Here you will find all available parts and drawings of the 'Bosch 060114A003 (GSB1800-2)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 060114A003 (GSB1800-2)
Spare parts list of model Bosch 060114A003 (GSB1800-2)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Housing Section | ||||
| 1 | 2605104683 | 28.56 | 34.56 | |
| Field | ||||
| 2 | 2604220689 | 18.94 | 22.92 | |
| Armature | ||||
| 3 | 2604011166 | 47.53 | 57.51 | |
| Fan | ||||
| 3/60 | 2606610029 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 4 | 2607200526 | |||
| No longer available, no replacement | ||||
| 6 | 2600707066 | |||
| Manufacturer's nameplate | ||||
| 9 | 2601117630 | 2.87 | 3.47 | |
| Needle bearing | ||||
| 14 | 2600914019 | 4.94 | 5.98 | |
| Dummy Plug | ||||
| 22 | 2601099109 | 1.00 | 1.21 | |
| Screw | ||||
| 23 | 2603490022 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 24 | 2910611002 | 1.00 | 1.21 | |
| O-Ring | ||||
| 25 | 1900210000 | 1.49 | 1.80 | |
| Damping Element | ||||
| 27 | 2603239024 | 1.00 | 1.21 | |
| Oval-Head Screw | ||||
| 28 | 2603429006 | 1.49 | 1.80 | |
| Handle Cover | ||||
| 29 | 2608040109 | 4.18 | 5.06 | |
| Drilling Spindle | ||||
| 30 | 2606135094 | 17.22 | 20.84 | |
| Locking washer | ||||
| 31 | 2600118006 | 2.08 | 2.52 | |
| Locking washer | ||||
| 31 | 2600118002 | 1.49 | 1.80 | |
| Locking washer | ||||
| 31 | 2600118001 | 1.00 | 1.21 | |
| Compression Spring | ||||
| 32 | 2604616006 | 1.49 | 1.80 | |
| groove ball bearing | ||||
| 33 | 1900905163 | 10.90 | 13.19 | |
| Cylindrical Gear | ||||
| 34 | 2606317082 | 12.82 | 15.51 | |
| Cylindrical Gear | ||||
| 35 | 2606317083 | 10.90 | 13.19 | |
| Shim | ||||
| 36 | 2600100695 | 1.49 | 1.80 | |
| Shim | ||||
| 37 | 2600101047 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 38 | 2601329072 | |||
| Retaining Washer | ||||
| 39 | 2600101084 | 1.49 | 1.80 | |
| Flat Key | ||||
| 40 | 2602300034 | 2.40 | 2.90 | |
| Guiding Plate | ||||
| 41 | 2601098031 | 1.49 | 1.80 | |
| Catch Disk | ||||
| 42 | 2600190070 | 5.81 | 7.03 | |
| Ball | ||||
| 44 | 1903230010 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 45 | 2601990001 | |||
| Pressure Plate | ||||
| 46 | 2601074003 | 1.00 | 1.21 | |
| Shim | ||||
| 52 | 2600100607 | 1.49 | 1.80 | |
| Bearing Sleeve | ||||
| 54 | 2600400027 | 4.18 | 5.06 | |
| Fork Lever | ||||
| 56 | 2601990009 | 1.00 | 1.21 | |
| Rotary Head | ||||
| 57 | 2602026091 | 4.94 | 5.98 | |
| Ratchet Cap | ||||
| 58 | 2600590006 | 1.49 | 1.80 | |
| Shim | ||||
| 59 | 2600100576 | 2.08 | 2.52 | |
| Spring retaining ring | ||||
| 60 | 2916650001 | 2.40 | 2.90 | |
| Driver Pin | ||||
| 62 | 2601335001 | 2.08 | 2.52 | |
| Shim washer | ||||
| 64 | 2600100618 | 1.00 | 1.21 | |
| Catch Disk | ||||
| 67 | 2600190071 | 6.73 | 8.14 | |
| Needle-Roller Bearing | ||||
| 68 | 2600914010 | 2.86 | 3.46 | |
| Felt Strip | ||||
| 76 | 2601005011 | 2.08 | 2.52 | |
| Felt Strip | ||||
| 77 | 2601005021 | 1.00 | 1.21 | |
| Key Chuck | ||||
| 80 | 2608571065 | 39.14 | 47.36 | |
| Pvc-Insulated Cable | ||||
| 90 | 2604448228 | 2.08 | 2.52 | |
| Pvc-Insulated Cable | ||||
| 91 | 1614431025 | 2.40 | 2.90 | |
| Plain Washer | ||||
| 96 | 2600100066 | 1.00 | 1.21 | |
| Auxiliary Handle | ||||
| 653 | 2602025118 | 13.13 | 15.89 | |
| Auxiliary Handle | ||||
| 653/120 | 1612025019 | 6.73 | 8.14 | |
| Clamping Band | ||||
| 653/124 | 1611316006 | 2.40 | 2.90 | |
| T-Head Bolt | ||||
| 653/125 | 1613490002 | 4.18 | 5.06 | |
| Support clamp | ||||
| 653/802 | 2608040176 | 6.73 | 8.14 | |
| No longer available, no replacement | ||||
| 655 | 1613001010 | |||
| Power supply cord | ||||
| 805 | 1607000385 | 13.13 | 15.89 | |
| Marking Plate | ||||
| 808 | 2601117650 | 2.87 | 3.47 | |
| Ball Bearing | ||||
| 813 | 2600905032 | 4.94 | 5.98 | |
| Brush Plate | ||||
| 816 | 2604337061 | 13.13 | 15.89 | |
| Carbon-Brush Set | ||||
| 816/04 | 2609160125 | 6.73 | 8.14 | |
| Tapping Screw | ||||
| 819 | 2910611006 | 1.49 | 1.80 | |
| Toothed Shaft | ||||
| 849 | 2606309935 | 18.94 | 22.92 | |
| Locking washer | ||||
| 863 | 2916080007 | 2.40 | 2.90 | |
| Bearing Bracket | ||||
| 866 | 2605807934 | 23.90 | 28.92 | |
| Chuck Wrench | ||||
| 881 | 2607950007 | 6.73 | 8.14 | |
| Fastening parts kit | ||||
| 890 | 2607001305 | 4.18 | 5.06 | |
| Cross Recessed-Head Screw | ||||
| 891 | 2603410046 | 2.08 | 2.52 | |
