Here you will find all available parts and drawings of the 'Festool 489564 ( AP85EB230V )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Festool 489564 ( AP85EB230V )

Spare parts list of model Festool 489564 ( AP85EB230V )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
ARMATURE 230V AP 85 EB
1 493791 210.78 255.04
FIELD COIL AP 85 E ET-BG
2 495626 139.15 168.37
SWITCH CARD AP 55 EB
3 489830 81.43 98.53
Mains cable H07 RN-F EURO
4 637685 22.02 26.64
Cable conduit RTR 1409
5 432436 1.39 1.68
Cover SP 85/45 EB
6 638721 42.47 51.39
BLADE COVER WIN AP 55 E
7 438943 3.82 4.62
Countersink M4x16-TAPTITE-KT15
8 228732 1.39 1.68
SWING GUARD STO AP 85 E
9 440506 8.98 10.87
Ch. head screw DIN 912-M8x25-10.9
10 200693 1.39 1.68
No longer available, no replacement
11 441732
Countersink M4x8-TAPTITE-T15
12 219043 1.39 1.68
FLANGE AXP 85
13 435057 8.64 10.45
SPRING AP 85 E
14 442275 7.73 9.35
Countersink M4x12-TAPTITE-T15
15 219053 1.39 1.68
BEARING COVER AP 85 E
16 439907 28.68 34.70
Ball bearing 6202 2RS DIN 625
17 789775 9.24 11.18
SEAL DG 20x35x5/01Z01
18 440009 14.16 17.13
Cup square bolt DIN 603-M8x25-4.6
19 400553 1.39 1.68
BUFFER AXP 130
20 714434 4.49 5.43
BUSH BK 1212
21 410229 8.64 10.45
RING AP 85 E
22 441219 6.41 7.76
No information available, not orderable
25 xxx
No information available, not orderable
26 440085
SPACER AP 55 E
27 440546 1.39 1.68
Oval head screw DIN 7985-M4x35-4.8
28 228660 1.39 1.68
SPINDLE STOP KN AP 55 E
29 440441 3.04 3.68
Pressure Sprin GRA-1/4-B
30 201134 1.39 1.68
O-ring 8x2,2-NBR-75SHORE
31 400013 1.39 1.68
Disc DIN 7349-8,4-100 HV
32 228527 1.39 1.68
No longer available, no replacement
33 441733
Grub screw DIN 914-M4x6-45H
34 224954 1.39 1.68
PENDULUM COVER AP 85 E
35 442276 83.01 100.44
Spacer wedge AP 85 E
36 439887 59.90 72.48
No information available, not orderable
37 xxx
Tooth ring ZA-5-SEEGER
38 234883 1.39 1.68
O-ring 71,5x1,5-NBR-75SHORE
39 200973 1.39 1.68
Circlip JV 35x1,5-SEEGER
40 205454 2.57 3.11
Gear shaft AP 85 E
41 445440 63.04 76.28
Oval head screw M4x16-TAPTITE-T15
42 219075 1.39 1.68
STRIPPER AP 85 E
43 441218 5.09 6.16
CLIP AP 85 E
44 440685 4.42 5.35
ADJUSTING WHEEL AP 55 E
45 440991 4.88 5.90
BOLT AP 85 E
46 439903 8.11 9.81
Disc DIN 9021-8,4-100 HV
47 219049 1.39 1.68
NUT AP 85 E
48 439911 5.41 6.55
LEVER AP 85 E
49 439922 2.51 3.04
Countersink M5x10-TAPTITE-KT15
50 219044 1.39 1.68
BALL BEARING 608 2Z C3 DIN 625
51 228559 4.30 5.20
Ball bearing 6201 DDU C3 E D8 MA7S-M
52 400065 8.38 10.14
FAN AP 85 E VOLLST.
53 483808 21.90 26.50
BALL BEARING 6000 2Z C3 DIN 625
54 789573 7.85 9.50
WASHER TN 232012
55 411613 1.39 1.68
Shim ring DIN 988-19x26x0,5
56 434608 1.39 1.68
COVER AP 85 E
57 441327 1.39 1.68
GUIDE AP 88 E
58 438048 2.57 3.11
COIL AP 85 E VOLLST.
59 486780 47.67 57.68
Cable clamp RTK-S
60 431899 1.39 1.68
Oval head screw PT-3,5x16-KT15
61 228663 1.39 1.68
Motor frame SP 85/45 EB
62 637525 38.84 47.00
Enclosure CSP 85/45 EB
63 637528 8.11 9.81
Spacer AP 88 E
64 438509 1.45 1.75
MOTOR HOUSING C AP 88 E
66 438172 7.39 8.94
No information available, not orderable
67 488601
Viewing Window AP 88 E
68 438198 2.45 2.96
Oval head screw PS 2 E M3x 6,5
69 228718 1.39 1.68
MOLTOPRENE PLAT 30x15x8
71 410394 1.39 1.68
Oval head screw PT-4,0x25-KT15
72 228580 1.39 1.68
No information available, not orderable
73 xxx
Rotary knob Basis Plus D 40 M8 5+12T
74 483162 5.41 6.55
Cup square bolt DIN 603-M8x35-4.6
76 215007 1.39 1.68
Oval head screw PT-5,0x70-KT15
77 228709 1.39 1.68
No information available, not orderable
78 xxx
Ch. head screw M5x40-TAPTITE
79 203780 1.66 2.01
COVER AP 85 E
80 440010 5.02 6.07
Oval head screw PT-4,0x12-KT15
81 219071 1.39 1.68
Brush holder AXP 85
82 482182 17.30 20.93
BRUSH AP 85 EB
83 488920 17.54 21.22
Oval head screw PT-4.0x20-KT15
84 228567 1.39 1.68
Oval head screw PT-4,0x25-KT15
85 228580 1.39 1.68
No information available, not orderable
86 xxx
PIVOT FRAME AP 85 E
87 439892 52.76 63.84
SCREW M5x16 POWERLOK
88 228617 1.39 1.68
Grub screw DIN 915-M4x8-45H
89 229949 1.39 1.68
Square nut DIN 562-M4-11H
90 773030 1.39 1.68
Oval head screw DIN 7985-M4x10-8.8-PR30+
91 228733 1.39 1.68
No information available, not orderable
92 xxx
CLAMPING PIECE AP 85 E
93 439899 7.32 8.86
Cup square bolt DIN 603-M8x50-4.6
94 771800 1.39 1.68
Rotary knob Basis Plus D 40 M8 5+12T
95 483162 5.41 6.55
No longer available, no replacement
97 637735
Countersink PT-4,0x10-KT15
98 219102 1.39 1.68
Grub screw DIN 551-M6x12-14H
99 442597 1.39 1.68
GUIDE SUPPORT AT 65 E
100 443971 1.39 1.68
FS ADJUST AP 65 E
101 442809 1.45 1.75
CHIP DEFLECTOR AW-AP 55
102 439696 7.99 9.67
Oval head screw PT-5,0x18-KT15
103 228694 1.39 1.68
WASHER AP 85 E
104 440675 1.39 1.68
No information available, not orderable
105 xxx
SEAL AP 85 E
106 440690 5.63 6.81
Oval head screw PT-4,0x10-T15
107 228729 1.39 1.68
CABLE PROTECTOR AP 85 E
109 440691 12.83 15.52
Auxiliary handl CSP 85/45 EB
110 637534 10.43 12.62
Countersink PT-5,0x16-KT15
111 439494 1.39 1.68
Pin key AT 55 E SW 6
112 439274 3.77 4.56
Brush holder AP 85 EB
113 487464 17.54 21.22
