Here you will find all available parts and drawings of the 'Bosch 060119B703 ( GSB20-2RCE )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Bosch 060119B703 ( GSB20-2RCE )

Spare parts list of model Bosch 060119B703 ( GSB20-2RCE )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Motor Housing
1 2605105033 20.42 24.71
Field 220-240V
2 2604220692 18.19 22.01
Armature 230-240V
3 2604011319 36.85 44.59
Switch
4 2607200585 20.42 24.71
Grommet
6 2600707072 1.94 2.35
Manufacturer's nameplate
9 2601116339 1.70 2.06
Ball Bearing 9x24x7
14 2600905095 9.53 11.53
Torx Oval-Head Screw 3x10
19 2603490017 1.70 2.06
Reference Plate
20 2601116343 2.71 3.28
Drilling Spindle
24 2606135130 18.19 22.01
Compression Spring
26 2604616013 1.94 2.35
groove ball bearing 17x35x10
27 1900905163 8.45 10.22
Shim 0,5 MM
28 2600100695 1.18 1.43
Spring retaining ring DIN 471 17x1 MM
29 2916650008 1.18 1.43
Flat Key
30 2602300032 2.71 3.28
Retaining Washer
31 2600101671 1.18 1.43
Cylindrical Gear
33 2606317084 10.73 12.98
Cylindrical Gear
34 2606317098 9.53 11.53
Shim 0,3 MM
35 2600101047 1.18 1.43
No longer available, no replacement
36 2600190090
Shim washer 1,0 MM
38 2600000021 1.18 1.43
Shim washer 1,35 MM
38 2600000030 1.18 1.43
Shim washer 1,7 MM
38 2600000031 1.18 1.43
Ball DIN 5401-5 G28
40 1903230009 0.83 1.00
Ball DIN 5401-5,5MM-III-ST
40 1903230010 0.83 1.00
Ball 5,25 MM
40 2603230007 0.83 1.00
Rotary Knob
41 2602026118 2.71 3.28
Control Shaft
42 2603120064 2.24 2.71
Seal
44 2601015091 2.71 3.28
Air Guide Plate
45 2600148008 2.24 2.71
Tapping Screw
46 2603435086 1.18 1.43
Contact Spring
48 2601324048 1.70 2.06
Disc Spring
53 2600550008 1.18 1.43
Shim 0,3 MM
61 2600100607 1.18 1.43
Headless Screw
63 2603435084 0.83 1.00
Headless Screw
64 2603435085 0.83 1.00
Compression Spring
68 2604616014 0.83 1.00
Rotary Knob BLACK
69 2602026117 1.70 2.06
Ratchet Cap
71 2600590006 1.18 1.43
Torx Oval-Head Screw 4x30
72 2603490025 0.83 1.00
Screw 4x16
73 2603490022 0.83 1.00
Switch Contact
74 1611329024 1.18 1.43
Adapter module
75 1600A0032J 1.18 1.43
Brush Plate
76 1614336061 13.93 16.86
Spring retaining ring DIN 472 35x1,5 MM
78 2916660014 1.18 1.43
No longer available, no replacement
79 2607230084
Keyless Chuck HSB 4
85 2608572143 60.65 73.39
Connecting Cable L=80 MM
86 1614448014 1.94 2.35
Lens BLACK
89 2605510206 1.94 2.35
Reference Plate
210 2601116318 0.83 1.00
Auxiliary Handle
653 2602025139 11.88 14.37
Auxiliary Handle M8
653/120 1612025019 5.33 6.45
Support clamp
653/121 2608040235 5.33 6.45
Clamping Band Ø43 MM
653/124 1611316006 1.94 2.35
T-Head Bolt M8x40 MM
653/125 1613490002 3.31 4.01
Depth-Gauge SW 6x210 MM
655 1613001009 2.71 3.28
Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-
805 1607000386 15.71 19.01
Marking Plate
808 2601116349 2.71 3.28
Carbon-Brush Set 220 V / 127 V
810 1617000525 8.45 10.22
Gear Housing
825 2605806892 33.45 40.47
Bearing Bracket
843 2605700943 29.75 36.00
Housing Cover
847 2605132901 12.41 15.02
Transmission
859 2606309934 40.61 49.14
Transmission
859 1600A00MM2 23.75 28.74
Adjusting Slide
866 2602033018 3.31 4.01
Toothed rack
867 2606308925 4.70 5.69
Holding Plate BLACK
888 2601328900 2.24 2.71
Fastening parts kit
890 2607001305 3.31 4.01
Cross Recessed-Head Screw M3x5
891 2603410046 1.70 2.06
