Here you will find all available parts and drawings of the 'Bosch 3600HB0800 ( INDEGOS+500 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 3600HB0800 ( INDEGOS+500 )
Spare parts list of model Bosch 3600HB0800 ( INDEGOS+500 )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Chassis Unterseite | ||||
| 1/1 | F016L90902 | 15.71 | 19.01 | |
| Cover GREEN | ||||
| 1/10 | F016L91310 | 5.83 | 7.05 | |
| Pivoting Blade Guard | ||||
| 1/12 | F016L90965 | 8.45 | 10.22 | |
| Sticker Bosch Logo | ||||
| 1/16 | F016L91256 | 6.54 | 7.91 | |
| Chassis | ||||
| 1/2 | F016L91276 | 29.75 | 36.00 | |
| Motor Housing | ||||
| 1/23 | F016L90907 | 4.10 | 4.96 | |
| Control Magnet | ||||
| 1/25 | F016L69389 | 2.24 | 2.71 | |
| Screw M4x20 PLASTIC | ||||
| 1/28 | F016L67706 | 0.83 | 1.00 | |
| Cover BLACK | ||||
| 1/3 | F016L91251 | 18.19 | 22.01 | |
| Weight | ||||
| 1/30 | F016L90740 | 13.93 | 16.86 | |
| Push Button | ||||
| 1/32 | F016L68978 | 2.71 | 3.28 | |
| Compression Spring | ||||
| 1/33 | F016L69569 | 1.18 | 1.43 | |
| Locking Lever | ||||
| 1/35 | F016L68980 | 1.18 | 1.43 | |
| Wiring Harness | ||||
| 1/38 | F016L69388 | 8.45 | 10.22 | |
| Compression Spring | ||||
| 1/4 | F016L68899 | 1.70 | 2.06 | |
| Screw and washer assembly | ||||
| 1/41 | F016L67951 | 1.94 | 2.35 | |
| Wire Harness assembly | ||||
| 1/43 | F016L69220 | 20.42 | 24.71 | |
| Data coupler | ||||
| 1/44 | F016L69178 | 15.71 | 19.01 | |
| profile gasket | ||||
| 1/45 | F016L69106 | 7.58 | 9.17 | |
| Battery Pack PBA 18V 2,5Ah W-B 45Wh | ||||
| 1/47 | 1607A350RU | 73.72 | 89.20 | |
| Wiring Harness | ||||
| 1/49 | 1600A02WX3 | 18.19 | 22.01 | |
| Cover GREEN | ||||
| 1/5 | F016L91252 | 11.88 | 14.37 | |
| Control Magnet | ||||
| 1/50 | F016L69405 | 1.94 | 2.35 | |
| Fastening Screw | ||||
| 1/52 | F016L67864 | 0.83 | 1.00 | |
| No longer available, no replacement | ||||
| 1/53 | F016L91313 | |||
| Wiring Harness | ||||
| 1/56 | F016L69247 | 15.71 | 19.01 | |
| Push Button | ||||
| 1/57 | F016L68981 | 1.94 | 2.35 | |
| Breather | ||||
| 1/58 | F016L69597 | 5.33 | 6.45 | |
| Screw Cap | ||||
| 1/60 | F016L69179 | 1.18 | 1.43 | |
| profile gasket | ||||
| 1/61 | F016L69180 | 3.31 | 4.01 | |
| Battery Holder | ||||
| 1/70 | F016L90903 | 2.24 | 2.71 | |
| Wiring Harness | ||||
| 1/72 | F016L90963 | 18.19 | 22.01 | |
| Drive Motor | ||||
| 1/807 | F016105558 | 197.04 | 238.42 | |
| Nameplate | ||||
| 1/808 | 160111AB4X | 0.83 | 1.00 | |
| Motor assembly | ||||
| 1/813 | F016105557 | 101.94 | 123.35 | |
| Blade Holder | ||||
| 1/817 | F016104903 | 18.19 | 22.01 | |
| Blade | ||||
| 1/818 | F016104255 | 22.36 | 27.06 | |
| Motor cover | ||||
| 1/821 | F016105503 | 13.93 | 16.86 | |
| Caster Wheel | ||||
| 1/824 | 1607000EE5 | 26.84 | 32.48 | |
| Caster Wheel | ||||
| 1/824/806 | 1607000EE4 | 15.00 | 18.15 | |
| Socket | ||||
| 1/826 | F016104899 | 5.33 | 6.45 | |
| Drive Wheel NEU | ||||
| 1/827 | 1607000EC4 | 23.75 | 28.74 | |
| Printed-Board Assembly | ||||
| 1/848 | 1600A02DD4 | 113.29 | 137.08 | |
| Printed Circuit Board | ||||
| 1/854 | F016104894 | 81.47 | 98.58 | |
| Cover | ||||
| 1/871 | F016105639 | 13.11 | 15.86 | |
| Seal Housing Ring | ||||
| 1/9 | F016L68966 | 1.18 | 1.43 | |
| Baseplate complete | ||||
| 2/1 | F016L90756 | 36.85 | 44.59 | |
| Printed-Board Assembly | ||||
| 2/805 | 1600A02545 | 176.66 | 213.76 | |
| Connector | ||||
| 10/39/5 | F016L68737 | 5.83 | 7.05 | |
| Power supply unit CH | ||||
| 10/5 | F016L90934 | 130.32 | 157.69 | |
| Power supply unit UK | ||||
| 10/805 | F016L69437 | 91.56 | 110.79 | |
| Power supply unit EU | ||||
| 10/805 | F016L69170 | 67.25 | 81.37 | |
| Cover Plate | ||||
| 10/9 | F016L69193 | 5.33 | 6.45 | |
