Here you will find all available parts and drawings of the 'Bosch 0603403803 ( PWS7-125 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0603403803 ( PWS7-125 )
Spare parts list of model Bosch 0603403803 ( PWS7-125 )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Housing Section | ||||
| 1 | 1605108203 | 15.71 | 19.01 | |
| Power supply cord CN 2,65m 2 x 0,75mm H05 W-F | ||||
| 5 | 1607000387 | 8.45 | 10.22 | |
| Grommet Ø6,5-Ø6,9x95 MM | ||||
| 6 | 2600703012 | 2.24 | 2.71 | |
| Manufacturer's nameplate | ||||
| 9 | 1601118856 | 2.71 | 3.28 | |
| Compression Spring | ||||
| 18 | 1604611026 | 0.83 | 1.00 | |
| No longer available, no replacement | ||||
| 22 | 1602319014 | |||
| Switch Handle BLACK | ||||
| 23 | 1602026077 | 1.18 | 1.43 | |
| Rubber Bushing | ||||
| 26 | 1600502020 | 1.94 | 2.35 | |
| No longer available, no replacement | ||||
| 28 | 1600905021 | |||
| Crown Gear | ||||
| 31 | 1606333624 | 8.45 | 10.22 | |
| Thread-forming tap. Screw DIN 7500, M4x10, SR10.2 | ||||
| 49 | 1603435068 | 1.18 | 1.43 | |
| Torx Oval-Head Screw 4x20 | ||||
| 50 | 1619P00105 | 1.18 | 1.43 | |
| Intermediate Plate | ||||
| 105 | 1600591034 | 1.94 | 2.35 | |
| No longer available, no replacement | ||||
| 652 | 1605510307 | |||
| Protective Cover | ||||
| 801 | 1600A025XP | 7.58 | 9.17 | |
| Pin-Type Face-Wrench | ||||
| 802 | 1607950052 | 2.71 | 3.28 | |
| Clamping Flange Ø22,3xØ42 MM | ||||
| 803 | 2605703014 | 4.10 | 4.96 | |
| O-Ring 20,35x1,78 MM | ||||
| 804 | 1600210039 | 1.70 | 2.06 | |
| Round Nut M14 | ||||
| 805 | 1603345043 | 6.54 | 7.91 | |
| No longer available, no replacement | ||||
| 806 | 1607000994 | |||
| Nameplate | ||||
| 808 | 160111A3H3 | 1.94 | 2.35 | |
| Field 230-240V | ||||
| 811 | 1607000723 | 26.84 | 32.48 | |
| No longer available, no replacement | ||||
| 821 | 1607000995 | |||
| No longer available, no replacement | ||||
| 830 | 1607000990 | |||
| No longer available, no replacement | ||||
| 832 | 1607000719 | |||
| Auxiliary Handle | ||||
| 891 | 1602025031 | 13.11 | 15.86 | |
| Protective Cover | ||||
| 891/1 | 1600A025XP | 7.58 | 9.17 | |
