Here you will find all available parts and drawings of the 'Bosch 0603302703 (PBH200RKE)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0603302703 (PBH200RKE)
Spare parts list of model Bosch 0603302703 (PBH200RKE)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| No longer available, no replacement | ||||
| 1 | 1615104002 | |||
| Field | ||||
| 2 | 2604220515 | 21.30 | 25.77 | |
| Fan | ||||
| 3/60 | 2606610022 | 3.71 | 4.49 | |
| No longer available, no replacement | ||||
| 4 | 2607200209 | |||
| Grommet | ||||
| 6 | 2600707061 | 2.86 | 3.46 | |
| Cable Clip | ||||
| 7 | 1611035005 | 2.08 | 2.52 | |
| Manufacturer's nameplate | ||||
| 9 | 1611110623 | 2.87 | 3.47 | |
| Manufacturer's nameplate | ||||
| 11 | 1611110625 | 3.48 | 4.21 | |
| No longer available, no replacement | ||||
| 12 | 1607328040 | |||
| groove ball bearing | ||||
| 13 | 1610905032 | 4.94 | 5.98 | |
| Reference Plate | ||||
| 16 | 1611110624 | 0.83 | 1.00 | |
| Guide Sleeve | ||||
| 17 | 1615819013 | 7.46 | 9.03 | |
| No longer available, no replacement | ||||
| 18 | 1615700027 | |||
| Drive bearing | ||||
| 20 | 1615819012 | 31.42 | 38.02 | |
| Protective Grille | ||||
| 24 | 1612388019 | 1.49 | 1.80 | |
| Toothed Shaft | ||||
| 25 | 1613160008 | 18.94 | 22.92 | |
| Cylindrical Gear | ||||
| 26 | 1616317600 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 27 | 1616317034 | |||
| No longer available, no replacement | ||||
| 28 | 1611015034 | |||
| No longer available, no replacement | ||||
| 29 | 1611015035 | |||
| Pressure Lever | ||||
| 31 | 1611329009 | 2.86 | 3.46 | |
| Piston Pin | ||||
| 33 | 1613103006 | 2.86 | 3.46 | |
| Shim washer | ||||
| 34 | 1610100608 | 1.49 | 1.80 | |
| Supporting Disc | ||||
| 36 | 1610102024 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 39 | 1610508020 | |||
| No longer available, no replacement | ||||
| 40 | 1611015033 | |||
| Holding Plate | ||||
| 43 | 1611031005 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 44 | 1614634002 | |||
| Compression Spring | ||||
| 45 | 1614610005 | 1.49 | 1.80 | |
| Retaining snap ring | ||||
| 46 | 1610200014 | 1.49 | 1.80 | |
| Needle-Roller Assembly | ||||
| 47 | 1610913008 | 4.18 | 5.06 | |
| Needle bearing | ||||
| 48 | 1610910071 | 6.73 | 8.14 | |
| Needle-Roller Bearing | ||||
| 49 | 2600917003 | 2.86 | 3.46 | |
| Roller-Cage Assembly | ||||
| 50 | 1610920002 | 3.44 | 4.16 | |
| Support Disc | ||||
| 51 | 1610102617 | 2.08 | 2.52 | |
| Thrust Needle Rim | ||||
| 52 | 1610920005 | 2.86 | 3.46 | |
| Support Disc | ||||
| 53 | 1610100602 | 1.49 | 1.80 | |
| Shim | ||||
| 54 | 1610100604 | 1.49 | 1.80 | |
| Shim | ||||
| 54 | 1610100606 | 1.49 | 1.80 | |
| Shim | ||||
| 54 | 1610100607 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 55 | 2604448096 | |||
| Connecting Cable | ||||
| 56 | 1614448014 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 57 | 1607328040 | |||
| Connecting Cable | ||||
| 58 | 2604448034 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 59 | 2604448060 | |||
| No longer available, no replacement | ||||
| 60 | 1610210086 | |||
| O-Ring | ||||
| 61 | 1610210046 | 2.08 | 2.52 | |
| No longer available, no replacement | ||||
| 64 | 1614601007 | |||
| Damping rubber | ||||
| 66 | 1610026001 | 1.00 | 1.21 | |
| Straight Pin | ||||
| 68 | 2917550133 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 70 | 2912401022 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 72 | 2912401019 | 1.00 | 1.21 | |
| Socket head cap screw | ||||
| 73 | 2603410001 | 1.49 | 1.80 | |
| Shaft Seal | ||||
| 75 | 1610283019 | 7.46 | 9.03 | |
| Roller-Cage Assembly | ||||
| 78 | 1610920006 | 2.86 | 3.46 | |
| Support Disc | ||||
| 79 | 1610100609 | 1.49 | 1.80 | |
| Overload Clutch | ||||
| 81 | 1616409006 | 15.26 | 18.46 | |
| Straight Pin | ||||
| 82 | 1613100019 | 1.49 | 1.80 | |
| Chuck Wrench | ||||
| 85/7 | 2607950007 | 6.73 | 8.14 | |
| Retaining ring | ||||
| 87 | 1614601010 | 1.24 | 1.50 | |
| Hex Nut | ||||
| 120/20 | 2915011007 | 1.00 | 1.21 | |
| Wing Screw | ||||
| 120/30 | 1613480007 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 120/50 | 2608040014 | |||
| Wing Screw | ||||
| 120/60 | 1613480008 | 1.49 | 1.80 | |
| Manufacturer's nameplate | ||||
| 125 | 1611110345 | 2.38 | 2.88 | |
| No longer available, no replacement | ||||
| 702 | 1617000133 | |||
| Retaining ring | ||||
| 702/10/2 | 2604601004 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 703 | 1615439003 | |||
| Rubber Bushing | ||||
| 703/30 | 1610312001 | 1.00 | 1.21 | |
| Rubber Bushing | ||||
| 703/651 | 1610312002 | 1.00 | 1.21 | |
| Auxiliary Handle | ||||
| 720 | 1619PB4323 | 9.67 | 11.70 | |
| No longer available, no replacement | ||||
| 750 | 2605438290 | |||
| No longer available, no replacement | ||||
| 752 | 1613001005 | |||
| Rotary hammer bit | ||||
| 753 | 1618596166 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 754 | 2607000122 | |||
| No longer available, no replacement | ||||
| 803 | 1614010076 | |||
| Power supply cord | ||||
| 805 | 1607000227 | 23.90 | 28.92 | |
| Nameplate | ||||
| 808 | 160111A3H3 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 810 | 2609992600 | |||
| No longer available, no replacement | ||||
| 810/04 | 1617014117 | |||
| Compression Spring | ||||
| 810/05 | 2604611026 | 1.49 | 1.80 | |
| Ratchet Cap | ||||
| 810/06 | 2601322013 | 1.49 | 1.80 | |
| groove ball bearing | ||||
| 814 | 1610905048 | 8.35 | 10.10 | |
| Parts Set | ||||
| 819 | 1617000964 | 248.72 | 300.95 | |
| Hammer Piston | ||||
| 821 | 1617000175 | 21.73 | 26.29 | |
| No longer available, no replacement | ||||
| 830 | 1617000177 | |||
| Change-Over Switch | ||||
| 877 | 2607200231 | 14.94 | 18.08 | |
| Parts Set | ||||
| 885 | 1617000959 | 179.65 | 217.38 | |
