Here you will find all available parts and drawings of the 'Bosch 3601HC7300 (GWS27-230JR)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 3601HC7300 (GWS27-230JR)
Spare parts list of model Bosch 3601HC7300 (GWS27-230JR)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motor Housing | ||||
| 1 | 1619P15457 | 13.13 | 15.89 | |
| Field | ||||
| 2 | 1619P17831 | 47.53 | 57.51 | |
| Power supply cord EU 4,15m 2 x 1,5mm H07 RN-F | ||||
| 5 | 1604460126 | 16.79 | 20.32 | |
| Grommet | ||||
| 6 | 1619P14369 | 1.49 | 1.80 | |
| Fastening Clamp | ||||
| 7 | 1601302018 | 1.49 | 1.80 | |
| groove ball bearing | ||||
| 13 | 1600905011 | 5.81 | 7.03 | |
| groove ball bearing | ||||
| 14 | 1600905028 | 12.09 | 14.63 | |
| Handle | ||||
| 24 | 1619P17065 | 9.67 | 11.70 | |
| O-Ring | ||||
| 28 | 1600210033 | 1.49 | 1.80 | |
| O-Ring | ||||
| 29 | 1600210045 | 1.49 | 1.80 | |
| Air Distributor | ||||
| 30 | 1619P15274 | 2.86 | 3.46 | |
| Air-Deflector Ring | ||||
| 31 | 1619P17066 | 2.40 | 2.90 | |
| Retaining snap ring | ||||
| 32 | 1600290019 | 1.49 | 1.80 | |
| Rotary shaft lip seal | ||||
| 33 | 1600290013 | 2.40 | 2.90 | |
| Shim | ||||
| 34 | 1600190021 | 2.40 | 2.90 | |
| Shim | ||||
| 34 | 1600190022 | 1.49 | 1.80 | |
| Shim | ||||
| 34 | 1600190020 | 1.49 | 1.80 | |
| Shim | ||||
| 34 | 1600190037 | 1.00 | 1.21 | |
| Shim | ||||
| 34 | 1600190038 | 1.00 | 1.21 | |
| Shim | ||||
| 34 | 1600190039 | 1.00 | 1.21 | |
| Shim | ||||
| 34 | 1600190040 | 1.00 | 1.21 | |
| Felt Washer | ||||
| 35 | 1600205034 | 1.49 | 1.80 | |
| Seal Ring | ||||
| 37 | 1600290036 | 2.08 | 2.52 | |
| Rubber Ring | ||||
| 38 | 1600206020 | 1.49 | 1.80 | |
| Rubber Ring | ||||
| 39 | 1600206030 | 1.49 | 1.80 | |
| Compression Spring | ||||
| 41 | 1604611032 | 1.49 | 1.80 | |
| Hex Nut | ||||
| 45 | 1603300019 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 50 | 1619P17064 | |||
| Needle-Roller Bearing | ||||
| 51 | 2600910001 | 4.18 | 5.06 | |
| Thread-forming tap. Screw | ||||
| 60 | 1603435023 | 2.08 | 2.52 | |
| Tapping Screw | ||||
| 61 | 2912401038 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 62 | 1603435060 | 1.49 | 1.80 | |
| Pan head screw | ||||
| 63 | 1603410014 | 1.49 | 1.80 | |
| Plastic-Cutting Screw | ||||
| 64 | 1603435042 | 1.49 | 1.80 | |
| Tapping Screw | ||||
| 65 | 2912401020 | 1.90 | 2.30 | |
| Tapping Screw | ||||
| 66 | 2910211019 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 67 | 1603435024 | 1.49 | 1.80 | |
| Sealing Plate | ||||
| 68 | 1601006011 | 2.40 | 2.90 | |
| Spring retaining ring | ||||
| 69 | 2916650905 | 1.00 | 1.21 | |
| Damper | ||||
| 75 | 1619P17360 | 7.46 | 9.03 | |
| Collar Screw | ||||
| 76 | 1619P17837 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 80 | 16072335R9 | |||
| Magnet | ||||
| 81 | 1616B10375 | 1.49 | 1.80 | |
| Ferrite | ||||
| 90 | 1619P14161 | 1.00 | 1.21 | |
| Button | ||||
| 101 | 1619P17357 | 1.49 | 1.80 | |
| Cap | ||||
| 102 | 1619P17355 | 2.86 | 3.46 | |
| Protective Cover | ||||
| 651 | 1600A01R96 | 39.14 | 47.36 | |
| Armature | ||||
| 803 | 1619P18630 | 52.45 | 63.46 | |
| Switch | ||||
| 804 | 1619P18632 | 13.13 | 15.89 | |
| Label | ||||
| 808 | 1619P18640 | 2.40 | 2.90 | |
| Carbon-Brush Set | ||||
| 810 | 1607014171 | 12.82 | 15.51 | |
| Brush Holder | ||||
| 816 | 1604336048 | 6.53 | 7.90 | |
| Gear Housing | ||||
| 821 | 1619P15750 | 34.82 | 42.13 | |
| Bearing Flange Ø230 MM | ||||
| 822 | 1619P17221 | 34.82 | 42.13 | |
| Bearing Flange | ||||
| 822 | 1619PS8649 | 18.94 | 22.92 | |
| Sealing cap | ||||
| 823 | 1619P15945 | 2.86 | 3.46 | |
| Grinding Spindle | ||||
| 825 | 1619P15297 | 7.46 | 9.03 | |
| Bevel Gear Set | ||||
| 826 | 1619P15388 | 23.90 | 28.92 | |
| Fan | ||||
| 835 | 1606610142 | 5.05 | 6.11 | |
| Fan | ||||
| 835 | 1600A00J93 | 2.86 | 3.46 | |
| Push-Button | ||||
| 840 | 1619P15752 | 3.44 | 4.16 | |
| Retaining Washer | ||||
| 846 | 1607000342 | 3.44 | 4.16 | |
| O-Ring | ||||
| 890 | 1600210039 | 2.08 | 2.52 | |
| Auxiliary Handle | ||||
| 891 | 16020250A1 | 13.13 | 15.89 | |
| Auxiliary Handle | ||||
| 891 | 1619P09013 | 7.58 | 9.17 | |
| Auxiliary Handle | ||||
| 891/1 | 160202509Z | 14.94 | 18.08 | |
| Pin-Type Face-Wrench | ||||
| 892 | 1607950061 | 4.18 | 5.06 | |
| Pin-Type Face-Wrench | ||||
| 892 | F000632033 | 2.40 | 2.90 | |
| Clamping Flange | ||||
| 893 | 2605703014 | 7.53 | 9.11 | |
| Round Nut | ||||
| 894 | 1603345043 | 8.35 | 10.10 | |
| Fast Locking Flange | ||||
| 896 | 1600A016PP | 41.30 | 49.97 | |
| Grease Tube | ||||
| 897 | 1605430003 | 34.82 | 42.13 | |
| Grease Tube | ||||
| 898 | 1615430020 | 18.94 | 22.92 | |
