Here you will find all available parts and drawings of the 'Bosch 0601190025 (S500A)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0601190025 (S500A)
Spare parts list of model Bosch 0601190025 (S500A)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Base Plate | ||||
| 1 | 1609203H47 | 304.15 | 368.02 | |
| Lifting Eye Bolt | ||||
| 2 | 1609203663 | 5.27 | 6.38 | |
| Threaded Insert | ||||
| 3 | 1609203664 | 6.53 | 7.90 | |
| Hex Socket Head Cap Screw | ||||
| 4 | 2910141244 | 1.49 | 1.80 | |
| Headed Bush | ||||
| 5 | 1609203666 | 10.68 | 12.92 | |
| Handle | ||||
| 6 | 1609203667 | 26.62 | 32.21 | |
| Position Pickup | ||||
| 7 | 1609203H44 | 12.21 | 14.77 | |
| Nameplate | ||||
| 8 | 1601106902 | 0.83 | 1.00 | |
| Support | ||||
| 10 | 1609203670 | 17.60 | 21.30 | |
| Support | ||||
| 11 | 1609203671 | 17.60 | 21.30 | |
| Clamping Piece | ||||
| 12 | 1609203672 | 13.90 | 16.82 | |
| Clamping Lever | ||||
| 14 | 1609203674 | 11.02 | 13.33 | |
| Serrated Lock-Washer | ||||
| 16 | 1609203676 | 1.32 | 1.60 | |
| Hex Socket Head Cap Screw | ||||
| 17 | 1609203677 | 1.32 | 1.60 | |
| Hex Screw | ||||
| 18 | 1609203678 | 3.71 | 4.49 | |
| Parallel Key | ||||
| 19 | 1609203679 | 11.02 | 13.33 | |
| Hex Socket Head Cap Screw | ||||
| 20 | 1609203680 | 1.32 | 1.60 | |
| Square Nut | ||||
| 21 | 1609203681 | 1.32 | 1.60 | |
| Set screw | ||||
| 22 | 1609203682 | 1.32 | 1.60 | |
| Hex Nut | ||||
| 23 | 1609203683 | 1.32 | 1.60 | |
| Handle | ||||
| 24 | 1609203684 | 3.04 | 3.68 | |
| Socket head cap screw DIN 84ZN-M4x25 | ||||
| 25 | 1609203685 | 1.32 | 1.60 | |
| Clamping Lever | ||||
| 26 | 1609203686 | 50.23 | 60.78 | |
| Round-Head Bolt | ||||
| 27 | 1609203687 | 2.18 | 2.64 | |
| Column | ||||
| 28 | 1609203E31 | 383.36 | 463.87 | |
| Tapping Screw | ||||
| 29 | 1609203689 | 1.32 | 1.60 | |
| Strap-Shaped Handle | ||||
| 30 | 1609203690 | 8.48 | 10.26 | |
| Guide Block | ||||
| 31 | 1609203E32 | 340.97 | 412.57 | |
| Adjusting Screw | ||||
| 32 | 1609203692 | 22.88 | 27.68 | |
| Guide Component | ||||
| 33 | 1609203693 | 3.04 | 3.68 | |
| Set screw | ||||
| 34 | 1609203694 | 1.32 | 1.60 | |
| Protective Glass | ||||
| 35 | 1609203695 | 55.56 | 67.23 | |
| Clamping Piece | ||||
| 36 | 1609203H45 | 50.23 | 60.78 | |
| Clamping Lever | ||||
| 37 | 1609203697 | 17.60 | 21.30 | |
| Hex Socket Head Cap Screw | ||||
| 41 | 1609203702 | 15.61 | 18.89 | |
| Rotary Cross 3-POLE | ||||
| 44 | 1609203H33 | 146.07 | 176.74 | |
| Locking Bolt | ||||
| 45 | 1609203706 | 26.62 | 32.21 | |
| Toothed Shaft | ||||
| 46 | 1609203707 | 26.62 | 32.21 | |
| Spirit Level | ||||
| 47 | 1609203708 | 1.00 | 1.21 | |
| Plain Washer | ||||
| 48 | 2916011016 | 1.00 | 1.21 | |
| Spring retaining ring | ||||
| 50 | 1609203711 | 8.48 | 10.26 | |
| Main Bearing | ||||
| 51 | 1609203712 | 5.96 | 7.21 | |
| Box Level | ||||
| 52 | 1609203713 | 5.96 | 7.21 | |
| Detent Pin | ||||
| 53 | 1609203777 | 55.25 | 66.85 | |
| Clamping Piece | ||||
| 55 | 1609203H46 | 17.60 | 21.30 | |
| Support bracket | ||||
| 59 | 1609203E33 | 33.33 | 40.33 | |
| Support bracket | ||||
| 60 | 1609203E34 | 33.33 | 40.33 | |
| Straight Pin DIN6325 6x20 | ||||
| 61 | 2917860149 | 2.18 | 2.64 | |
| Knurled Thumbscrew | ||||
| 62 | 2912502201 | 7.32 | 8.86 | |
| Transport Reel | ||||
| 90 | 1609203F74 | 262.05 | 317.08 | |
| Support | ||||
| 90/10 | 1609203N96 | 102.63 | 124.18 | |
| Support | ||||
| 90/20 | 1609203N97 | 102.63 | 124.18 | |
| Plain Washer | ||||
| 90/30 | 1609203P27 | 1.32 | 1.60 | |
| Plain Washer | ||||
| 90/31 | 1609203N98 | 8.48 | 10.26 | |
| Hex Screw | ||||
| 90/40 | 1609203P26 | 2.18 | 2.64 | |
| Axle | ||||
| 90/50 | 1609203N99 | 41.30 | 49.97 | |
| O-Ring | ||||
| 90/60 | 1609203P08 | 2.18 | 2.64 | |
| Toothed Ring | ||||
| 90/70 | 1609203P28 | 1.90 | 2.30 | |
| Wheel | ||||
| 90/80 | 1609203P07 | 26.62 | 32.21 | |
| Spring retaining ring | ||||
| 90/90 | 1609203P00 | 4.10 | 4.96 | |
| No information available, not orderable | ||||
| 704 | 2608598111 | |||
| No longer available, no replacement | ||||
| 705 | 2607000744 | |||
| No longer available, no replacement | ||||
| 705/1 | 2607000746 | |||
| No longer available, no replacement | ||||
| 706 | 2607000745 | |||
| No longer available, no replacement | ||||
| 706/1 | 2607000747 | |||
| No longer available, no replacement | ||||
| 707 | 0601191003 | |||
| No information available, not orderable | ||||
| 708 | 2609390314 | |||
| Fitting | ||||
| 708/1 | 2609390377 | 495.00 | 598.95 | |
| Hose fitting 1/4" | ||||
| 708/11 | 2609390359 | 8.45 | 10.22 | |
| Sealing disk | ||||
| 708/12 | 2609390360 | 1.94 | 2.35 | |
| Sealing Cone | ||||
| 708/13 | 2609390361 | 15.71 | 19.01 | |
| O-Ring 7x2,72 MM | ||||
| 708/14 | 2609390362 | 5.27 | 6.38 | |
| Compression Spring | ||||
| 708/15 | 2609390363 | 3.71 | 4.49 | |
| Pressure gauge | ||||
| 708/16 | 2609390364 | 29.75 | 36.00 | |
| Push-Button | ||||
| 708/17 | 2609390365 | 26.84 | 32.48 | |
| Locking Washer DIN 6799-4-FST | ||||
| 708/18 | 2916089057 | 0.83 | 1.00 | |
| Rotary Handle | ||||
| 708/19 | 2609390366 | 26.62 | 32.21 | |
| Flexible Connection | ||||
| 708/2 | 2609390378 | 67.98 | 82.26 | |
| Compression Spring | ||||
| 708/21 | 2609390367 | 8.45 | 10.22 | |
| Bleeder Plug | ||||
| 708/22 | 2609390368 | 29.75 | 36.00 | |
| Base Body | ||||
| 708/23 | 2609390369 | 168.86 | 204.32 | |
| Coiled Spring Pin DIN-EN/28750-4x16 | ||||
| 708/24 | 2917800097 | 1.00 | 1.21 | |
| Lock Bolt | ||||
| 708/25 | 2609390370 | 37.50 | 45.38 | |
| Retaining Pin | ||||
| 708/26 | 2609390371 | 20.39 | 24.67 | |
| Seal Ring | ||||
| 708/27 | 2609390372 | 10.68 | 12.92 | |
| Hose | ||||
| 708/28 | 2609390373 | 40.61 | 49.14 | |
| Insert Nipple 1/4" | ||||
| 708/29 | 2609390374 | 5.96 | 7.21 | |
| Seal Ring | ||||
| 708/3 | 2609390376 | 26.62 | 32.21 | |
| Hose Clamper | ||||
| 708/30 | 2609390375 | 2.71 | 3.28 | |
| Clamping Lever | ||||
| 814 | 1609203674 | 11.02 | 13.33 | |
| Hex Screw | ||||
| 815 | 1609203675 | 2.18 | 2.64 | |
| Water collection ring | ||||
| 880 | 1609203F70 | 233.78 | 282.87 | |
| Seal Carrier | ||||
| 881 | 1609203F71 | 81.47 | 98.58 | |
| Sealing Cover | ||||
| 882 | 1609203F72 | 41.30 | 49.97 | |
| Holding Device | ||||
| 884 | 1609203E41 | 146.07 | 176.74 | |
| Seal Ring | ||||
| 888 | 1609203E40 | 67.98 | 82.26 | |
