Here you will find all available parts and drawings of the 'Bosch 0601751020 ( GWS20-180 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0601751020 ( GWS20-180 )
Spare parts list of model Bosch 0601751020 ( GWS20-180 )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motor Housing | ||||
| 1 | 1619P11718 | 13.90 | 16.82 | |
| Field | ||||
| 2 | 1604220380 | 34.82 | 42.13 | |
| VENTILATOR | ||||
| 3/50 | 1606610142 | 3.71 | 4.49 | |
| Grommet | ||||
| 6 | 1600703023 | 2.40 | 2.90 | |
| Fastening Clamp | ||||
| 7 | 1601302018 | 1.49 | 1.80 | |
| Manufacturer's nameplate | ||||
| 9 | 1601118683 | 2.71 | 3.28 | |
| groove ball bearing | ||||
| 13 | 1600905011 | 5.81 | 7.03 | |
| Sealing cap | ||||
| 23 | 1618B00802 | 1.00 | 1.21 | |
| Handle | ||||
| 24 | 1619P11545 | 11.37 | 13.76 | |
| Grinding Spindle | ||||
| 25 | 160312305U | 11.02 | 13.33 | |
| No longer available, no replacement | ||||
| 26 | 1606333618 | |||
| Bevel Gear | ||||
| 27 | 1606333237 | 28.56 | 34.56 | |
| O-Ring | ||||
| 28 | 1600210033 | 1.49 | 1.80 | |
| O-Ring | ||||
| 29 | 1600210034 | 1.49 | 1.80 | |
| Air Distributor | ||||
| 30 | 1600591029 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 31 | 1600591075 | |||
| Retaining snap ring | ||||
| 32 | 1600290019 | 1.49 | 1.80 | |
| Rotary shaft lip seal | ||||
| 33 | 1600290013 | 2.40 | 2.90 | |
| Shim | ||||
| 34 | 1600190021 | 2.40 | 2.90 | |
| Shim | ||||
| 34 | 1600190022 | 1.49 | 1.80 | |
| Shim | ||||
| 34 | 1600190020 | 1.49 | 1.80 | |
| Felt Washer | ||||
| 35 | 1600205034 | 1.49 | 1.80 | |
| Seal Ring | ||||
| 37 | 1600290036 | 2.08 | 2.52 | |
| Rubber Ring | ||||
| 38 | 1600206020 | 1.49 | 1.80 | |
| Rubber Ring | ||||
| 39 | 1600206030 | 1.49 | 1.80 | |
| Hex Nut | ||||
| 45 | 1603300019 | 1.49 | 1.80 | |
| Plain bearing | ||||
| 51 | 1600200031 | 2.86 | 3.46 | |
| Socket Housing | ||||
| 53 | 1605190068 | 1.00 | 1.21 | |
| Thread-forming tap. Screw | ||||
| 60 | 1603435023 | 2.08 | 2.52 | |
| Tapping Screw | ||||
| 61 | 2912401038 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 62 | 1603435060 | 1.49 | 1.80 | |
| Pan head screw | ||||
| 63 | 1603410014 | 1.49 | 1.80 | |
| Plastic-Cutting Screw | ||||
| 64 | 1603435042 | 1.49 | 1.80 | |
| Tapping Screw | ||||
| 65 | 2912401020 | 1.90 | 2.30 | |
| Tapping Screw | ||||
| 66 | 2910211019 | 1.00 | 1.21 | |
| Sealing Plate | ||||
| 68 | 1601006011 | 2.40 | 2.90 | |
| O-Ring | ||||
| 650/30/20 | 1600210039 | 2.08 | 2.52 | |
| Parts Set | ||||
| 700 | 1607000250 | 0.83 | 1.00 | |
| No longer available, no replacement | ||||
| 700/10 | 1605510222 | |||
| Round-Head Bolt | ||||
| 700/20/30 | 2910281244 | 1.49 | 1.80 | |
| Wing Nut | ||||
| 700/20/40 | 2915191007 | 3.44 | 4.16 | |
| Compression Spring | ||||
| 700/20/60 | 1604643003 | 6.73 | 8.14 | |
| No longer available, no replacement | ||||
| 701 | 1608135003 | |||
| Suction Hood | ||||
| 702 | 1605510179 | 0.83 | 1.00 | |
| Strap-Shaped Handle | ||||
| 703 | 1607000247 | 1.00 | 1.21 | |
| Hex Screw | ||||
| 703/11 | 2603450007 | 5.81 | 7.03 | |
| No longer available, no replacement | ||||
| 704 | 1605510181 | |||
| No longer available, no replacement | ||||
| 730 | 1608601006 | |||
| Round Nut | ||||
| 730/20 | 1603345004 | 1.00 | 1.21 | |
| Plain Washer | ||||
| 730/30 | 2916011022 | 1.49 | 1.80 | |
| Protecting Cover | ||||
| 740 | 1601329013 | 1.00 | 1.21 | |
| Auxiliary Handle | ||||
| 750/10 | 2602025075 | 1.00 | 1.21 | |
| Pin-Type Face-Wrench | ||||
| 750/20 | 1607950048 | 1.00 | 1.21 | |
| Clamping-Flange | ||||
| 750/30 | 1605703099 | 1.00 | 1.21 | |
| Clamping Nut | ||||
| 750/40 | 1603340040 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 751 | 1605510222 | |||
| SNELSPANMOER | ||||
| 752 | 1603340027 | 45.52 | 55.08 | |
| Fast Locking Flange | ||||
| 752 | 1600A016PP | 41.30 | 49.97 | |
| Suction Bend | ||||
| 763 | 1600793007 | 1.00 | 1.21 | |
| Pin-Type Face-Wrench | ||||
| 764 | 1607950004 | 1.00 | 1.21 | |
| Armature | ||||
| 803 | 1619P15296 | 52.45 | 63.46 | |
| Switch | ||||
| 804 | 1607000967 | 31.42 | 38.02 | |
| Power supply cord | ||||
| 805 | 1607000228 | 23.90 | 28.92 | |
| Nameplate | ||||
| 808 | 160111A3H3 | 2.40 | 2.90 | |
| Carbon-Brush Set | ||||
| 810 | 1607014171 | 12.82 | 15.51 | |
| groove ball bearing | ||||
| 814 | 1600905023 | 11.37 | 13.76 | |
| Brush Holder | ||||
| 816 | 1604336048 | 6.53 | 7.90 | |
| Gear Housing | ||||
| 821 | 1607000974 | 49.56 | 59.97 | |
| No longer available, no replacement | ||||
| 822 | 1607000986 | |||
| Push-Button | ||||
| 840 | 1607000206 | 10.90 | 13.19 | |
| Retaining Washer | ||||
| 846 | 1607000342 | 3.44 | 4.16 | |
| Needle-Roller Bearing | ||||
| 851 | 2600910001 | 4.18 | 5.06 | |
