Here you will find all available parts and drawings of the 'Bosch 0601936723 (GSR7,2VES-2)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0601936723 (GSR7,2VES-2)
Spare parts list of model Bosch 0601936723 (GSR7,2VES-2)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| No longer available, no replacement | ||||
| 2/10 | 2606316161 | |||
| No longer available, no replacement | ||||
| 5 | 2601099055 | |||
| Manufacturer's nameplate SUNNY SIDE | ||||
| 9 | 2601118479 | 2.24 | 2.71 | |
| Sticker SHADOW SIDE | ||||
| 20 | 2601118480 | 2.24 | 2.71 | |
| Keyless Chuck | ||||
| 25 | 2608572214 | 47.53 | 57.51 | |
| Adapter Insert | ||||
| 28 | 2605719018 | 1.49 | 1.80 | |
| Insert Piece | ||||
| 29 | 2605510130 | 3.44 | 4.16 | |
| Inserted Part | ||||
| 31 | 2608040098 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 45 | 2606200065 | |||
| Intermediate Flange | ||||
| 45/6 | 2605719008 | 3.44 | 4.16 | |
| Torx SH cap screw | ||||
| 54 | 2603414048 | 1.00 | 1.21 | |
| Support | ||||
| 96 | 2608040131 | 2.08 | 2.52 | |
| Clamp Spring | ||||
| 100 | 2601322016 | 2.08 | 2.52 | |
| Torx Oval-Head Screw | ||||
| 101 | 2603490018 | 1.00 | 1.21 | |
| Retaining Bracket | ||||
| 102 | 2601329041 | 1.49 | 1.80 | |
| Countersunk-Head Screw | ||||
| 107 | 2609110721 | 2.08 | 2.52 | |
| Support | ||||
| 108 | 2602180001 | 1.00 | 1.21 | |
| Fast Charger | ||||
| 753 | 2607224425 | 155.51 | 188.17 | |
| Fast Charger | ||||
| 753 | 2607224701 | 122.80 | 148.59 | |
| Slide-In Accu Package 7,2V,1,5Ah,NiCd | ||||
| 791 | 2607336141 | 55.25 | 66.85 | |
| Screwdriver Blade | ||||
| 793 | 2608521018 | 4.18 | 5.06 | |
| Housing Section BLUE | ||||
| 801 | 2605104824 | 11.88 | 14.37 | |
| DC motor 7,2V | ||||
| 802 | 2607022945 | 23.75 | 28.74 | |
| On-Off Switch | ||||
| 804 | 2607200353 | 58.03 | 70.22 | |
| Adjusting Slide | ||||
| 832 | 2601099126 | 10.90 | 13.19 | |
| No information available, not orderable | ||||
| 899 | 0601936723 | |||
