Here you will find all available parts and drawings of the 'Bosch 0603376868 (PBH160RE)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0603376868 (PBH160RE)
Spare parts list of model Bosch 0603376868 (PBH160RE)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Field | ||||
| 2 | 2604220515 | 21.30 | 25.77 | |
| Fan | ||||
| 3/50 | 2606610022 | 3.71 | 4.49 | |
| No longer available, no replacement | ||||
| 4 | 1607200172 | |||
| Grommet | ||||
| 6 | 2600703018 | 2.40 | 2.90 | |
| Cable Clip | ||||
| 7 | 2601035001 | 1.49 | 1.80 | |
| Manufacturer's nameplate | ||||
| 9 | 1611110Y41 | 2.71 | 3.28 | |
| No longer available, no replacement | ||||
| 10 | 2605807060 | |||
| Reference Plate | ||||
| 11 | 1611110Y42 | 2.71 | 3.28 | |
| No longer available, no replacement | ||||
| 12 | 1607328040 | |||
| groove ball bearing | ||||
| 13 | 1610905032 | 4.94 | 5.98 | |
| Damping rubber | ||||
| 15 | 1610026001 | 1.00 | 1.21 | |
| Catch Disk | ||||
| 20 | 1616409012 | 4.94 | 5.98 | |
| Cylindrical Gear | ||||
| 22 | 1616317608 | 6.73 | 8.14 | |
| Striker | ||||
| 27 | 1618710068 | 6.73 | 8.14 | |
| No longer available, no replacement | ||||
| 30 | 1611911000 | |||
| Compression Spring | ||||
| 32 | 1614617002 | 0.83 | 1.00 | |
| Compression Spring | ||||
| 33 | 1614634008 | 1.00 | 1.21 | |
| Bearing Pin | ||||
| 34 | 1613100021 | 1.00 | 1.21 | |
| Supporting Disc | ||||
| 36 | 1610190021 | 2.08 | 2.52 | |
| Protective Cap | ||||
| 39 | 1610508021 | 1.00 | 1.21 | |
| Supporting Disc | ||||
| 43 | 1610190020 | 1.00 | 1.21 | |
| Straight Pin | ||||
| 46 | 1613160022 | 1.00 | 1.21 | |
| Needle bearing | ||||
| 53 | 1610910077 | 4.18 | 5.06 | |
| No longer available, no replacement | ||||
| 55 | 1610920012 | |||
| No longer available, no replacement | ||||
| 56 | 1610102030 | |||
| Roller Thrust Bearing | ||||
| 57 | 1610920009 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 60 | 1610280006 | |||
| O-Ring | ||||
| 62 | 1610210125 | 1.00 | 1.21 | |
| Ball | ||||
| 63 | 1903230013 | 2.08 | 2.52 | |
| No longer available, no replacement | ||||
| 65 | 1614601018 | |||
| Spring retaining ring | ||||
| 67 | 1614601077 | 1.49 | 1.80 | |
| Shim washer | ||||
| 72 | 1610100007 | 1.00 | 1.21 | |
| Contact Spring | ||||
| 73 | 1614682004 | 2.00 | 2.42 | |
| No longer available, no replacement | ||||
| 74 | 1611015040 | |||
| Sealing Frame | ||||
| 75 | 1611015041 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 76 | 1611015042 | |||
| Connecting Cable | ||||
| 86 | 2604448147 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 87 | 2604448096 | |||
| Connecting Cable | ||||
| 88 | 2604448034 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 89 | 2604448060 | |||
| Tapping Screw | ||||
| 92 | 2912401021 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 93 | 2912401019 | 1.00 | 1.21 | |
| Torx Oval-Head Screw | ||||
| 94 | 2603490017 | 2.08 | 2.52 | |
| Socket head cap screw | ||||
| 95 | 2603410001 | 1.49 | 1.80 | |
| Auxiliary Handle | ||||
| 651 | 2602025125 | 9.67 | 11.70 | |
| No longer available, no replacement | ||||
| 652 | 2609005615 | |||
| Housing Section | ||||
| 801 | 1617000575 | 31.65 | 38.30 | |
| No longer available, no replacement | ||||
| 803 | 1614010144 | |||
| Power supply cord | ||||
| 805 | 3607030489 | 31.42 | 38.02 | |
| End Splice | ||||
| 806 | 1900452012 | 1.49 | 1.80 | |
| Nameplate | ||||
| 808 | 160111A3H5 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 810/040 | 1617014136 | |||
| Ratchet Cap | ||||
| 810/060 | 2601322017 | 1.49 | 1.80 | |
| groove ball bearing | ||||
| 814 | 1610905048 | 8.35 | 10.10 | |
| Change-Over Switch | ||||
| 816 | 2607200231 | 14.94 | 18.08 | |
| Hammer Pipe | ||||
| 821 | 1617000320 | 31.42 | 38.02 | |
| No longer available, no replacement | ||||
| 821/01 | 1617000349 | |||
| Jack Shaft | ||||
| 824 | 1617000301 | 47.53 | 57.51 | |
| No longer available, no replacement | ||||
| 841 | 1617000303 | |||
| No longer available, no replacement | ||||
| 844 | 1617000576 | |||
| Bushing | ||||
| 850 | 1617000975 | 5.81 | 7.03 | |
| Straight Pin | ||||
| 864 | 1613100019 | 1.49 | 1.80 | |
