Here you will find all available parts and drawings of the 'Bosch 0601345603 ( GWS9-150C )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Bosch 0601345603 ( GWS9-150C )

Spare parts list of model Bosch 0601345603 ( GWS9-150C )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Motor Housing
1 16051082CC 11.65 14.10
Field
2 1604220220 37.50 45.38
Fan
3/50 1606610121 1.49 1.80
On-Off Switch
4 1607200086 10.90 13.19
Pan head screw
4/10 2910110048 1.00 1.21
Grommet
6 2600703013 2.40 2.90
Fastening Clamp
7 1601302017 1.00 1.21
Manufacturer's nameplate
9 1601110610 2.38 2.88
No longer available, no replacement
12 1607328029
Ball Bearing
13 2600905032 4.94 5.98
No longer available, no replacement
14 2600905052
Manufacturer's nameplate
17 1601110777 2.38 2.88
Compression Spring
18 1619P09932 1.28 1.55
Compression Spring
18 1604611026 1.00 1.21
Adjusting Slide
22 1602319002 2.40 2.90
Switch Handle
23 1602026057 1.49 1.80
Housing Cover
25 1600508010 6.53 7.90
Rubber Bushing
26 1600502020 2.40 2.90
Rubber Ring
27 1600206025 2.08 2.52
Air-Deflector Ring
29 1601328005 2.40 2.90
Retaining clip
31 2916660013 2.08 2.52
Grinding Spindle
32 1607000D6A 7.46 9.03
O-Ring
33 3600210124 2.86 3.46
Shim
35 1600136010 2.40 2.90
Shim
35 1600136011 2.08 2.52
Shim
35 1600136012 1.00 1.21
Spring Washer
36 1600150011 1.00 1.21
Rotary shaft lip seal
37 1600290016 2.40 2.90
Crown Gear
38 1606333235 67.98 82.26
Spiral Spring
39 1604652013 1.49 1.80
Spring retaining ring
40 2916660009 2.08 2.52
Needle bearing
41 1600910018 4.94 5.98
groove ball bearing
42 1600905006 11.37 13.76
Bevel Gear
43 1606333234 37.50 45.38
Hex Nut
45 1603300016 1.49 1.80
Hex Nut
45 1619P17544 1.00 1.21
Tapping Screw
47 2910211018 1.00 1.21
Tapping Screw
48 2910211005 1.00 1.21
Thread-forming tap. Screw
49 1603435026 1.90 2.30
Tapping Screw
50 2910211021 1.49 1.80
Speed governor
51 1607233008 26.62 32.21
Connecting Cable
53 1604448005 2.86 3.46
Connecting Cable
54 1604448006 2.40 2.90
Tapping Screw
55 2912401021 1.00 1.21
Reference Plate
100 1601110310 2.40 2.90
Reference Plate
105 1601110470 1.00 1.21
O-Ring
107 1600210044 1.00 1.21
Protective Cover
650/10 1600A025XP 8.48 10.26
Auxiliary Handle
650/10 160202509T 3.44 4.16
Round Nut
650/20 1603345043 8.35 10.10
Pin-Type Face-Wrench
650/30 1607950052 3.44 4.16
Clamping Flange
650/50 2605703014 7.53 9.11
O-Ring
650/50/20 1600210039 2.08 2.52
Offset Screwdriver
650/60 1907950006 3.71 4.49
Hexagon Socket Screw Key
650/60 2610364015 3.44 4.16
No longer available, no replacement
652 2605510127
Hex Socket Head Cap Screw
652/20 2910141197 1.20 1.45
No longer available, no replacement
803 1604010248
Power supply cord
805 1607000227 23.90 28.92
Nameplate
808 160111A3H3 2.40 2.90
Carbon-Brush Set
810 1607014116 10.90 13.19
Push-Button
813 1607000253 2.08 2.52
Brush Holder
816 1600A003G4 3.44 4.16
Gear Housing
821 1605806480 52.45 63.46
Bearing Flange
828 1607000936 27.81 33.65
SNELSPANMOER
896 1603340027 45.52 55.08
Fast Locking Flange
896 1600A016PP 41.30 49.97
