Here you will find all available parts and drawings of the 'Bosch 0601949567 (GSR12V)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0601949567 (GSR12V)
Spare parts list of model Bosch 0601949567 (GSR12V)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| No longer available, no replacement | ||||
| 2/10 | 2606316161 | |||
| No longer available, no replacement | ||||
| 5 | 2601099055 | |||
| Manufacturer's nameplate | ||||
| 9 | 2601119715 | 2.87 | 3.47 | |
| Reference Plate | ||||
| 20 | 2601119716 | 2.87 | 3.47 | |
| Keyless Chuck | ||||
| 25 | 2608572214 | 47.53 | 57.51 | |
| Control Fork | ||||
| 30 | 2602033008 | 2.40 | 2.90 | |
| Adjusting Slide | ||||
| 32 | 2601099060 | 1.00 | 1.21 | |
| Planetary Gear Train | ||||
| 45 | 2606200073 | 52.45 | 63.46 | |
| Intermediate Flange | ||||
| 45/6 | 2605719011 | 3.44 | 4.16 | |
| No longer available, no replacement | ||||
| 91 | 2607335054 | |||
| Screwdriver Blade | ||||
| 93 | 1609200147 | 3.44 | 4.16 | |
| Support | ||||
| 96 | 2608040079 | 1.00 | 1.21 | |
| Torx Oval-Head Screw | ||||
| 101 | 2603490018 | 1.00 | 1.21 | |
| Retaining Bracket | ||||
| 102 | 2601329041 | 1.49 | 1.80 | |
| Countersunk-Head Screw | ||||
| 107 | 2609110721 | 2.08 | 2.52 | |
| Fast Charger | ||||
| 653 | 2607224425 | 155.51 | 188.17 | |
| Fast Charger | ||||
| 653 | 2607224701 | 122.80 | 148.59 | |
| No longer available, no replacement | ||||
| 797 | 2601398009 | |||
| Housing Section | ||||
| 801 | 2605104649 | 14.94 | 18.08 | |
| No longer available, no replacement | ||||
| 802 | 2607022962 | |||
| On-Off Switch | ||||
| 804 | 2607200353 | 58.03 | 70.22 | |
| No information available, not orderable | ||||
| 899 | 0601949520 | |||
