.46
Cable clamp CTN ET-BG
29 200586 4.03 4.88
Hood ET-BG CT 26/36
30 496250 43.32 52.42
Cable harness ET-BG CT26/36
31 496251 30.01 36.31
Flexible lead p ET-BG CT26/36 USA
32 496773 23.35 28.25
Oval head screw PT 5,0x30 T25
33 467456 1.51 1.83
Reservoir seal CT N ET-BG
34 201007 25.05 30.31
Filter holder CTH ET-BG
35 497649 45.74 55.35
Filter holder ET-BG CT26/36
35 496255 26.86 32.50
Filter Housing CTH HF-N Reed cont. ET-BG
36 10785460 145.93 176.58
Cover CT26/36 ET-BG
37 201975 43.80 53.00
Sound insulatio ET-BG CT26/36
38 496258 37.87 45.82
Cable bushing CTN ET-BG
39 200584 16.70 20.21
Cable harness CTN ET-BG
40 200565 10.73 12.98
Clamp ET-BG CT26/36
41 496262 20.33 24.60
Solenoid ring CT 26/36 ET-BG
42 200594 8.28 10.02
Turbine ET-BG 230V CT26/36
44 10494016 172.91 209.22
Brush ET-BG 240v CT26/36
45 496268 37.63 45.53
Sealing set ET-BG CT26/36
46 496256 22.75 27.53
Cylinder screw M5x16 ET-BG
48 10739618 3.02 3.65
Lock washer D 3,2 DIN 6799
49 479114 1.51 1.83
Cable harness Magnet Ct 26/36 AC ET-BG
51 200889 25.17 30.46
Rest CT 26/36 AC USA ET-BG
52 200887 42.96 51.98
Rest CT 26/36 AC ET-BG
52 200855 15.61 18.89
Damper ring CT 26/36 AC ET-BG
53 200854 20.57 24.89
Solenoid CT 26/36 AC ET-BG
54 200852 62.19 75.25
Magnetic holder CT 26/36 AC ET-BG
55 200853 13.31 16.11
Spring CT 26/36 AC II ET-BG
56 201004 18.03 21.82
Spring plate CT-N ET-BG
60 200528 19.12 23.14
Valve collar CT N AC ET-BG
61 498827 30.86 37.34
Rest Filtersack CT N ET-BG
64 200591 10.01 12.11
Seal CT 26/36 ET-BG
65 200574 5.18 6.27
Contact ET-BG CT26/36
66 496221 23.72 28.70
Muff CT 26/36 ET-BG
67 200568 13.31 16.11
Restrictor ET-BG CT26
69 496223 19.48 23.57
Holder Lenkrolle CT26/36 ET-BG
74 200593 11.35 13.73
ROLLER CT
75 452840 19.48 23.57
Container ET-BG CT 26
76 496233 81.92 99.12
Pipe CTN ET-BG
77 200571 17.55 21.24
Tooth ring CT 17 ET-BG
79 202484 3.67 4.44
Wheel cover D200 CT 26/36 ET-BG
80 200570 11.02 13.33
Assembly kit SB ET-BG CT 26/36
84 500252 94.38 114.20
Locking latch CT N B1 ET-BG
85 200873 12.71 15.38
Handle CT 36 HD ET-BG
87 500318 16.34 19.77
Countersunk screw PT 5,0x40 TORX ET-BG
88 10739635 1.94 2.35
Bow ET-BG VCP 260
89 35000546 49.13 59.45
Casing box CT 36 HD ET-BG
90 500320 91.48 110.69
Housing insert CT 36 HD ET-BG
91 500319 34.49 41.73
Cable clamp CT 36 HD ET-BG
92 201023 15.00 18.15
Insert CT 26/36 ET-BG
93 500321 35.21 42.60
Box ET-BG CT 36 HD
94 35000553 72.96 88.28
Bolt CT 26/36 ET-BG
95 500314 18.15 21.96
Container kompl. CT 26 ET-BG
96 500327 137.82 166.76
Wheel CT 26/36 ET-BG
97 500316 37.27 45.10
Leg CT 26/36 ET-BG
98 500317 27.10 32.79
CTH 26 E ET-BG
100 10737642 2.16 2.61
Locking latch SVG-CT MINI ET-BG
101 200534 10.87 13.15
Closure SYS TL kpl- SG2-T01-002
103 497819 15.00 18.15
Protecting cap CT 26 / 36 VP
105 204307 17.30 20.93
