Here you will find all available parts and drawings of the 'Bosch 0601584103 ( GST85P )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0601584103 ( GST85P )
Spare parts list of model Bosch 0601584103 ( GST85P )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Needle Roller | ||||
| 4 | 1903201042 | 2.08 | 2.52 | |
| Felt Washer | ||||
| 5 | 2600108077 | 1.49 | 1.80 | |
| Cupped Washer | ||||
| 6 | 2600500002 | 1.49 | 1.80 | |
| Spring retaining ring | ||||
| 8 | 2916660008 | 2.08 | 2.52 | |
| No longer available, no replacement | ||||
| 9 | 2600400008 | |||
| Shim | ||||
| 12 | 2600101616 | 2.86 | 3.46 | |
| Eccentric Cog Wheel | ||||
| 15 | 1619P02581 | 21.30 | 25.77 | |
| Shim | ||||
| 16 | 2600102653 | 1.49 | 1.80 | |
| Shim | ||||
| 17 | 2600100515 | 2.40 | 2.90 | |
| Fork Lever | ||||
| 18 | 2601923004 | 3.04 | 3.68 | |
| Shim | ||||
| 20 | 2600102652 | 1.49 | 1.80 | |
| Shim | ||||
| 21 | 2600100626 | 1.49 | 1.80 | |
| Shim | ||||
| 21 | 2600100627 | 1.49 | 1.80 | |
| Shim | ||||
| 21 | 2600100628 | 1.49 | 1.80 | |
| Counterweight | ||||
| 22 | 2601098003 | 8.35 | 10.10 | |
| Spacer Sleeve | ||||
| 23 | 2600309009 | 1.49 | 1.80 | |
| Shim | ||||
| 25 | 2600100575 | 2.08 | 2.52 | |
| Shim | ||||
| 25 | 2600100576 | 2.08 | 2.52 | |
| Shim | ||||
| 25 | 2600100577 | 1.49 | 1.80 | |
| Microencapsulated Screw | ||||
| 27 | 2914551176 | 1.00 | 1.21 | |
| Shim | ||||
| 29 | 2600100607 | 1.49 | 1.80 | |
| Shim | ||||
| 29 | 2600100568 | 1.49 | 1.80 | |
| Shim | ||||
| 29 | 2600100569 | 1.49 | 1.80 | |
| Air Eliminator | ||||
| 32 | 2602305042 | 1.49 | 1.80 | |
| Ratchet Cap | ||||
| 34 | 2600590006 | 1.49 | 1.80 | |
| Rotary Knob | ||||
| 35 | 2602026036 | 4.18 | 5.06 | |
| Rotary Knob | ||||
| 37 | 2602026037 | 2.86 | 3.46 | |
| Seal | ||||
| 39 | 2601015050 | 2.18 | 2.64 | |
| Sintered-Metal Bushing | ||||
| 40/10 | 2600301046 | 3.44 | 4.16 | |
| Bushing | ||||
| 40/20 | 2600301045 | 2.86 | 3.46 | |
| Thread-forming tap. Screw | ||||
| 41 | 2603410048 | 1.49 | 1.80 | |
| Compression Spring | ||||
| 42 | 2604613000 | 1.49 | 1.80 | |
| Guide Bracket | ||||
| 43 | 1616B00224 | 13.13 | 15.89 | |
| Lifting Rod | ||||
| 44 | 1619P12765 | 14.94 | 18.08 | |
| Clamping Saddle | ||||
| 45 | 2602329011 | 3.44 | 4.16 | |
| Sliding Piece | ||||
| 46 | 1619P12767 | 9.67 | 11.70 | |
| Countersunk-Head Screw | ||||
| 47 | 2603421040 | 1.49 | 1.80 | |
| Supporting Disc | ||||
| 48 | 2600112031 | 1.49 | 1.80 | |
| Seal Ring | ||||
| 49 | 2600290017 | 1.49 | 1.80 | |
| Shim | ||||
| 50 | 2600101612 | 1.49 | 1.80 | |
| Clamp Screw | ||||
| 53 | 2603490011 | 6.73 | 8.14 | |
| Locking washer | ||||
| 57 | 2600116011 | 2.08 | 2.52 | |
| Torx Oval-Head Screw | ||||
| 60 | 2603490024 | 1.49 | 1.80 | |
| Hex Nut | ||||
| 62 | 2915011007 | 1.00 | 1.21 | |
| Profile Beading | ||||
| 64 | 2601030019 | 2.40 | 2.90 | |
| Hex Socket Head Cap Screw | ||||
| 65 | 2910141197 | 1.44 | 1.74 | |
| Flanged Fitting | ||||
| 68 | 2605702016 | 7.46 | 9.03 | |
| No longer available, no replacement | ||||
| 71 | 2604617003 | |||
| Thread-forming tap. Screw | ||||
| 72 | 2603410054 | 2.40 | 2.90 | |
| Thread-forming tap. Screw | ||||
| 74 | 2603410049 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 75 | 2606491015 | |||
| Scale Plate | ||||
| 76 | 2601328044 | 2.40 | 2.90 | |
| Shim | ||||
| 77 | 2600100032 | 1.49 | 1.80 | |
| Sticker | ||||
| 78 | 2601110930 | 1.49 | 1.80 | |
| Compression Spring | ||||
| 85 | 2604610040 | 1.49 | 1.80 | |
| Safety Device | ||||
| 90 | 2601322021 | 4.18 | 5.06 | |
| Socket head cap screw | ||||
| 91 | 2910011128 | 1.00 | 1.21 | |
| Field | ||||
| 102 | 2604220709 | 27.81 | 33.65 | |
| Armature | ||||
| 103 | 2604010578 | 52.45 | 63.46 | |
| Fan | ||||
| 103/60 | 2606610049 | 2.08 | 2.52 | |
| Switch | ||||
| 104 | 2607200674 | 14.94 | 18.08 | |
| Grommet | ||||
| 106 | 2600703027 | 1.49 | 1.80 | |
| Cable Clip | ||||
| 107 | 2601035001 | 1.49 | 1.80 | |
| Manufacturer's nameplate | ||||
| 109 | 2601118482 | 2.38 | 2.88 | |
| Suppression Filter | ||||
| 112 | 2607329104 | 9.67 | 11.70 | |
| Ball Bearing | ||||
| 113 | 1900905018 | 16.79 | 20.32 | |
| Brush Holder | ||||
| 116 | 1600A003G4 | 3.44 | 4.16 | |
| Brush Holder | ||||
| 116 | 2601323022 | 2.86 | 3.46 | |
| Socket head cap screw | ||||
| 118 | 2603410001 | 1.49 | 1.80 | |
| Screw | ||||
| 119 | 2603490022 | 1.00 | 1.21 | |
| Reference Plate | ||||
| 120 | 2601118526 | 2.40 | 2.90 | |
| Tapping Screw | ||||
| 129 | 2910601321 | 1.49 | 1.80 | |
| Switch Handle | ||||
| 130 | 2602026015 | 1.49 | 1.80 | |
| Offset Screwdriver | ||||
| 131 | 1907950006 | 3.71 | 4.49 | |
| Hexagon Socket Screw Key | ||||
| 131 | 2610364015 | 3.44 | 4.16 | |
| Suppression Filter | ||||
| 133 | 2604465049 | 3.44 | 4.16 | |
| Suppression Filter | ||||
| 133 | 1619P15513 | 2.18 | 2.64 | |
| Connecting Cable | ||||
| 134 | 2604448044 | 1.00 | 1.21 | |
| Connecting Cable | ||||
| 135 | 2604448056 | 1.49 | 1.80 | |
| Tapping Screw | ||||
| 139 | 2910611006 | 1.49 | 1.80 | |
| Plug | ||||
| 149 | 2603231032 | 1.49 | 1.80 | |
| Shim | ||||
| 150 | 2600101020 | 1.49 | 1.80 | |
| Shim | ||||
| 150 | 2600101022 | 1.49 | 1.80 | |
| Shim washer | ||||
| 150 | 2600101027 | 1.49 | 1.80 | |
| Shim | ||||
| 151 | 2600150004 | 2.08 | 2.52 | |
| Tapping Screw | ||||
| 152 | 2603435086 | 1.32 | 1.60 | |
| Adjusting Slide | ||||
| 153 | 2602319005 | 1.49 | 1.80 | |
| Cover Disc | ||||
| 154 | 2601328045 | 2.08 | 2.52 | |
| Torx Oval-Head Screw | ||||
| 155 | 2603490017 | 2.08 | 2.52 | |
| Spiral Spring | ||||
| 156 | 2604652009 | 1.49 | 1.80 | |
| Housing Cover | ||||
| 157 | 2600508036 | 9.67 | 11.70 | |
| Safety Device | ||||
| 201 | 2601322021 | 4.18 | 5.06 | |
| Socket head cap screw | ||||
| 203 | 2910011128 | 1.00 | 1.21 | |
| Gear Housing | ||||
| 801 | 2605808917 | 71.68 | 86.73 | |
| No longer available, no replacement | ||||
| 802 | 2605108904 | |||
| Power supply cord | ||||
| 805 | 1607000385 | 13.13 | 15.89 | |
| groove ball bearing | ||||
| 807 | 2600905039 | 11.37 | 13.76 | |
| Carbon-Brush Set | ||||
| 810 | 1607000486 | 67.98 | 82.26 | |
| Carbon-Brush Set | ||||
| 810 | 2604320912 | 8.48 | 10.26 | |
| No longer available, no replacement | ||||
| 813 | 2607001130 | |||
| Locking washer | ||||
| 819 | 2916080007 | 2.40 | 2.90 | |
| Eccentric Disc | ||||
| 824 | 2601072901 | 7.46 | 9.03 | |
| Locking washer | ||||
| 826 | 2916080910 | 2.08 | 2.52 | |
| Needle bearing | ||||
| 830 | 2600917900 | 8.35 | 10.10 | |
| No longer available, no replacement | ||||
| 836 | 2916080008 | |||
| Spring retaining ring | ||||
| 838 | 2600116009 | 1.00 | 1.21 | |
| Gear Cover | ||||
| 840 | 2605808921 | 98.18 | 118.80 | |
| No longer available, no replacement | ||||
| 851 | 2601015901 | |||
| Roller Lever | ||||
| 854 | 1619P00777 | 14.94 | 18.08 | |
| Roller Set | ||||
| 855 | 1619P01375 | 10.90 | 13.19 | |
| Roller Set | ||||
| 859 | 1619P01375 | 10.90 | 13.19 | |
| Fan Cover | ||||
| 861 | 2605500900 | 4.18 | 5.06 | |
| Base Plate | ||||
| 863 | 2601016903 | 16.79 | 20.32 | |
| No longer available, no replacement | ||||
| 869 | 2602026900 | |||
| Nameplate | ||||
| 888 | 160111A3H3 | 2.40 | 2.90 | |
