Here you will find all available parts and drawings of the 'Fein 71050200940 (ABOP10)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Fein 71050200940 (ABOP10)
Spare parts list of model Fein 71050200940 (ABOP10)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motor Housing | ||||
| 10 | 31912104020 | 39.56 | 47.87 | |
| Stop button | ||||
| 30 | 32816063000 | 3.34 | 4.04 | |
| Spiral spring | ||||
| 40 | 30901387000 | 1.56 | 1.89 | |
| Switch | ||||
| 50 | 30701318990 | 46.57 | 56.35 | |
| Air guide ring | ||||
| 70 | 31428172000 | 6.41 | 7.76 | |
| Grooved ball bearing | ||||
| 90 | 41701027250 | 7.10 | 8.59 | |
| Sealing ring | ||||
| 100 | 32612084001 | 3.13 | 3.79 | |
| Fan wheel | ||||
| 110 | 31004051000 | 7.38 | 8.93 | |
| MOTOR | ||||
| 115 | 54113010800 | 204.16 | 247.03 | |
| Plug | ||||
| 120 | 30703054000 | 5.36 | 6.49 | |
| Pin | ||||
| 353 | 40242051000 | 1.56 | 1.89 | |
| Intermediate gear box | ||||
| 355 | 31506378040 | 48.49 | 58.67 | |
| Grooved ball bearing | ||||
| 360 | 41701118160 | 5.57 | 6.74 | |
| Gearbox housing | ||||
| 375 | 31508267010 | 71.46 | 86.47 | |
| Circlip | ||||
| 380 | 42616047007 | 1.56 | 1.89 | |
| Gear-wheel | ||||
| 390 | 33663176010 | 30.30 | 36.66 | |
| Clutch ring | ||||
| 400 | 30103053000 | 13.08 | 15.83 | |
| Circlip | ||||
| 410 | 42644018007 | 2.29 | 2.77 | |
| Spring washer | ||||
| 420 | 42446023000 | 1.56 | 1.89 | |
| Disc | ||||
| 430 | 30109191000 | 5.77 | 6.98 | |
| Circlip | ||||
| 440 | 42616006007 | 1.87 | 2.26 | |
| Grooved ball bearing | ||||
| 450 | 41701010054 | 7.24 | 8.76 | |
| Shaft | ||||
| 460 | 33403116000 | 22.33 | 27.02 | |
| Roller | ||||
| 470 | 41709005007 | 1.56 | 1.89 | |
| Quick-action chuck | ||||
| 480 | 63205035010 | 96.80 | 117.13 | |
| Shaft, toothed | ||||
| 500 | 33763063000 | 22.33 | 27.02 | |
| Gear-wheel | ||||
| 510 | 33657172009 | 35.09 | 42.46 | |
| Disc | ||||
| 530 | 32408243007 | 2.09 | 2.53 | |
| Cover | ||||
| 850 | 30240284000 | 3.13 | 3.79 | |
| Screw (16 MM, 3.5 MM, TX15, EJOT) | ||||
| 950 | 43074010000 | 1.56 | 1.89 | |
| Screw | ||||
| 960 | 43072010009 | 1.56 | 1.89 | |
| Screw | ||||
| 970 | 43072003006 | 1.56 | 1.89 | |
| Handle | ||||
| 5000 | 32119123020 | 28.39 | 34.35 | |
| Case | ||||
| 5010 | 33901131080 | 67.54 | 81.72 | |
| Handle | ||||
| 5200 | 32119122000 | 7.66 | 9.27 | |
| Wire clamp | ||||
| 5210 | 30232050000 | 8.63 | 10.44 | |
| Case insert | ||||
| 5300 | 33904432000 | 27.43 | 33.19 | |
| No longer available, no replacement | ||||
| 6000 | 32160003014 | |||
| Extractor tool (SW0016, L 130 MM, M 12) | ||||
| 7016 | 64104150008 | 116.75 | 141.27 | |
| Chuck cone (SW0078, Ø 15 MM) | ||||
| 7078 | 64107015000 | 174.81 | 211.52 | |
| Chuck cone (SW0081, ID 19 MM, M 6) | ||||
| 7081 | 64107019007 | 96.98 | 117.35 | |
| Safety instruction | ||||
| 9020 | 34130054061 | 1.87 | 2.26 | |
