Here you will find all available parts and drawings of the 'Festool 494735 (BF-OF-CMS)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Festool 494735 (BF-OF-CMS)
Spare parts list of model Festool 494735 (BF-OF-CMS)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| GEAR COVER CMS-OF | ||||
| 1 | 472932 | 8.64 | 10.45 | |
| Stop rail,right CMS-OF | ||||
| 2 | 473324 | 3.82 | 4.62 | |
| Cup square bolt DIN 603-M6x30-4.6 | ||||
| 3 | 771793 | 1.51 | 1.83 | |
| Rotary knob SF-OF D 23 M6x23 blau | ||||
| 4 | 486243 | 2.38 | 2.88 | |
| Cup square bolt DIN 603-M6x40-4.6 | ||||
| 5 | 228534 | 1.51 | 1.83 | |
| Rotary knob D34 M6x111blau | ||||
| 6 | 485667 | 7.92 | 9.58 | |
| Guide tube CMS | ||||
| 7 | 473325 | 9.94 | 12.03 | |
| Rotary knob KF 4 E D 23 M6 / 8T | ||||
| 8 | 440712 | 2.88 | 3.48 | |
| CLAMP CMS-OF | ||||
| 9 | 473326 | 1.66 | 2.01 | |
| Extractor conne CMS-OF | ||||
| 10 | 472933 | 15.37 | 18.60 | |
