Here you will find all available parts and drawings of the 'Festool 495833 ( ASA6000CT-SR-EU )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Festool 495833 ( ASA6000CT-SR-EU )
Spare parts list of model Festool 495833 ( ASA6000CT-SR-EU )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Carrier ASA 6000 | ||||
| 1 | 450021 | 582.49 | 704.81 | |
| Carrier ASA 5000 | ||||
| 1 | 445452 | 422.65 | 511.41 | |
| Ch. head screw DIN 912-M8x35-8.8 | ||||
| 2 | 200695 | 1.39 | 1.68 | |
| Angle holder ASA | ||||
| 3 | 445450 | 290.64 | 351.67 | |
| Hose ASA 5000 | ||||
| 4 | 445466 | 59.17 | 71.60 | |
| Clip ASA 5000 | ||||
| 5 | 445467 | 22.26 | 26.93 | |
| Blind rivet ASA 5000 | ||||
| 6 | 445469 | 7.85 | 9.50 | |
| Cable clamp EAA-D | ||||
| 7 | 495716 | 30.25 | 36.60 | |
| Pipe EAA-AD-ASA Alu | ||||
| 8 | 477905 | 116.16 | 140.55 | |
| Air hose BG_11m EAA-D | ||||
| 9 | 495748 | 128.26 | 155.19 | |
| Air hose BG_10m EAA-D | ||||
| 9 | 495749 | 89.06 | 107.76 | |
| Control cable v. EAA 2x0.34 PVC 11M | ||||
| 10 | 495491 | 144.96 | 175.40 | |
| Control cable v. EAA 2x0.34 PVC 10M | ||||
| 10 | 495505 | 114.22 | 138.21 | |
| Mains cable H07 RN-F 3x1.51 11M DIN | ||||
| 11 | 475407 | 144.96 | 175.40 | |
| Cable with plug H07 RN-F 3x1.5 10MDIN | ||||
| 11 | 475439 | 144.96 | 175.40 | |
| Countersink M6x16 | ||||
| 12 | 411272 | 1.39 | 1.68 | |
| Gearwheel kit ASA ET-BG | ||||
| 13 | 496322 | 86.15 | 104.24 | |
| Protective hose ASA 5000 | ||||
| 14 | 445463 | 26.14 | 31.63 | |
| Pipe ASA 5000 | ||||
| 15 | 445461 | 12.83 | 15.52 | |
| Plate ASA ET-BG | ||||
| 16 | 496320 | 186.10 | 225.18 | |
| Hexagon nut M14 DIN 982 FE/ZN 8 BK | ||||
| 17 | 400588 | 3.70 | 4.48 | |
| Hinge ASA ET-BG | ||||
| 18 | 496321 | 592.66 | 717.12 | |
| Carrier ASA 6000 | ||||
| 19 | 450020 | 650.98 | 787.69 | |
| Fitting ASA 5000 | ||||
| 20 | 445460 | 31.82 | 38.50 | |
| Cheese head scr M8x20 A3H | ||||
| 21 | 400153 | 6.41 | 7.76 | |
| Bolt ASA 5000 | ||||
| 22 | 445446 | 35.33 | 42.75 | |
| Axis ASA ET-BG | ||||
| 23 | 496318 | 123.06 | 148.90 | |
| bearing ASA ET-BG | ||||
| 24 | 496319 | 331.06 | 400.58 | |
| Bracket ASA | ||||
| 25 | 495837 | 302.26 | 365.73 | |
| Pipe squeezing ASA 5000 | ||||
| 26 | 445456 | 37.39 | 45.24 | |
| RIVET A4x16 DIN 7337 | ||||
| 27 | 400152 | 5.47 | 6.62 | |
| Installation du | ||||
| 28 | 445473 | 139.88 | 169.25 | |
| Protective hose ASA 5000 | ||||
| 29 | 445459 | 51.79 | 62.67 | |
| Pipe ASA 5000 2000 MM | ||||
| 30 | 445472 | 117.13 | 141.73 | |
| Connecting piec ASA 5000 kpl. | ||||
| 31 | 489397 | 37.27 | 45.10 | |
| Corrugated hose ASA | ||||
| 32 | 477972 | 58.56 | 70.86 | |
| Terminal screw Fa. Oetiker ET-BG | ||||
| 33 | 200632 | 11.37 | 13.76 | |
| Plug ASA EAA 230V EU | ||||
| 35 | 497961 | 44.65 | 54.03 | |
| Plug STEUERLEITUNG ASA EAA | ||||
| 36 | 497963 | 41.74 | 50.51 | |
| Plug Steuerleitung EAA | ||||
| 37 | 497967 | 56.26 | 68.07 | |
