Here you will find all available parts and drawings of the 'Festool 486169 ( BASIS2A )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Festool 486169 ( BASIS2A )
Spare parts list of model Festool 486169 ( BASIS2A )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Rotary knob D34 Exz.10 blue | ||||
| 1 | 487755 | 8.45 | 10.22 | |
| Rotary knob D34 M6x27,5 blau | ||||
| 2 | 486202 | 2.57 | 3.11 | |
| Disc DIN 9021-6,4-100 HV | ||||
| 3 | 228546 | 1.39 | 1.68 | |
| Swivel Section CS 70 EB ET-BG | ||||
| 4 | 10699976 | 43.56 | 52.71 | |
| Swiv. segment CS 70 EB | ||||
| 4 | 448014 | 30.13 | 36.46 | |
| Ch. head screw DIN 912-M6x12-10.9 | ||||
| 6 | 200684 | 1.39 | 1.68 | |
| Support device CS 70 EB | ||||
| 7 | 489181 | 26.86 | 32.50 | |
| Rotary knob D34 M6/8T blue | ||||
| 8 | 440713 | 2.71 | 3.28 | |
| Stud M6x20 DIN 938 5.8 | ||||
| 9 | 464525 | 1.39 | 1.68 | |
| SPRING BASIS 1 A/T | ||||
| 10 | 458559 | 15.25 | 18.45 | |
| Cup square bolt DIN 603-M6x40-4.6 | ||||
| 11 | 228534 | 1.39 | 1.68 | |
| Spacer CS 70 EB | ||||
| 12 | 448066 | 8.52 | 10.31 | |
| Workpiece hold CS 70 EB | ||||
| 13 | 450199 | 6.60 | 7.99 | |
| Square nut DIN 557-M8-05 | ||||
| 14 | 219098 | 1.39 | 1.68 | |
| Ch. head screw DIN 912-M8x25-10.9 | ||||
| 15 | 200693 | 1.39 | 1.68 | |
| GUARD BASIS 1 A VOLLST. | ||||
| 16 | 485762 | 46.46 | 56.22 | |
| Countersink DIN 965-M6x25-4.8 | ||||
| 17 | 403038 | 1.39 | 1.68 | |
| Profile plate BASIS 2 A | ||||
| 18 | 445496 | 173.76 | 210.25 | |
| Disc DIN 125-B-6,4-140 HV | ||||
| 19 | 200578 | 1.39 | 1.68 | |
| Hexagon nut DIN 439-M6 | ||||
| 20 | 200601 | 1.39 | 1.68 | |
| Spring VL -4-1/4 | ||||
| 21 | 207813 | 1.39 | 1.68 | |
| Rotary knob BASIS 2 D34 M6/11T | ||||
| 22 | 483350 | 6.67 | 8.07 | |
| CLAMPING PLATE BASIS 2 A VORNE | ||||
| 23 | 442222 | 21.30 | 25.77 | |
| CLAMPING PLATE BASIS 2 A VORNE AP85E | ||||
| 23 | 440262 | 15.97 | 19.32 | |
| Disc CS 70 EB | ||||
| 24 | 448471 | 3.30 | 3.99 | |
| Flat head screw CS 70 EB | ||||
| 25 | 448065 | 4.03 | 4.88 | |
| Countersink M4x8-TAPTITE-T15 | ||||
| 26 | 219043 | 1.39 | 1.68 | |
| Oval head screw M4x6-DUO-TAPTITE-PZV | ||||
| 27 | 400348 | 1.39 | 1.68 | |
| GRADUATED SCALE CS 70 EB | ||||
| 28 | 488156 | 21.78 | 26.35 | |
| Clamping plate CS 50 EB | ||||
| 31 | 10023711 | 4.68 | 5.66 | |
| Dowel pin DIN 7346-5x12-ST | ||||
| 32 | 228692 | 1.39 | 1.68 | |
| CLAMPING PIECE BASIS WRA 500 | ||||
| 33 | 490276 | 79.74 | 96.49 | |
| GUARD SUPPORT AP 85 E | ||||
| 34 | 443042 | 53.72 | 65.00 | |
| SCREW BASIS 1 | ||||
| 35 | 436038 | 8.78 | 10.62 | |
| CHAIN BASIS 1 A | ||||
| 36 | 440158 | 3.43 | 4.15 | |
| BOLT BASIS 1 A VOLLST. | ||||
| 37 | 484615 | 45.98 | 55.64 | |
| CHAIN BASIS 2 A | ||||
| 38 | 441042 | 7.26 | 8.78 | |
| Clamp OF 1 E ET-BG | ||||
| 39 | 200498 | 8.90 | 10.77 | |
| SPRING BASIS 1 | ||||
| 40 | 436040 | 5.41 | 6.55 | |
| CLAMPING PLATE BASIS 1 | ||||
| 41 | 436039 | 5.74 | 6.95 | |
| Disc DIN 9021-4,3-100 HV | ||||
| 42 | 403100 | 1.39 | 1.68 | |
| Oval head screw M4x8-TAPTITE-T15 | ||||
| 43 | 228570 | 1.39 | 1.68 | |
| CLAMPING PLATE BASIS 2 A | ||||
| 44 | 442223 | 16.70 | 20.21 | |
| Rotary knob BASIS 2 D34 M6/11T | ||||
| 45 | 483350 | 6.67 | 8.07 | |
| GUIDE PROFILE CS 70 EB | ||||
| 46 | 465708 | 31.34 | 37.92 | |
| Stop Profile CS 70 ET-BG | ||||
| 47 | 10711280 | 28.19 | 34.11 | |
