Here you will find all available parts and drawings of the 'Bosch 0601856B03 ( GWS26-230BV )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Bosch 0601856B03 ( GWS26-230BV )

Spare parts list of model Bosch 0601856B03 ( GWS26-230BV )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Motor Housing BLUE
1 1605108239 11.88 14.37
Field
2 160422051P 40.61 49.14
Grommet Ø 10,5-Ø11,0x100 MM
6 1600703023 1.94 2.35
Fastening Clamp
7 1601302018 1.18 1.43
Manufacturer's nameplate
9 1601118G03 2.71 3.28
groove ball bearing
14 1600905028 9.53 11.53
Sealing cap
23 1605500206 2.80 3.39
No longer available, no replacement
24 1605132130
Grinding Spindle
25 160312305U 10.73 12.98
O-Ring 79,0x1,78 MM
28 1600210033 1.18 1.43
O-Ring 8,0x1,0 MM
29 1600210045 1.18 1.43
Air Distributor
30 1600591029 1.94 2.35
Air-Deflector Ring
31 1600591075 1.94 2.35
Retaining snap ring
32 1600290019 1.18 1.43
Shim 0,3 MM THICK
34 1600190021 1.94 2.35
Shim 0,1 MM THICK
34 1600190022 1.18 1.43
Shim 0,15 MM THICK
34 1600190020 1.18 1.43
Shim 0,2 MM THICK
34 1600190037 0.83 1.00
Shim 0,25 MM THICK
34 1600190038 0.83 1.00
Shim 0,35 MM THICK
34 1600190039 0.83 1.00
Shim 0,4 MM THICK
34 1600190040 0.83 1.00
Felt Washer
35 1600205034 1.18 1.43
Seal Ring BLACK
37 1600290036 1.70 2.06
Rubber Ring 7 MM WIDE
38 1600206020 1.18 1.43
Rubber Ring
39 1600206030 1.18 1.43
Hex Nut M10, SW14
45 1603300019 1.18 1.43
Plain bearing Ø14 MM
51 1600200031 2.24 2.71
Socket Housing
53 1605190068 0.83 1.00
Thread-forming tap. Screw TT M5x18 MM
60 1603435023 1.18 1.43
Tapping Screw DIN 7981-4,8x38-C-Z-ST
61 2912401038 0.83 1.00
Pan head screw M4x10 MM
63 1603410014 1.18 1.43
Plastic-Cutting Screw St3,9x12
64 1603435042 1.18 1.43
Tapping Screw DIN 7981-3,9x19-C-Z-ST
65 2912401020 0.83 1.00
Tapping Screw DIN 7971-ST3,9x16-F
66 2910211019 0.83 1.00
Sealing Plate
68 1601006011 1.94 2.35
Damper
75 1600290057 15.71 19.01
Collar Screw TORX-PLUS-20-IP
76 1603414016 1.18 1.43
Catch Slide
101 1601990004 1.94 2.35
Compression Spring
102 1604616022 1.18 1.43
Manufacturer's nameplate
131 1601118G06 2.24 2.71
Protective Cover
651 1600A00XM0 18.19 22.01
Armature
803 1604010BC1 67.25 81.37
Switch BLACK
804 1607000967 26.84 32.48
Power supply cord EU 4,15m 2 x 1,5mm H07 RN-F
805 1607000228 20.42 24.71
Nameplate
808 160111A3H3 1.94 2.35
Carbon-Brush Set
810 1607014171 11.88 14.37
groove ball bearing 8x22x7
813 1600905011 4.70 5.69
Brush Holder
816 1604336048 5.33 6.45
Gear Housing
821 1607000C03 44.82 54.23
Bearing Flange Ø230 MM
822 1607000C05 20.42 24.71
Parts Set
826 1600A003FE 33.45 40.47
Rotary shaft lip seal 16 MM BLUE
833 1600290064 1.70 2.06
Rotary shaft lip seal 18,7 MM RED
833/1 1600290013 1.94 2.35
No information available, not orderable
835 1606610142
Push-Button
840 1607000354 5.33 6.45
Retaining Washer
846 1607000C3E 9.53 11.53
Spring retaining ring
848 1600119010 1.18 1.43
groove ball bearing 17x40x12
850 1600905026 6.54 7.91
Needle-Roller Bearing Ø14 MM
851 2600910001 3.31 4.01
O-Ring 20,35x1,78 MM
890 1600210039 1.70 2.06
Auxiliary Handle M14 BLACK
891 1602025051 23.75 28.74
Pin-Type Face-Wrench
892 F000632033 1.94 2.35
Clamping Flange Ø22,3xØ42 MM
893 2605703014 4.10 4.96
Round Nut M14
894 1603345043 6.54 7.91
Fast Locking Flange
896 1600A016PP 36.85 44.59
