Here you will find all available parts and drawings of the 'Bosch 3601A48600 (GSB16RE)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 3601A48600 (GSB16RE)
Spare parts list of model Bosch 3601A48600 (GSB16RE)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Housing Section | ||||
| 1 | 2605104711 | 31.42 | 38.02 | |
| Field | ||||
| 2 | 2604220689 | 18.94 | 22.92 | |
| No longer available, no replacement | ||||
| 3 | 2604011254 | |||
| Fan | ||||
| 3/9 | 2606610093 | 2.86 | 3.46 | |
| Switch | ||||
| 4 | 2607200556 | 27.81 | 33.65 | |
| Power supply cord | ||||
| 5 | 1607000386 | 18.94 | 22.92 | |
| No longer available, no replacement | ||||
| 6 | 2600707066 | |||
| Manufacturer's nameplate | ||||
| 9 | 2601116655 | 3.44 | 4.16 | |
| No longer available, no replacement | ||||
| 16 | 2604337115 | |||
| Reference Plate | ||||
| 20 | 2601117427 | 4.94 | 5.98 | |
| Tapping Screw | ||||
| 22 | 2910611002 | 1.00 | 1.21 | |
| O-Ring | ||||
| 24 | 1900210000 | 1.49 | 1.80 | |
| Change-Over Switch | ||||
| 25 | 2602098008 | 1.00 | 1.21 | |
| Damping Element | ||||
| 27 | 2603239024 | 1.00 | 1.21 | |
| Handle Cover | ||||
| 28 | 2608040177 | 4.94 | 5.98 | |
| Indexing Disk | ||||
| 30/38 | 2601990027 | 1.49 | 1.80 | |
| Pressure Plate | ||||
| 30/39 | 2601074004 | 1.00 | 1.21 | |
| Ball | ||||
| 30/40 | 1903230009 | 1.00 | 1.21 | |
| Compression Spring | ||||
| 30/41 | 2604616006 | 1.49 | 1.80 | |
| Key Chuck | ||||
| 30/46 | 2608571065 | 39.14 | 47.36 | |
| Frame | ||||
| 30/47 | 2608040120 | 2.40 | 2.90 | |
| Contact Strap | ||||
| 53 | 2601329043 | 2.40 | 2.90 | |
| Pvc-Insulated Cable | ||||
| 55 | 1614431025 | 2.40 | 2.90 | |
| Pvc-Insulated Cable | ||||
| 56 | 2604448228 | 2.08 | 2.52 | |
| Auxiliary Handle | ||||
| 654 | 2602025118 | 13.13 | 15.89 | |
| Depth-Gauge | ||||
| 655 | 1613001009 | 3.44 | 4.16 | |
| Marking Plate | ||||
| 808 | 2601115234 | 3.44 | 4.16 | |
| Ball Bearing | ||||
| 813 | 2600905032 | 4.94 | 5.98 | |
| No longer available, no replacement | ||||
| 816 | 2604321946 | |||
| Tapping Screw | ||||
| 819 | 2910611006 | 1.49 | 1.80 | |
| Tapping Screw | ||||
| 826 | 2910611020 | 1.49 | 1.80 | |
| Drilling Spindle | ||||
| 831 | 2606135932 | 23.90 | 28.92 | |
| Bearing Bracket | ||||
| 833 | 2605807937 | 18.94 | 22.92 | |
| Gear Cover | ||||
| 836 | 2605808084 | 3.44 | 4.16 | |
| Flanged Bearing | ||||
| 837 | 2605805009 | 12.82 | 15.51 | |
| Shim | ||||
| 842 | 2600101047 | 1.49 | 1.80 | |
| Chuck Wrench | ||||
| 848 | 2607950007 | 6.73 | 8.14 | |
| Fastening parts kit | ||||
| 890 | 2607001305 | 4.18 | 5.06 | |
| Cross Recessed-Head Screw | ||||
| 891 | 2603410046 | 2.08 | 2.52 | |
