Here you will find all available parts and drawings of the 'Fein 71293400940 (AMM700MAX)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Fein 71293400940 (AMM700MAX)
Spare parts list of model Fein 71293400940 (AMM700MAX)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motor Housing | ||||
| 15 | 31901237030 | 44.66 | 54.04 | |
| Slide switch | ||||
| 30 | 32805324000 | 4.32 | 5.23 | |
| Air guide ring | ||||
| 70 | 31428193000 | 7.10 | 8.59 | |
| Speed setting switch | ||||
| 110 | 30762515990 | 144.19 | 174.47 | |
| Housing | ||||
| 120 | 31428192000 | 17.54 | 21.22 | |
| Pressure piece | ||||
| 125 | 31415181000 | 3.34 | 4.04 | |
| Pressure piece | ||||
| 155 | 31415110000 | 2.51 | 3.04 | |
| Pressure piece | ||||
| 160 | 31415160000 | 2.71 | 3.28 | |
| Bearing bush | ||||
| 225 | 31603052010 | 10.30 | 12.46 | |
| Rotor | ||||
| 250 | 33102009030 | 164.60 | 199.17 | |
| Grooved ball bearing | ||||
| 260 | 41701000012 | 6.41 | 7.76 | |
| Sealing ring | ||||
| 265 | 40612000005 | 1.56 | 1.89 | |
| Disc | ||||
| 275 | 42446008006 | 1.56 | 1.89 | |
| Sealing ring | ||||
| 290 | 40612000004 | 1.56 | 1.89 | |
| Needle bearing | ||||
| 300 | 41706000001 | 41.47 | 50.18 | |
| Stator | ||||
| 350 | 51113013940 | 76.56 | 92.64 | |
| Tool head | ||||
| 405 | 31508299030 | 202.88 | 245.48 | |
| Lever | ||||
| 430 | 34300000013 | 13.08 | 15.83 | |
| Circlip | ||||
| 465 | 42615110009 | 1.56 | 1.89 | |
| Eccentric ring | ||||
| 480 | 33218150000 | 3.34 | 4.04 | |
| Pin | ||||
| 490 | 40242043008 | 2.29 | 2.77 | |
| Bush | ||||
| 495 | 30507220000 | 2.51 | 3.04 | |
| Locking spring | ||||
| 510 | 30907069000 | 4.52 | 5.47 | |
| Fillister head screw | ||||
| 520 | 43064023045 | 1.56 | 1.89 | |
| Screw | ||||
| 530 | 43074000004 | 1.56 | 1.89 | |
| Screw (16 MM, 3.5 MM, TX15, EJOT) | ||||
| 535 | 43074010000 | 1.56 | 1.89 | |
| Pressure piece | ||||
| 685 | 31415171000 | 1.56 | 1.89 | |
| RFID Transponder | ||||
| 2500 | 32217517000 | 1.56 | 1.89 | |
| Case | ||||
| 5000 | 33901154630 | 58.08 | 70.28 | |
| Handle | ||||
| 5200 | 32119122000 | 7.66 | 9.27 | |
| Wire clamp | ||||
| 5210 | 30232050000 | 8.63 | 10.44 | |
| EPP insert | ||||
| 5300 | 33904570000 | 17.54 | 21.22 | |
| Battery pack (Akku-Pack, 18 V, 6 AH, LITHIUM-ION, | ||||
| 5500 | 92604175020 | 133.87 | 161.98 | |
| Battery pack (Akku-Pack, 18 V, 3 AH, LITHIUM-ION, | ||||
| 5500 | 92604182020 | 95.59 | 115.66 | |
| Charger (ALG 80_, EU, 12 V - 18 V, 8 A, FEIN) | ||||
| 5550 | 92604180010 | 75.13 | 90.91 | |
| No longer available, no replacement | ||||
| 6000 | 32160005000 | |||
| No information available, not orderable | ||||
| 6010 | 04010101004 | |||
| Extractor tool (SW0016, L 130 MM, M 12) | ||||
| 7016 | 64104150008 | 116.75 | 141.27 | |
| Extractor tool (SW0033, M 56 x 1.5 MM, ID 28.2 MM) | ||||
| 7033 | 64114038010 | 59.97 | 72.56 | |
| Assembly aid (SW0043, QUICKIN) | ||||
| 7043 | 64122122000 | 8.08 | 9.78 | |
| Press-in fixture (SW0047) | ||||
| 7047 | 64122127000 | 137.81 | 166.75 | |
| Chuck cone (SW0079, ID 16 MM) | ||||
| 7079 | 64107016001 | 103.36 | 125.07 | |
| Safety instruction | ||||
| 9020 | 34130054061 | 1.87 | 2.26 | |
