Here you will find all available parts and drawings of the 'Bosch 0601921560 (GSR12VES)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0601921560 (GSR12VES)
Spare parts list of model Bosch 0601921560 (GSR12VES)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Sticker | ||||
| 9 | 2601118181 | 2.86 | 3.46 | |
| Reference Plate | ||||
| 20 | 2601118802 | 0.83 | 1.00 | |
| Drilling Spindle | ||||
| 26 | 2606309027 | 10.90 | 13.19 | |
| groove ball bearing | ||||
| 29 | 1900905127 | 27.81 | 33.65 | |
| groove ball bearing | ||||
| 29 | 1900905120 | 9.67 | 11.70 | |
| Spring retaining ring | ||||
| 31 | 2916650001 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 32 | 2605190014 | |||
| Setting Socket | ||||
| 33 | 2600499015 | 9.67 | 11.70 | |
| Retaining Washer | ||||
| 34 | 2600134004 | 1.49 | 1.80 | |
| Thread-forming tap. Screw | ||||
| 35 | 2603490003 | 1.49 | 1.80 | |
| Perforated disk | ||||
| 36 | 2600190041 | 2.86 | 3.46 | |
| Catch Disk | ||||
| 37 | 2600290019 | 1.49 | 1.80 | |
| Shim | ||||
| 40/10 | 2600101631 | 1.00 | 1.21 | |
| Coupling Half | ||||
| 41 | 2606490047 | 5.81 | 7.03 | |
| Ball Cage | ||||
| 42 | 2600923001 | 3.44 | 4.16 | |
| Ball | ||||
| 43 | 1903230007 | 1.49 | 1.80 | |
| Cylindrical Gear | ||||
| 46 | 1609340007 | 13.13 | 15.89 | |
| Adjusting Slide | ||||
| 47 | 2601099027 | 1.49 | 1.80 | |
| Sintered-Metal Bushing | ||||
| 48 | 2600301011 | 1.49 | 1.80 | |
| Screw | ||||
| 49 | 2603490022 | 1.00 | 1.21 | |
| Pinion | ||||
| 53 | 2606316112 | 4.18 | 5.06 | |
| Sintered-Metal Bushing | ||||
| 54 | 2600302002 | 1.49 | 1.80 | |
| Shim | ||||
| 55 | 2600100636 | 1.49 | 1.80 | |
| Holding Spring | ||||
| 58 | 2601250002 | 1.49 | 1.80 | |
| Heat Sink | ||||
| 61 | 2605715000 | 4.18 | 5.06 | |
| Oval-Head Screw | ||||
| 62 | 2910641050 | 1.00 | 1.21 | |
| Connecting Cable | ||||
| 63 | 2604413005 | 1.49 | 1.80 | |
| Connecting Cable | ||||
| 64 | 2604413004 | 1.49 | 1.80 | |
| Contact Spring | ||||
| 66 | 2601324012 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 68 | 2601010038 | |||
| No longer available, no replacement | ||||
| 71 | 2601251003 | |||
| Sticker | ||||
| 75 | 2601118299 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 77 | 2601110461 | |||
| Countersunk-Head Screw | ||||
| 78 | 2609110721 | 2.08 | 2.52 | |
| No longer available, no replacement | ||||
| 199 | 1601110265 | |||
| Filler Piece | ||||
| 200 | 2605510027 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 725 | 2608572010 | |||
| Protective Flap | ||||
| 725/800 | 2600591006 | 12.82 | 15.51 | |
| No longer available, no replacement | ||||
| 730 | 2607335021 | |||
| Fast Charger | ||||
| 760 | 2607224425 | 155.51 | 188.17 | |
| Fast Charger | ||||
| 760 | 2607224701 | 122.80 | 148.59 | |
| Screwdriver Blade | ||||
| 765 | 1609200147 | 3.44 | 4.16 | |
| No longer available, no replacement | ||||
| 801 | 2605104776 | |||
| DC motor | ||||
| 802 | 2607022910 | 31.42 | 38.02 | |
| On-Off Switch | ||||
| 804 | 2607200302 | 47.53 | 57.51 | |
| No longer available, no replacement | ||||
| 838 | 2607001126 | |||
| Coupling Half | ||||
| 844 | 2606436900 | 14.94 | 18.08 | |
| Toothed Shaft | ||||
| 851 | 1609340005 | 14.94 | 18.08 | |
| No longer available, no replacement | ||||
| 899 | 0601921565 | |||
