Here you will find all available parts and drawings of the 'Bosch 0601141691 ( GSB2-600RE )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0601141691 ( GSB2-600RE )
Spare parts list of model Bosch 0601141691 ( GSB2-600RE )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Housing Section | ||||
| 1 | 2605104437 | 31.65 | 38.30 | |
| Field | ||||
| 2 | 2604220429 | 23.90 | 28.92 | |
| No longer available, no replacement | ||||
| 3 | 2604010862 | |||
| Fan | ||||
| 3/60 | 2606610029 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 4 | 2607200209 | |||
| Grommet | ||||
| 6 | 2600707059 | 3.44 | 4.16 | |
| Grommet | ||||
| 6 | 2600707061 | 2.86 | 3.46 | |
| Grommet | ||||
| 6 | 2600707060 | 2.40 | 2.90 | |
| Cable Clip | ||||
| 7 | 2601035001 | 1.49 | 1.80 | |
| Manufacturer's nameplate | ||||
| 9 | 2601118842 | 2.87 | 3.47 | |
| No longer available, no replacement | ||||
| 12 | 2607329114 | |||
| groove ball bearing | ||||
| 14 | 2600905050 | 10.34 | 12.51 | |
| No longer available, no replacement | ||||
| 16 | 2605807060 | |||
| Socket head cap screw | ||||
| 18 | 2603410001 | 1.49 | 1.80 | |
| Screw | ||||
| 19 | 2603490022 | 1.00 | 1.21 | |
| Reference Plate | ||||
| 20 | 2601118439 | 1.73 | 2.09 | |
| Torx Oval-Head Screw | ||||
| 27 | 2603490018 | 1.00 | 1.21 | |
| Socket head cap screw | ||||
| 28 | 2603429005 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 29 | 2601022000 | |||
| Drilling Spindle | ||||
| 30 | 2606135044 | 15.26 | 18.46 | |
| Locking washer | ||||
| 31 | 2600118006 | 2.08 | 2.52 | |
| Locking washer | ||||
| 31 | 2600118002 | 1.49 | 1.80 | |
| Locking washer | ||||
| 31 | 2600118001 | 1.00 | 1.21 | |
| Compression Spring | ||||
| 32 | 2604616002 | 1.49 | 1.80 | |
| groove ball bearing | ||||
| 33 | 1900905163 | 10.90 | 13.19 | |
| Cylindrical Gear | ||||
| 34 | 2606317045 | 10.90 | 13.19 | |
| Cylindrical Gear | ||||
| 35 | 2606317037 | 27.81 | 33.65 | |
| Shim | ||||
| 36 | 2600101515 | 1.00 | 1.21 | |
| Retaining clip | ||||
| 37 | 2916650006 | 1.49 | 1.80 | |
| Retaining Washer | ||||
| 39 | 2600101671 | 1.49 | 1.80 | |
| Flat Key | ||||
| 40 | 2602300028 | 4.94 | 5.98 | |
| Catch Disk | ||||
| 42 | 2600190052 | 6.73 | 8.14 | |
| Ball | ||||
| 44 | 1903230010 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 45 | 2601990001 | |||
| Pressure Plate | ||||
| 46 | 2601074003 | 1.00 | 1.21 | |
| Shim | ||||
| 52 | 2600100607 | 1.49 | 1.80 | |
| Needle-Roller Bearing | ||||
| 53 | 2600914010 | 2.86 | 3.46 | |
| Bearing Sleeve | ||||
| 54 | 2600400027 | 4.18 | 5.06 | |
| No longer available, no replacement | ||||
| 56 | 2602033005 | |||
| Rotary Head | ||||
| 57 | 2602026091 | 4.94 | 5.98 | |
| Ratchet Cap | ||||
| 58 | 2600590006 | 1.49 | 1.80 | |
| Driver Pin | ||||
| 62 | 2601335001 | 2.08 | 2.52 | |
| Shim washer | ||||
| 64 | 2600100618 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 67 | 2600190057 | |||
| Cupped Washer | ||||
| 70 | 2600500014 | 1.49 | 1.80 | |
| O-Ring | ||||
| 71 | 1900210117 | 3.44 | 4.16 | |
| Spring retaining ring | ||||
| 72 | 2916660008 | 2.08 | 2.52 | |
| No longer available, no replacement | ||||
| 73 | 2600400008 | |||
| O-Ring | ||||
| 75 | 1900210000 | 1.49 | 1.80 | |
| Felt Strip | ||||
| 76 | 2601005011 | 2.08 | 2.52 | |
| Felt Strip | ||||
| 77 | 2601005016 | 1.49 | 1.80 | |
| Retaining ring | ||||
| 81 | 2604601004 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 82 | 2603421208 | |||
| No longer available, no replacement | ||||
| 90 | 2604448060 | |||
| No longer available, no replacement | ||||
| 91 | 2604448045 | |||
| Connecting Cable | ||||
| 92 | 2604448034 | 1.49 | 1.80 | |
| Connecting Cable | ||||
| 93 | 2604448132 | 1.00 | 1.21 | |
| Connecting Cable | ||||
| 94 | 2604448115 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 95 | 2604448170 | |||
| No longer available, no replacement | ||||
| 654 | 2607000122 | |||
| Auxiliary Handle | ||||
| 753 | 1619PB4323 | 9.67 | 11.70 | |
| Hex Nut | ||||
| 753/20 | 2915011007 | 1.00 | 1.21 | |
| Wing Screw | ||||
| 753/30 | 1613480007 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 753/50 | 2608040014 | |||
| Wing Screw | ||||
| 753/60 | 1613480008 | 1.49 | 1.80 | |
| Depth-Gauge | ||||
| 755 | 2603001019 | 1.00 | 1.21 | |
| Key Chuck | ||||
| 780 | 1608571062 | 1.00 | 1.21 | |
| Chuck Wrench | ||||
| 780/700 | 2607950007 | 6.73 | 8.14 | |
| Power supply cord | ||||
| 805 | 1607000385 | 13.13 | 15.89 | |
| Marking Plate | ||||
| 808 | 2601119002 | 2.87 | 3.47 | |
| No longer available, no replacement | ||||
| 813 | 2600917902 | |||
| No longer available, no replacement | ||||
| 816/040 | 2604321913 | |||
| No longer available, no replacement | ||||
| 816/060 | 2601329051 | |||
| Change-Over Switch | ||||
| 822 | 2607200231 | 14.94 | 18.08 | |
| Tapping Screw | ||||
| 823 | 2912401020 | 1.90 | 2.30 | |
| Toothed Shaft | ||||
| 849 | 2606309913 | 23.90 | 28.92 | |
| Locking washer | ||||
| 863 | 2916080007 | 2.40 | 2.90 | |
| Bearing Bracket | ||||
| 866 | 2605807928 | 23.90 | 28.92 | |
| Felt Washer | ||||
| 869 | 2600108000 | 1.49 | 1.80 | |
