Here you will find all available parts and drawings of the 'Bosch 0603933003 ( PBM7,2VS-2 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0603933003 ( PBM7,2VS-2 )
Spare parts list of model Bosch 0603933003 ( PBM7,2VS-2 )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| On-Off Switch | ||||
| 4 | 2607200317 | 20.42 | 24.71 | |
| Manufacturer's nameplate SUNNY SIDE | ||||
| 9 | 2601118326 | 3.31 | 4.01 | |
| Reference Plate SHADOW SIDE | ||||
| 20 | 2601118327 | 3.31 | 4.01 | |
| groove ball bearing | ||||
| 27 | 1900905127 | 22.36 | 27.06 | |
| Adapter | ||||
| 28 | 2605719006 | 1.18 | 1.43 | |
| Insert Piece BLACK | ||||
| 29 | 2605510147 | 2.24 | 2.71 | |
| No longer available, no replacement | ||||
| 32 | 2601099032 | |||
| Cylindrical Gear Z=58/67 | ||||
| 42 | 1609340007 | 11.88 | 14.37 | |
| Pinion Z=14 | ||||
| 47 | 2606316142 | 2.71 | 3.28 | |
| Sticker RECHARGABLE BATERY | ||||
| 51 | 2601118320 | 3.31 | 4.01 | |
| Sintered-Metal Bushing | ||||
| 94 | 2600301011 | 1.18 | 1.43 | |
| Sintered-Metal Bushing | ||||
| 95 | 2600302002 | 1.18 | 1.43 | |
| Rubber-Inter Calation | ||||
| 96 | 2600290022 | 2.24 | 2.71 | |
| Clamp Spring | ||||
| 100 | 2601322016 | 1.70 | 2.06 | |
| Screw 4x16 | ||||
| 101 | 2603490022 | 0.83 | 1.00 | |
| Retaining Bracket | ||||
| 102 | 2601329041 | 1.18 | 1.43 | |
| Connecting Cable L=79 MM WHITE | ||||
| 103 | 2604413004 | 1.18 | 1.43 | |
| No longer available, no replacement | ||||
| 108 | 2601010038 | |||
| Keyless Chuck | ||||
| 725 | 2608572214 | 40.61 | 49.14 | |
| No information available, not orderable | ||||
| 725/800 | 1607950053 | |||
| Slide-In Accu Package 7,2V,1,5Ah,NiCd | ||||
| 730 | 2607336141 | 55.25 | 66.85 | |
| Fast Charger EU 230/7,2-24V, 1h | ||||
| 760 | 2607224425 | 130.32 | 157.69 | |
| Fast Charger EU 230/7,2-14,4V, 30 MIN. | ||||
| 760 | 2607224701 | 101.94 | 123.35 | |
| Screwdriver Blade 6 MM | ||||
| 765 | 1609200147 | 2.71 | 3.28 | |
| No longer available, no replacement | ||||
| 797 | 2601398009 | |||
| Housing Section GREEN | ||||
| 801 | 2605104859 | 10.73 | 12.98 | |
| DC motor 7,2V | ||||
| 802 | 2607022911 | 20.42 | 24.71 | |
| Drilling Spindle 3/8" | ||||
| 826 | 2606135917 | 15.71 | 19.01 | |
| Toothed Shaft Z=10/19/81 | ||||
| 840 | 1609340005 | 12.41 | 15.02 | |
