Here you will find all available parts and drawings of the 'Bosch 0603278483 (PWS6-115)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0603278483 (PWS6-115)
Spare parts list of model Bosch 0603278483 (PWS6-115)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| No longer available, no replacement | ||||
| 1 | 1605108127 | |||
| Field | ||||
| 2 | 1604220325 | 21.30 | 25.77 | |
| Fan | ||||
| 3/50 | 1606610121 | 1.49 | 1.80 | |
| On-Off Switch | ||||
| 4 | 1607200086 | 10.90 | 13.19 | |
| Pan head screw | ||||
| 4/10 | 2910110048 | 1.00 | 1.21 | |
| Grommet | ||||
| 6 | 2600703011 | 2.86 | 3.46 | |
| Grommet | ||||
| 6 | 2600703012 | 2.86 | 3.46 | |
| Grommet | ||||
| 6 | 2600703013 | 2.40 | 2.90 | |
| Fastening Clamp | ||||
| 7 | 1601302017 | 1.00 | 1.21 | |
| Manufacturer's nameplate | ||||
| 9 | 1601118174 | 4.18 | 5.06 | |
| No longer available, no replacement | ||||
| 12 | 1607328029 | |||
| Ball Bearing | ||||
| 13 | 2600905032 | 4.94 | 5.98 | |
| groove ball bearing | ||||
| 14 | 1600905032 | 5.81 | 7.03 | |
| Manufacturer's nameplate | ||||
| 17 | 1601118154 | 1.49 | 1.80 | |
| Compression Spring | ||||
| 18 | 1619P09932 | 1.28 | 1.55 | |
| Compression Spring | ||||
| 18 | 1604611026 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 21 | 1605806429 | |||
| Adjusting Slide | ||||
| 22 | 1602319002 | 2.40 | 2.90 | |
| Switch Handle | ||||
| 23 | 1602026057 | 1.49 | 1.80 | |
| Housing Cover | ||||
| 25 | 1600508005 | 2.86 | 3.46 | |
| Rubber Bushing | ||||
| 26 | 1600502020 | 2.40 | 2.90 | |
| Rubber Ring | ||||
| 27 | 1600206025 | 2.08 | 2.52 | |
| No longer available, no replacement | ||||
| 28 | 1605805061 | |||
| Air-Deflector Ring | ||||
| 29 | 1601328005 | 2.40 | 2.90 | |
| Grinding Spindle | ||||
| 32 | 1607000D6A | 7.46 | 9.03 | |
| Shim | ||||
| 35 | 1600136010 | 2.40 | 2.90 | |
| Shim | ||||
| 35 | 1600136011 | 2.08 | 2.52 | |
| Shim | ||||
| 35 | 1600136012 | 1.00 | 1.21 | |
| Spring Washer | ||||
| 36 | 1600150011 | 1.00 | 1.21 | |
| Crown Gear | ||||
| 38 | 1606333606 | 10.90 | 13.19 | |
| Spiral Spring | ||||
| 39 | 1604652013 | 1.49 | 1.80 | |
| Spring retaining ring | ||||
| 40 | 2916660009 | 2.08 | 2.52 | |
| Needle bearing | ||||
| 41 | 1600910018 | 4.94 | 5.98 | |
| Bevel Gear | ||||
| 43 | 1606333605 | 3.44 | 4.16 | |
| Hex Nut | ||||
| 45 | 1603300016 | 1.49 | 1.80 | |
| Hex Nut | ||||
| 45 | 1619P17544 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 47 | 2910211018 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 48 | 2910211005 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 49 | 2912401420 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 50 | 2912401420 | 1.00 | 1.21 | |
| Connecting Cable | ||||
| 53 | 1604448015 | 1.00 | 1.21 | |
| Connecting Cable | ||||
| 54 | 1604448016 | 1.49 | 1.80 | |
| Tapping Screw | ||||
| 55 | 2912401420 | 1.00 | 1.21 | |
| Round Nut | ||||
| 650/20 | 1603345043 | 8.35 | 10.10 | |
| Pin-Type Face-Wrench | ||||
| 650/30 | 1607950052 | 3.44 | 4.16 | |
| Clamping Flange | ||||
| 650/40 | 2605703014 | 7.53 | 9.11 | |
| O-Ring | ||||
| 650/40/20 | 1600210039 | 2.08 | 2.52 | |
| No longer available, no replacement | ||||
| 650/50 | 2607950511 | |||
| Protective Cover | ||||
| 651/10 | 1600A025XP | 9.67 | 11.70 | |
| Auxiliary Handle | ||||
| 651/10 | 160202509T | 3.44 | 4.16 | |
| No longer available, no replacement | ||||
| 652 | 1600A0136P | |||
| Hex Socket Head Cap Screw | ||||
| 652/20 | 2910141197 | 1.44 | 1.74 | |
| Armature With Fan | ||||
| 803 | 1604010615 | 43.12 | 52.18 | |
| No longer available, no replacement | ||||
| 805 | 1603460163 | |||
| Nameplate | ||||
| 808 | 160111A3H3 | 2.40 | 2.90 | |
| Carbon-Brush Set | ||||
| 810 | 1607014116 | 10.90 | 13.19 | |
| Brush Holder | ||||
| 816 | 1600A003G4 | 3.44 | 4.16 | |
| No longer available, no replacement | ||||
| 838 | 1607000943 | |||
| SNELSPANMOER | ||||
| 896 | 1603340027 | 45.52 | 55.08 | |
| Fast Locking Flange | ||||
| 896 | 1600A016PP | 41.30 | 49.97 | |
