Here you will find all available parts and drawings of the 'Bosch 0601362003 ( GWS23-230 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Bosch 0601362003 ( GWS23-230 )

Spare parts list of model Bosch 0601362003 ( GWS23-230 )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Motor Housing BLACK
1 1605108145 20.42 24.71
Field
2 160422057K 60.65 73.39
Fan
3/50 1606610127 2.24 2.71
Grommet Ø7,9-Ø12,0x120 MM
6 1600703022 2.24 2.71
Grommet Ø 10,5-Ø11,0x100 MM
6 1600703023 1.94 2.35
Fastening Clamp
7 1601302018 1.18 1.43
Manufacturer's nameplate
9 1601118346 0.83 1.00
Suppression Filter
12 1607328035 3.31 4.01
groove ball bearing 8x22x7
13 1600905011 4.70 5.69
Groove ball bearing 10x35x11
14 1600905025 9.53 11.53
Brush Holder
16 1604336021 2.24 2.71
Sealing cap BLACK
23 1605500150 2.71 3.28
Handle BLUE
24 1605132117 8.45 10.22
Grinding Spindle M14, SW17
25 1603523100 11.88 14.37
O-Ring 79,0x1,78 MM
28 1600210033 1.18 1.43
Air-Deflector Ring
30 1600591010 1.70 2.06
Air-Deflector Ring
31 1600591011 1.18 1.43
Retaining snap ring
32 1600290019 1.18 1.43
Rotary shaft lip seal 18,7 MM RED
33 1600290013 1.94 2.35
Rotary shaft lip seal 16 MM BLUE
33 1600290064 1.70 2.06
Shim 0,3 MM THICK
34 1600190021 1.94 2.35
Shim 0,1 MM THICK
34 1600190022 1.18 1.43
Shim 0,15 MM THICK
34 1600190020 1.18 1.43
Felt Washer
35 1600205034 1.18 1.43
Spiral Spring
36 1604652015 1.94 2.35
Seal Ring BLACK
37 1600290036 1.70 2.06
Rubber Ring 7 MM WIDE
38 1600206020 1.18 1.43
Rubber Ring
39 1600206030 1.18 1.43
Reference Plate
43 1601110470 0.83 1.00
Holding Bracket
44 1601334008 1.94 2.35
Hex Nut M10, SW14
45 1603300019 1.18 1.43
Spring retaining ring
48 1600119010 1.18 1.43
groove ball bearing
50 3600905134 8.45 10.22
Plain bearing Ø14 MM
51 1600200031 2.24 2.71
Cable routing
52 1602388027 1.94 2.35
Socket Housing
53 1605190038 1.18 1.43
Storage Ledge BLACK
55 1602388029 1.18 1.43
Thread-forming tap. Screw TT M5x18 MM
60 1603435023 1.18 1.43
Tapping Screw DIN 7981-4,8x38-C-Z-ST
61 2912401038 0.83 1.00
Tapping Screw C4,8x63 MM
62 1603435024 1.18 1.43
Pan head screw M4x10 MM
63 1603410014 1.18 1.43
Plastic-Cutting Screw St3,9x12
64 1603435042 1.18 1.43
Tapping Screw DIN 7981-3,9x19-C-Z-ST
65 2912401020 0.83 1.00
Tapping Screw DIN 7971-ST3,9x16-F
66 2910211019 0.83 1.00
Tapping Screw BZ 4,8x78 MM
67 1603435019 1.18 1.43
Manufacturer's nameplate
70 1601110554 0.83 1.00
O-Ring 20,35x1,78 MM
650/30/20 1600210039 1.70 2.06
Parts Set Ø230 MM
700 1607000251 0.83 1.00
No longer available, no replacement
700/10 1605510223
No longer available, no replacement
700/20 1608135003
No longer available, no replacement
701 1608135003
No information available, not orderable
702 1605510180
Parts Set
703 1607000140 0.83 1.00
Hex Screw M14x16x1,5 MM
703/11 2603450007 4.70 5.69
No longer available, no replacement
704 1605510181
No longer available, no replacement
730 1608601006
No information available, not orderable
730/20 1603345004
No information available, not orderable
740 1601329013
No information available, not orderable
750/10 2602025075
Hex Screw M14x16x1,5 MM
750/11 2603450007 4.70 5.69
No information available, not orderable
750/20 1607950048
Round-Head Bolt DIN 603-M 8x25
750/20/30 2910281244 1.18 1.43
Wing Nut DIN 315-M8-GT-C
750/20/40 2915191007 2.71 3.28
Plain Washer DIN 315-M8-GT-C
750/20/50 2600100041 1.18 1.43
Compression Spring
750/20/60 1604643003 5.33 6.45
No information available, not orderable
750/30 1605703099
No information available, not orderable
750/40 1603340040
No longer available, no replacement
751 1605510223
No information available, not orderable
763 1600793007
No information available, not orderable
764 1607950004
Fast Locking Flange
770 1600A016PP 36.85 44.59
Switch
804 1607200103 23.75 28.74
Carbon-Brush Set
810 1607014171 11.88 14.37
Gear Housing
821 1605805592 73.72 89.20
No longer available, no replacement
822 1607000985
Bearing Flange Ø230 MM BLACK
822/01 1607000932 33.45 40.47
Bearing Flange Ø 230 MM SILVER
822/02 1607000922 38.24 46.27
Assembly Of Service Parts
826 1600A005BH 40.61 49.14
No longer available, no replacement
830 1604011153
Power supply cord EU 4,15m 2 x 1,5mm H07 RN-F
835 1607000228 20.42 24.71
Seal Ring
837 1600290020 1.18 1.43
Push-Button BLACK
840 1607000206 8.45 10.22
Retaining Washer
846 1607000C3E 9.53 11.53
Needle-Roller Bearing Ø14 MM
851 2600910001 3.31 4.01
Nameplate
888 160111A3H3 1.94 2.35
