Here you will find all available parts and drawings of the 'Bosch 3600H81F50 (ROTAK37LI)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 3600H81F50 (ROTAK37LI)
Spare parts list of model Bosch 3600H81F50 (ROTAK37LI)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Screw | ||||
| 32 | F016L66162 | 1.00 | 1.21 | |
| Mower deck | ||||
| 40 | F016L66158 | 33.33 | 40.33 | |
| Housing | ||||
| 41 | F016L66003 | 37.50 | 45.38 | |
| Cover Panel | ||||
| 42 | F016L66039 | 2.40 | 2.90 | |
| Motor Hood | ||||
| 43 | F016L66780 | 73.72 | 89.20 | |
| Battery Tray | ||||
| 43/1 | F016L65952 | 33.33 | 40.33 | |
| No longer available, no replacement | ||||
| 43/10 | F016L66108 | |||
| Battery Cover | ||||
| 43/2 | F016L65954 | 10.68 | 12.92 | |
| Motor Hood | ||||
| 43/3 | F016L65953 | 18.19 | 22.01 | |
| No longer available, no replacement | ||||
| 43/6 | F016L66669 | |||
| Release Lever | ||||
| 43/8 | F016L66107 | 2.18 | 2.64 | |
| Locking Device | ||||
| 43/9 | F016L65988 | 1.00 | 1.21 | |
| Axle | ||||
| 52/01 | F016L65929 | 4.70 | 5.69 | |
| No longer available, no replacement | ||||
| 52/02 | F016L90582 | |||
| No longer available, no replacement | ||||
| 52/03 | F016L90583 | |||
| Cutter Blade | ||||
| 55 | F016L66005 | 30.08 | 36.40 | |
| Adapter | ||||
| 58 | F016L66115 | 2.18 | 2.64 | |
| Bolt M10x30 | ||||
| 59 | F016L66141 | 2.18 | 2.64 | |
| Axle | ||||
| 61/01 | F016L65928 | 2.52 | 3.05 | |
| Lever | ||||
| 61/02 | F016L90581 | 6.73 | 8.14 | |
| Spacer | ||||
| 61/03 | F016L90585 | 1.49 | 1.80 | |
| Ratchet Cap | ||||
| 64 | F016F05700 | 1.00 | 1.21 | |
| Handle | ||||
| 75/01 | F016L66182 | 33.33 | 40.33 | |
| Push-Button | ||||
| 75/10 | F016F05705 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 75/11 | F016L66240 | |||
| Self-Cutting Screw | ||||
| 75/14 | F016T49429 | 1.00 | 1.21 | |
| Cable Clip | ||||
| 75/27 | F016L90575 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 75/4 | F016L65739 | |||
| Switch Housing | ||||
| 75/5 | F016L66235 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 75/6 | F016T49630 | |||
| Switch Kit | ||||
| 75/7 | F016104163 | 13.13 | 15.89 | |
| No longer available, no replacement | ||||
| 75/8 | F016L66416 | |||
| Collector Box Bottom BLACK | ||||
| 80 | F016L65674 | 43.12 | 52.18 | |
| Guard Flap | ||||
| 82 | F016L66137 | 10.90 | 13.19 | |
| Handle | ||||
| 83/84 | F016F05683 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 85 | F016L66165 | |||
| Spring | ||||
| 99 | F016L59327 | 2.86 | 3.46 | |
| Spring | ||||
| 100 | F016L65790 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 101 | F016L67260 | |||
| Restrictor | ||||
| 102 | F016L66111 | 2.52 | 3.05 | |
| Roller Drum | ||||
| 150 | F016L65871 | 10.90 | 13.19 | |
| No longer available, no replacement | ||||
| 151 | F016L64900 | |||
| No longer available, no replacement | ||||
| 152 | F016L64901 | |||
| Spindle | ||||
| 153 | F016L65869 | 6.73 | 8.14 | |
| Company Logo ROTAK 37 LI | ||||
| 452 | F016L66286 | 3.04 | 3.68 | |
| Spring Washer 1/2" | ||||
| 503 | F016L66173 | 1.32 | 1.60 | |
| No longer available, no replacement | ||||
| 505 | F016L65803 | |||
| No longer available, no replacement | ||||
| 506/1 | F016L59277 | |||
| Wing Nut | ||||
| 506/2 | F016L66136 | 4.18 | 5.06 | |
| Battery Pack GBA 36V 4,0Ah H-C | ||||
| 650 | 1607A350R2 | 262.05 | 317.08 | |
| Fast Charger J GAL 3680 CV 100/14,4-36V | ||||
| 651 | 2607225909 | 126.98 | 153.65 | |
| No longer available, no replacement | ||||
| 801 | F016104248 | |||
| Cover | ||||
| 841/1 | F016104316 | 6.53 | 7.90 | |
| No longer available, no replacement | ||||
| 843/5 | F016104244 | |||
| No longer available, no replacement | ||||
| 850 | F016103992 | |||
| No longer available, no replacement | ||||
| 860 | F016103994 | |||
| No longer available, no replacement | ||||
| 875/03 | F016103675 | |||
| No longer available, no replacement | ||||
| 875/18 | F016103601 | |||
| No longer available, no replacement | ||||
| 878 | F016L65571 | |||
| Cover | ||||
| 883 | F016103608 | 27.81 | 33.65 | |
