Here you will find all available parts and drawings of the 'Bosch 3600H85B05 ( ROTAK32R )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 3600H85B05 ( ROTAK32R )
Spare parts list of model Bosch 3600H85B05 ( ROTAK32R )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Support Element | ||||
| 41 | F016L67976 | 0.83 | 1.00 | |
| Comb RED | ||||
| 42 | F016L66697 | 1.18 | 1.43 | |
| Carrying Handle | ||||
| 45 | F016L66654 | 2.24 | 2.71 | |
| Axle | ||||
| 52 | F016L66849 | 5.83 | 7.05 | |
| Cutter Blade | ||||
| 55 | 1600A025F8 | 10.73 | 12.98 | |
| Hex Screw M8x20 MM | ||||
| 59 | F016T48547 | 1.94 | 2.35 | |
| Axle | ||||
| 61 | F016L66848 | 5.83 | 7.05 | |
| Handle | ||||
| 75/1 | F016L62792 | 20.42 | 24.71 | |
| Self-Cutting Screw 4x19 MM | ||||
| 75/14 | F016T49429 | 0.83 | 1.00 | |
| Switch Housing | ||||
| 75/4/1 | F016L66234 | 1.94 | 2.35 | |
| Clamping Piece | ||||
| 75/4/11 | F016L66236 | 0.83 | 1.00 | |
| Switch Housing | ||||
| 75/4/2 | F016L66235 | 1.94 | 2.35 | |
| Positioning Lever | ||||
| 75/4/3 | F016L66238 | 2.71 | 3.28 | |
| Compression Spring | ||||
| 75/4/4 | F016L66240 | 0.83 | 1.00 | |
| Push-Button | ||||
| 75/4/5 | F016F05705 | 0.83 | 1.00 | |
| No longer available, no replacement | ||||
| 75/4/806 | F016L66416 | |||
| Power supply cord EU | ||||
| 75/4/808 | F016104086 | 12.41 | 15.02 | |
| No longer available, no replacement | ||||
| 75/4/809 | F016104088 | |||
| On-Off Switch | ||||
| 75/4/810 | F016F05717 | 11.88 | 14.37 | |
| Handle Bar BLACK | ||||
| 78 | F016L66682 | 6.54 | 7.91 | |
| Handle Bar BLACK | ||||
| 79 | F016L66655 | 6.54 | 7.91 | |
| Collector Box Bottom | ||||
| 80 | F016L66683 | 11.88 | 14.37 | |
| Guard Flap | ||||
| 82 | F016L66686 | 3.31 | 4.01 | |
| Carrying Handle | ||||
| 84 | F016L66685 | 2.24 | 2.71 | |
| closing spring | ||||
| 85 | F016L66687 | 1.18 | 1.43 | |
| Spring | ||||
| 90 | F016L65773 | 1.18 | 1.43 | |
| Drive Belt | ||||
| 92 | F016L66677 | 8.45 | 10.22 | |
| Drive Belt | ||||
| 92 | 1600A02K8R | 7.58 | 9.17 | |
| Thermal protector | ||||
| 93 | F016L66958 | 6.54 | 7.91 | |
| Belt Tensioner | ||||
| 96 | F016L68711 | 4.70 | 5.69 | |
| Baffle | ||||
| 98 | F016L66688 | 4.10 | 4.96 | |
| Balance Weights | ||||
| 99 | F016L66698 | 6.54 | 7.91 | |
| Bearing cover | ||||
| 108 | F016L66689 | 1.18 | 1.43 | |
| Roller | ||||
| 150 | F016L66853 | 6.54 | 7.91 | |
| Roller Carrier L/H | ||||
| 151 | F016L66855 | 1.70 | 2.06 | |
| Roller Carrier R/H | ||||
| 152 | F016L66856 | 1.70 | 2.06 | |
| Spindle | ||||
| 153 | F016L66854 | 4.70 | 5.69 | |
| Company Logo ROTAK 32 R ALT | ||||
| 452 | F016L67239 | 2.71 | 3.28 | |
| Company Logo ROTAK 32 R NEU | ||||
| 452 | 1600A0233R | 1.94 | 2.35 | |
| Plain Washer Ø8,15 MM | ||||
| 501 | F016T40590 | 1.18 | 1.43 | |
| Screw | ||||
| 502 | F016L68323 | 0.83 | 1.00 | |
| Securing Cap Ø8 MM BLACK | ||||
| 503 | F016T48990 | 0.83 | 1.00 | |
| Self-Cutting Screw 4x19 MM | ||||
| 504 | F016T49429 | 0.83 | 1.00 | |
| Motor | ||||
| 801 | F016104035 | 91.56 | 110.79 | |
| Cap | ||||
| 801/1/18 | F016L64499 | 0.83 | 1.00 | |
| Screw M5x8 Csk Hd. | ||||
| 805 | F016L36542 | 1.94 | 2.35 | |
| Wing Nut | ||||
| 806 | F016L66155 | 1.70 | 2.06 | |
| Mower deck | ||||
| 840 | F016104246 | 26.84 | 32.48 | |
| Bearing 6002-2RS | ||||
| 840/1/2 | F016L67442 | 2.71 | 3.28 | |
| Motor Hood | ||||
| 843 | F016104033 | 15.71 | 19.01 | |
| Collector Box Top | ||||
| 883 | F016104032 | 18.19 | 22.01 | |
| Wheel | ||||
| 887 | 1600A00J3Y | 5.83 | 7.05 | |
| Drive Shaft | ||||
| 891 | 1600A02AZ3 | 12.18 | 14.74 | |
| Cable Clip ROTAK II | ||||
| 895 | F016L66895 | 0.83 | 1.00 | |
