Here you will find all available parts and drawings of the 'Bosch 0603232103 ( P80/P80K )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Bosch 0603232103 ( P80/P80K )

Spare parts list of model Bosch 0603232103 ( P80/P80K )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
No longer available, no replacement
1 2605104927
No longer available, no replacement
2 2604010516
No longer available, no replacement
3 1604220071
No longer available, no replacement
4 1605500066
No longer available, no replacement
5 1607200060
No longer available, no replacement
6 2607329099
No longer available, no replacement
7 2604460255
Grommet Ø6,4-Ø7,5x75 MM
8 1600703016 0.83 1.00
Grommet Ø8,2 MM
8 2600703008 0.83 1.00
Fastening Clamp
9 1601302014 1.18 1.43
Tapping Screw DIN 7971-BZ3,9x6,5
10 2910211016 0.83 1.00
No longer available, no replacement
11 2910211017
No longer available, no replacement
12 1600301900
No longer available, no replacement
13 1600205023
No longer available, no replacement
14 1610210014
Spiral Spring
15 1604652004 1.94 2.35
No longer available, no replacement
16 1601034025
Brush Holder
18 1601323007 1.18 1.43
Tapping Screw DIN 7972-BZ2,9x6,5
19 2910601004 0.83 1.00
Ball Bearing 8x22x7
21 1900905029 15.71 19.01
Tapping Screw DIN 7981-ST3,9x16-C-H
22 2910611019 2.24 2.71
Felt Strip
23 1601005003 0.83 1.00
No longer available, no replacement
24 2606320020
Bearing bolt
26 2603103009 8.45 10.22
Shim washer
28 2600200003 0.83 1.00
Spring retaining ring 30x1,2MM, DIN 472
29 2916660012 1.18 1.43
groove ball bearing
30 2600900003 0.83 1.00
Component
31 2600005003 0.83 1.00
Felt Disc
32 2600005001 1.18 1.43
Socket head cap screw DIN 84-AM5x12-8.8
33 2910021154 0.83 1.00
Spring Lock Washer DIN 128-A5-FST
34 2916690004 1.18 1.43
Plain Washer 5-ST
35 2916021011 0.83 1.00
Felt Strip
37 2601005003 0.83 1.00
Socket head cap screw DIN 84-AM4x15-8.8
41 2910021125 0.83 1.00
Spring Lock Washer DIN 128-A4-FST
42 2916690003 0.83 1.00
Plain Washer DIN 125-A4,3-ST
43 2916011010 0.83 1.00
Nameplate
44 2601105051 1.18 1.43
Manufacturer's nameplate
45 1601110013 1.18 1.43
Reference Plate
46 2601110024 0.83 1.00
Component
51 2600113008 0.83 1.00
Hex Nut DIN 934-M6-8-A
53 2915011007 0.83 1.00
No longer available, no replacement
60 2603527007
Shim 0,3 MM
61 2600101654 1.18 1.43
Component 0,2 MM
61 2600101651 0.83 1.00
No longer available, no replacement
78 2608635074
Torx Oval-Head Screw 3x10
85 2603490017 1.70 2.06
Socket head cap screw M3x6,5-4.8
86 2603410001 1.18 1.43
Sticker
87 2601110022 0.83 1.00
Component
88 2601010023 0.83 1.00
Pan head screw M 4x20 MM
89 2603410016 1.18 1.43
No longer available, no replacement
92 1602381001
Guide
97 2601000033 5.83 7.05
Supporting Disc
98 2600100027 1.18 1.43
Socket head cap screw DIN 84-AM4x15-8.8
99 2910021125 0.83 1.00
Hex Nut DIN 985-M4-8
100 2915061002 0.83 1.00
Plain Washer DIN 125-A 6,4-ST
101 2916011014 0.83 1.00
No longer available, no replacement
102 2916690005
No longer available, no replacement
103 2910011201
No longer available, no replacement
652 2602025004
No longer available, no replacement
700 1605411023
No information available, not orderable
800 0603299003
No information available, not orderable
801 0603907203
No longer available, no replacement
817 1604321900
