Here you will find all available parts and drawings of the 'Bosch 0601102915 ( UB2J75UB2/75 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Bosch 0601102915 ( UB2J75UB2/75 )

Spare parts list of model Bosch 0601102915 ( UB2J75UB2/75 )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
No longer available, no replacement
1 3605108094
Brush Holder
2 1604336005 15.71 19.01
No longer available, no replacement
3 1604652001
Field 220-230V
4 1604220082 60.65 73.39
Terminal lug 1,5-4x4
4/20 1901350003 0.83 1.00
Air-Deflector Ring
5 1600209002 3.31 4.01
Armature 220-240V
7 1609991109 168.86 204.32
Sealing cap BLUE
12 3605500057 0.83 1.00
No longer available, no replacement
13 3605133012
Insulating Plate 20x20x50 MM
13/2 1602381006 1.18 1.43
Tapping Screw DIN 7971-B 3,9x19
13/3 2910211220 1.18 1.43
Switch
15 1607200037 40.61 49.14
Switch
15 1607200078 36.85 44.59
Power supply cord AUS 2,65m 2 x 1,0mm PVC
16 1604460032 11.88 14.37
Grommet Ø9,2-Ø12x120 MM
17 3600703011 2.24 2.71
Bearing cover
18 1600501019 18.19 22.01
No longer available, no replacement
19/20 1607328012
Ball Bearing 7x19x6
20 2600905032 4.10 4.96
No longer available, no replacement
21 1602381001
Terminal lug 1,5-4x4
21/2 1901350003 0.83 1.00
groove ball bearing 17x35x10
22 1600900001 18.19 22.01
Intermediate Bearing
23 3605820033 101.94 123.35
Manufacturer's nameplate
25 1601110004 0.83 1.00
Felt Disc
26 1600108003 0.83 1.00
O-Ring 74,0x3,0 MM
27 1600210006 1.18 1.43
Fastening Clamp
28 1601302014 1.18 1.43
Intermediate Ring
29 1600502011 1.94 2.35
Tapping Screw DIN 7971-ST3,9x16-F
30 2910211019 0.83 1.00
Socket head cap screw DIN 84-AM5x12-8.8
31 2910021154 0.83 1.00
Tapping Screw B4,8x90 MM
33 1603435006 1.18 1.43
Socket head cap screw DIN 84-AM4x15-8.8
35 2910021125 0.83 1.00
Socket head cap screw DIN 84-AM4x15-8.8
36 2910021125 0.83 1.00
Socket head cap screw DIN 84-AM4x8-8.8
37 2910021118 0.83 1.00
Socket head cap screw DIN 84-AM4x6-8.8
38 2910021116 1.70 2.06
Spring Washer DIN 137-A4
39 1600150006 5.33 6.45
Plain Washer A 4,3 DIN 125-ST
46 2916010410 0.83 1.00
No longer available, no replacement
60 1605806186
groove ball bearing 15x32x8
61 1900900201 23.75 28.74
Spacer Bushing
62 1600300026 6.54 7.91
groove ball bearing 15x35x11
63 1900900303 18.19 22.01
Spacer Bushing
64 1600300027 3.31 4.01
Drilling Spindle
65 1603124039 36.85 44.59
Retaining snap ring
66 3607030355 13.93 16.86
Shim 0,5 MM THICK
67 1600102003 1.18 1.43
Sealing disk
68 1600108000 1.18 1.43
Straight Toothed Gear Z=50
69 1606317045 44.82 54.23
Adjusting bolt
70 1603104005 44.82 54.23
Shim 0,2 MM THICK
71 1420100620 1.18 1.43
Control Lever
72 1602026026 8.45 10.22
Socket head cap screw M3,5x5,5 MM
73 1603413005 2.24 2.71
Control Lever
74 1602120006 5.33 6.45
No longer available, no replacement
75 1606328048
Spindle With Gear Z=12
76 1606309036 91.56 110.79
No longer available, no replacement
77 1606328058
Rotary shaft lip seal
78 1600283003 3.31 4.01
Shim 0,5 MM THICK
79 1600100631 1.18 1.43
Socket head cap screw DIN 84-AM4x12-8.8
80 2910021122 1.70 2.06
Spring Lock Washer DIN 127-B3,5
82 2916680004 1.70 2.06
Spring retaining ring DIN 472 35x1,5 MM
83 2916660014 1.18 1.43
Straight Toothed Gear Z=35
84 1606317043 60.65 73.39
Cylindrical Gear Z=33
85 1606320041 36.85 44.59
Reference Plate
86 1601110153 0.83 1.00
Reference Plate DOUBLE INSULATION
87 1601110058 1.18 1.43
Reference Plate
88 1601110076 0.83 1.00
No longer available, no replacement
89 2601110041
Auxiliary Handle
650 160202509Z 12.41 15.02
Auxiliary Handle
650 16020250A1 11.88 14.37
No information available, not orderable
651 1608571027
No longer available, no replacement
811 1607014101
Nameplate
888 160111A3H3 1.94 2.35
