Here you will find all available parts and drawings of the 'Bosch 0601581503 ( GST60PBE )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Bosch 0601581503 ( GST60PBE )

Spare parts list of model Bosch 0601581503 ( GST60PBE )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Needle Roller DIN 5402-A3x11,8-G2
4 1903201042 1.70 2.06
Felt Washer
5 2600108077 1.18 1.43
Cupped Washer
6 2600500002 1.18 1.43
Spring retaining ring DIN 472-24x1,2 MM
8 2916660008 1.70 2.06
Receptacle
9 2600400008 1.18 1.43
Shim 0,5 MM
12 2600101616 2.24 2.71
Eccentric Cog Wheel
15 1619P02581 18.19 22.01
Shim 1,0 MM
16 2600102653 1.18 1.43
Shim 0,3 MM
17 2600100515 1.94 2.35
Fork Lever
18 2601923004 2.24 2.71
Shim 0,5 MM
20 2600102652 1.18 1.43
Shim 0,2 MM
21 2600100626 1.18 1.43
Shim 0,3 MM
21 2600100627 1.18 1.43
Shim 0,5 MM
21 2600100628 1.18 1.43
Counterweight
22 2601098003 6.54 7.91
Spacer Sleeve
23 2600309009 1.18 1.43
Shim 0,2 MM
25 2600100575 1.70 2.06
Shim 0,3 MM
25 2600100576 1.70 2.06
Shim 0,5 MM
25 2600100577 1.18 1.43
Shim 0,3 MM
29 2600100607 1.18 1.43
Shim 0,5 MM
29 2600100568 1.18 1.43
Shim 1,0 MM
29 2600100569 1.18 1.43
Air Eliminator
32 2602305042 1.18 1.43
Ratchet Cap
34 2600590006 1.18 1.43
Rotary Knob BLACK
35 2602026036 3.31 4.01
Rotary Knob BLACK
37 2602026037 2.24 2.71
Seal
39 2601015050 1.94 2.35
Thread-forming tap. Screw M4x8
41 2603410048 1.18 1.43
Compression Spring
42 2604613000 1.18 1.43
Guide Bracket
43 1616B00224 11.88 14.37
Lifting Rod
44 1619P12765 12.41 15.02
Clamping Saddle
45 2602329011 2.71 3.28
Sliding Piece
46 1619P12767 7.58 9.17
Countersunk-Head Screw DIN 7962-M3,5x8-10.9
47 2603421040 1.18 1.43
Supporting Disc 0,5 MM
48 2600112031 1.18 1.43
Seal Ring 0,5 MM
49 2600290017 1.18 1.43
Shim 0,5 MM
50 2600101612 1.18 1.43
Clamp Screw
53 2603400000 3.31 4.01
Roller Set
59 1619P01375 8.45 10.22
Torx Oval-Head Screw 4x25
60 2603490024 1.18 1.43
Hex Nut DIN 934-M6-8-A
62 2915011007 0.83 1.00
Profile Beading
64 2601030019 1.94 2.35
Hex Socket Head Cap Screw DIN 912-M6x16-8.8
65 2910141197 0.83 1.00
Microencapsulated Screw DIN 7985-M4x12MM
69 2914551176 0.83 1.00
Scale Plate
70 2601328044 1.94 2.35
Shim 0,2 MM
77 2600100032 1.18 1.43
Safety Device
90 2601322021 3.31 4.01
Socket head cap screw DIN 84-AM4x18-5.8
91 2910011128 0.83 1.00
Field 220-240V
102 2604220709 23.75 28.74
Armature 230-240V
103 2604010578 44.82 54.23
Switch
104 2607200260 8.45 10.22
Grommet Ø6,5-Ø6,9x95 MM
106 2600703027 1.18 1.43
Cable Clip
107 2601035001 1.18 1.43
Manufacturer's nameplate
109 2601116647 1.94 2.35
No longer available, no replacement
112 2607329105
Ball Bearing 7x22x7
113 1900905018 13.93 16.86
Brush Holder
116 1600A003G4 2.71 3.28
Socket head cap screw M3x6,5-4.8
118 2603410001 1.18 1.43
Screw 4x16
119 2603490022 0.83 1.00
Reference Plate
120 2601117544 2.71 3.28
Tapping Screw DIN 7982-ST3,9x22C-H
125 2910601321 1.18 1.43
Strap-Shaped Handle
126 2602025040 11.88 14.37
Strap-Shaped Handle
127 2602025041 7.58 9.17
Thread-forming tap. Screw M 5x16
128 2603410054 1.94 2.35
Offset Screwdriver
131 1907950006 3.12 3.78
Hexagon Socket Screw Key 5 MM
131 2610364015 2.71 3.28
Square Nut M4
132 2603320001 1.18 1.43
Suppression Filter
137 2604465049 2.71 3.28
No longer available, no replacement
138 2607230115
Connecting Cable L = 278 MM BLUE
144 2604448012 1.18 1.43
Connecting Cable L = 288 MM WHITE
145 2604448062 1.18 1.43
Connecting Cable L=124 MM WHITE
147 2604448018 1.94 2.35
Insulation Tubing
148 2600409017 0.83 1.00
Shim 0,5 MM
150 2600101020 1.18 1.43
Shim 0,2 MM
150 2600101022 1.18 1.43
Shim washer 0,3 MM
150 2600101027 1.18 1.43
Shim
151 2600150004 1.70 2.06
Tapping Screw
152 2603435086 1.18 1.43
Plug BLUE
153 2603231032 1.18 1.43
Cover Disc
154 2601328045 1.70 2.06
Torx Oval-Head Screw 3x10
155 2603490017 1.70 2.06
Housing Cover BLUE
157 2600508038 6.54 7.91
Spiral Spring
166 2604652009 1.18 1.43
Fan
170 2606610049 1.70 2.06
Sintered-Metal Bushing
171 2600301046 2.71 3.28
Bushing
172 2600301045 2.24 2.71
No longer available, no replacement
199 1601110265
Gear Housing
801 2605808915 33.45 40.47
No longer available, no replacement
802 2605108904
Power supply cord EU 2,6m 2 x 1,0 mm
805 1607000385 11.88 14.37
groove ball bearing 9x24x7
807 2600905039 9.53 11.53
Carbon-Brush Set
810 2604320912 7.58 9.17
Needle-Roller Cage
813 2607001130 4.70 5.69
Locking Washer DIN 6799-4-FSt
819 2916080007 1.94 2.35
Eccentric Disc
824 2601072901 5.83 7.05
Screw and washer assembly M 4x20 MM
830 2914501021 0.83 1.00
Needle bearing
831 2600917900 6.54 7.91
No longer available, no replacement
836 2916080008
Spring retaining ring
838 2600116009 0.83 1.00
Gear Cover
840 2605808919 113.29 137.08
No longer available, no replacement
851 2601015901
No longer available, no replacement
854 2601321902
Roller Set
855 1619P01375 8.45 10.22
Fan Cover
861 2605500900 3.31 4.01
Base Plate
863 2601016903 12.41 15.02
Nameplate
888 160111A3H3 1.94 2.35
