Here you will find all available parts and drawings of the 'Bosch 3601F4C008 ( GSA900E )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Bosch 3601F4C008 ( GSA900E )

Spare parts list of model Bosch 3601F4C008 ( GSA900E )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Power supply cord
1 2610927651 26.84 32.48
Grommet
2 2610938453 0.83 1.00
Screw
3 2610923220 0.83 1.00
Clamp
4 2610921077 0.83 1.00
Screw
5 2610923221 0.83 1.00
Screw
6 2610923222 0.83 1.00
connecting terminal
9 2610353428 0.83 1.00
Screw
12 2610998574 0.83 1.00
Cable
13 2610921102 0.83 1.00
Screw
17 2610923223 0.83 1.00
Connector
18 2610921103 0.83 1.00
Nameplate
19 2610930974 2.71 3.28
No longer available, no replacement
29 2610927561
Baffle
30 2610938454 0.83 1.00
Rubber Bushing
32 2610921082 0.83 1.00
Ball Bearing
33 2610921079 4.70 5.69
Motor Housing
34 2610938457 26.84 32.48
Armature 220-230V
35 2610927562 73.72 89.20
Bearing Plate
36 2610938458 4.70 5.69
Ball Bearing
37 2610921080 6.54 7.91
Retaining snap ring
38 2610380120 0.83 1.00
Washer
39 2610921084 0.83 1.00
Seal
40 2610921085 0.83 1.00
Screw
41 2610938459 0.83 1.00
Gear Housing
42 2610938460 33.45 40.47
Washer
44 2610938462 0.83 1.00
Shim
45 2610938463 0.83 1.00
Ball Bearing
46 2610938464 7.58 9.17
Retaining snap ring
47 2610938465 0.83 1.00
Base Plate
55 2610921088 2.71 3.28
No longer available, no replacement
56 2610921089
Screw
57 2610923217 0.83 1.00
Screw
58 2610923218 0.83 1.00
Cover
63 2610921091 15.71 19.01
Collar
68 2610921093 0.83 1.00
Screw
69 2610923216 0.83 1.00
Collar
70 2610921094 0.83 1.00
Locating ring
71 2610921095 0.83 1.00
Collar
72 2610921096 13.93 16.86
End Plate
73 2610921097 0.83 1.00
Washer
90 2610921101 0.83 1.00
No longer available, no replacement
91 2610923219
Screw
92 2610923222 0.83 1.00
Rubber Plug
94 2610923225 0.83 1.00
Suppression Filter
95 2610927566 4.70 5.69
Choke
96 2610927567 0.83 1.00
Shim Plate
110 2610941383 0.83 1.00
Handle
201 2610921083 20.42 24.71
No longer available, no replacement
202 2610927563
Carbon-Brush Set
203 2610921078 9.53 11.53
Hook
204 2610921104 4.70 5.69
No longer available, no replacement
205 2610921086
No longer available, no replacement
206 2610921090
Locking Lever
207 2610921092 1.94 2.35
No longer available, no replacement
208 2610921098
No longer available, no replacement
209 2610921099
No longer available, no replacement
213 2610933676
Bevel Gear Set
214 2610941222 49.56 59.97
