Here you will find all available parts and drawings of the 'Bosch 3600HB8300 ( UNIVERSALCHAIN35 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 3600HB8300 ( UNIVERSALCHAIN35 )
Spare parts list of model Bosch 3600HB8300 ( UNIVERSALCHAIN35 )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Housing | ||||
| 1 | 160580669U | 11.88 | 14.37 | |
| Motor Housing | ||||
| 2 | 16051082PW | 13.93 | 16.86 | |
| Switch | ||||
| 4 | 160720035H | 5.83 | 7.05 | |
| Power supply cord EU 0,4m 2 x 1,0mm H07 RN-F | ||||
| 5 | 2604460183 | 6.54 | 7.91 | |
| Grommet | ||||
| 6 | 2609005766 | 2.24 | 2.71 | |
| Suppression Filter | ||||
| 7 | 2609004394 | 5.83 | 7.05 | |
| Spring | ||||
| 13 | 2609001047 | 0.83 | 1.00 | |
| Torsion Spring | ||||
| 14 | 2609006397 | 1.18 | 1.43 | |
| Lever | ||||
| 15 | 1600A015GN | 0.83 | 1.00 | |
| Compression Spring | ||||
| 33 | 2609001048 | 0.83 | 1.00 | |
| Safety Switch | ||||
| 34 | 1600A0276D | 1.18 | 1.43 | |
| Compression Spring | ||||
| 35 | 160461202U | 0.83 | 1.00 | |
| Mounting Plate | ||||
| 36 | 1600A015D1 | 3.31 | 4.01 | |
| Sprocket wheel | ||||
| 37 | 1600A015D2 | 2.71 | 3.28 | |
| Spring retaining ring DIN 471-10x1MM-FSt | ||||
| 38 | 2916650001 | 1.94 | 2.35 | |
| Pipe | ||||
| 39 | 2609001086 | 1.18 | 1.43 | |
| Torx Oval-Head Screw 4x20 | ||||
| 40 | 2603490023 | 0.83 | 1.00 | |
| Pipe | ||||
| 42 | 1600A015DE | 1.18 | 1.43 | |
| Switch Segment | ||||
| 43 | 1600A0276E | 1.18 | 1.43 | |
| Sealing | ||||
| 46 | 1600A015DJ | 1.18 | 1.43 | |
| Handle | ||||
| 53 | 160513217Y | 4.70 | 5.69 | |
| Protective Shield | ||||
| 54 | 1600A015CX | 7.58 | 9.17 | |
| Oval-Head Screw | ||||
| 55 | 1600A01N9H | 0.83 | 1.00 | |
| Torx Oval-Head Screw | ||||
| 56 | 2609110080 | 1.18 | 1.43 | |
| Adjustment Knob | ||||
| 680 | 1600A028X6 | 12.10 | 14.64 | |
| Reservoir Cap | ||||
| 683 | 1600A027C7 | 1.70 | 2.06 | |
| Chain Guard | ||||
| 687 | 1600A01B1L | 4.10 | 4.96 | |
| Saw Chain AKE 35 | ||||
| 689 | 2609007364 | 20.42 | 24.71 | |
| Guide Rail 350 mm | ||||
| 690 | 1600A015H6 | 20.42 | 24.71 | |
| Motor | ||||
| 803 | 1607000DW1 | 40.61 | 49.14 | |
| Nameplate | ||||
| 808 | 160111A99Y | 1.94 | 2.35 | |
| Pump | ||||
| 811 | 1607000DW5 | 8.45 | 10.22 | |
| Container | ||||
| 816 | 1607000DW4 | 8.45 | 10.22 | |
| Clutch | ||||
| 818 | 1607000DW2 | 20.42 | 24.71 | |
| Linkage | ||||
| 829 | 1607000DW3 | 10.73 | 12.98 | |
| Adjustment Device | ||||
| 881 | 1607000F4C | 8.45 | 10.22 | |
