Here you will find all available parts and drawings of the 'Bosch 0601278760 ( GVS350AE )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0601278760 ( GVS350AE )
Spare parts list of model Bosch 0601278760 ( GVS350AE )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Housing Section BLUE | ||||
| 1 | 2605104576 | 15.71 | 19.01 | |
| Fan | ||||
| 3/50 | 2606610090 | 1.18 | 1.43 | |
| Grommet Ø6,4-Ø7,2x76 MM | ||||
| 6 | 2600703017 | 1.94 | 2.35 | |
| Cable Clip | ||||
| 7 | 2601035001 | 1.18 | 1.43 | |
| Manufacturer's nameplate | ||||
| 9 | 2601119137 | 2.71 | 3.28 | |
| Flanged Bearing | ||||
| 13 | 2605805008 | 4.10 | 4.96 | |
| No longer available, no replacement | ||||
| 14 | 2600905065 | |||
| Screw 4x16 | ||||
| 19 | 2603490022 | 0.83 | 1.00 | |
| Damping rubber | ||||
| 25 | 2603100056 | 1.18 | 1.43 | |
| Rpm Actuator 230-240V | ||||
| 26 | 2607233029 | 23.75 | 28.74 | |
| Contact Spring | ||||
| 27 | 2601329037 | 1.18 | 1.43 | |
| Switch Slide | ||||
| 28 | 2602319014 | 2.24 | 2.71 | |
| No longer available, no replacement | ||||
| 29 | 2604465109 | |||
| Wedge | ||||
| 30 | 2608000209 | 0.83 | 1.00 | |
| No longer available, no replacement | ||||
| 32 | 2601098045 | |||
| No longer available, no replacement | ||||
| 33 | 2601005019 | |||
| Hex Screw M 6x35 DIN 933-8.8 | ||||
| 40 | 2911061207 | 0.83 | 1.00 | |
| Compression Spring | ||||
| 41 | 2604612006 | 2.24 | 2.71 | |
| Control Knob RED | ||||
| 42 | 2606621011 | 2.24 | 2.71 | |
| Release Lever | ||||
| 48 | 2601990018 | 1.70 | 2.06 | |
| Coiled Spring | ||||
| 50 | 2604651009 | 0.83 | 1.00 | |
| No longer available, no replacement | ||||
| 51 | 2604680002 | |||
| No longer available, no replacement | ||||
| 58 | 2600118008 | |||
| Ceramic Plate | ||||
| 59 | 2601010059 | 4.70 | 5.69 | |
| No longer available, no replacement | ||||
| 60 | 2606625026 | |||
| Plug | ||||
| 63 | 2600591011 | 1.70 | 2.06 | |
| Adjusting Plate BLACK | ||||
| 64 | 2605500138 | 2.24 | 2.71 | |
| Sealing Cord | ||||
| 72 | 2603239027 | 2.71 | 3.28 | |
| No longer available, no replacement | ||||
| 73 | 2608604893 | |||
| No information available, not orderable | ||||
| 720 | 0603999012 | |||
| Protective Cover | ||||
| 754 | 1600A025XP | 7.58 | 9.17 | |
| Field 230-240V | ||||
| 802 | 2604220588 | 13.93 | 16.86 | |
| Armature 230V | ||||
| 803 | 2604010948 | 36.85 | 44.59 | |
| Power supply cord EU 2,6m 2 x 1,0 mm | ||||
| 805 | 1607000385 | 11.88 | 14.37 | |
| Marking Plate | ||||
| 808 | 2601119520 | 2.71 | 3.28 | |
| Carbon-Brush Set | ||||
| 810 | 2604321921 | 11.88 | 14.37 | |
| Brush Plate | ||||
| 816 | 2604337900 | 13.93 | 16.86 | |
| deflection pulley | ||||
| 836 | 2606625902 | 26.84 | 32.48 | |
| Tape Stretching Lever | ||||
| 845 | 2601990900 | 4.10 | 4.96 | |
| Tape Stretching Lever | ||||
| 846 | 2601990901 | 3.31 | 4.01 | |
| Locking Washer DIN 6799-4-FSt | ||||
| 849 | 2916080007 | 1.94 | 2.35 | |
| No longer available, no replacement | ||||
| 852 | 2601990902 | |||
| No longer available, no replacement | ||||
| 857 | 2606625903 | |||
| Crown Gear | ||||
| 867 | 2606334902 | 23.75 | 28.74 | |
| No longer available, no replacement | ||||
| 870 | 2605500907 | |||
