Here you will find all available parts and drawings of the 'Bosch 3601F45R00 ( GSA36V-LI )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 3601F45R00 ( GSA36V-LI )
Spare parts list of model Bosch 3601F45R00 ( GSA36V-LI )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motor Housing | ||||
| 1 | 1619P14652 | 8.45 | 10.22 | |
| Pole housing 14;4-24V | ||||
| 2 | 2610942109 | 18.19 | 22.01 | |
| Armature | ||||
| 3 | 2610944295 | 55.25 | 66.85 | |
| Electronics Module | ||||
| 4 | 1607233545 | 101.94 | 123.35 | |
| Ball Bearing | ||||
| 13 | 1619P01511 | 5.33 | 6.45 | |
| groove ball bearing 6000-2RS DIN 625 | ||||
| 14 | 1900905173 | 4.10 | 4.96 | |
| Screw ST3,9x19 | ||||
| 19 | 2610315386 | 1.18 | 1.43 | |
| Spiral Spring | ||||
| 21 | 1619P14306 | 2.71 | 3.28 | |
| Rubber Ring | ||||
| 22 | 1619P01127 | 0.83 | 1.00 | |
| Label | ||||
| 23 | 2610944085 | 1.94 | 2.35 | |
| Set Of Handles | ||||
| 27 | 2610942115 | 13.93 | 16.86 | |
| Protective Washer | ||||
| 28 | 2610908804 | 1.94 | 2.35 | |
| mat seal | ||||
| 29 | 2610934995 | 2.71 | 3.28 | |
| Front Housing | ||||
| 31 | 2610935103 | 15.71 | 19.01 | |
| Sintered-Metal Bushing | ||||
| 35 | 2610934999 | 4.10 | 4.96 | |
| Spindle Assembly | ||||
| 36 | 2610944393 | 26.84 | 32.48 | |
| Spring Retaining Plate | ||||
| 37 | 2610935431 | 1.70 | 2.06 | |
| Felt Washer SP 14,0 | ||||
| 39 | 2610030004 | 1.70 | 2.06 | |
| Shaft Seal | ||||
| 40 | 2610995815 | 7.58 | 9.17 | |
| Plastic Collar | ||||
| 41 | 2610935004 | 1.94 | 2.35 | |
| Bearing Shell | ||||
| 42 | 2610908698 | 5.83 | 7.05 | |
| Conversion Gear | ||||
| 43 | 2610942118 | 18.19 | 22.01 | |
| Supporting foot | ||||
| 45 | 2610935005 | 6.54 | 7.91 | |
| Compression Spring | ||||
| 47 | 2610937437 | 1.70 | 2.06 | |
| Insulating Sleeve | ||||
| 48 | 2610935008 | 15.71 | 19.01 | |
| Wobble Plate | ||||
| 50 | 2610938887 | 40.61 | 49.14 | |
| Retaining Plate | ||||
| 53 | 2610935010 | 1.70 | 2.06 | |
| groove ball bearing 15x32x9 | ||||
| 61 | 1900905162 | 13.93 | 16.86 | |
| Trunnion | ||||
| 62 | 2610918051 | 1.18 | 1.43 | |
| Push-Button | ||||
| 76 | 2610942123 | 1.94 | 2.35 | |
| Compression Spring | ||||
| 77 | 1614610015 | 3.31 | 4.01 | |
| Baffle | ||||
| 82 | 2610935014 | 5.33 | 6.45 | |
| Switch Slide | ||||
| 85 | 2610942122 | 1.70 | 2.06 | |
| Leaf Spring | ||||
| 86 | 2610942782 | 1.18 | 1.43 | |
| Screw | ||||
| 88 | 1619P01446 | 0.83 | 1.00 | |
| Torx Oval-Head Screw | ||||
| 89 | 1619P06252 | 1.18 | 1.43 | |
| Thread-forming tap. Screw DIN 7500, M4x10, SR10.2 | ||||
| 90 | 1603435068 | 1.18 | 1.43 | |
| Screw BLACK | ||||
| 91 | 1619P01932 | 0.83 | 1.00 | |
| Screw | ||||
| 92 | 1619P01447 | 0.83 | 1.00 | |
| Screw BLACK | ||||
| 93 | 1619P01931 | 0.83 | 1.00 | |
| Fastener | ||||
| 94 | 2610944271 | 2.24 | 2.71 | |
| Battery Pack 36V, 2,0Ah, LI | ||||
| 651 | 2607336003 | 342.01 | 413.83 | |
| Battery Pack 36V 2,0 Ah Li | ||||
| 651 | 2607336913 | 187.62 | 227.02 | |
| Charger EU GAL 3680 CV 230/14,4-36V | ||||
| 653 | 2607226457 | 148.65 | 179.87 | |
| Charger GB GAL 3680 CV 230/14,4-26V | ||||
| 653 | 2607226459 | 113.29 | 137.08 | |
| Fast Charger | ||||
| 653 | 2607225103 | 106.68 | 129.08 | |
| Fast Charger AUS AL 36V-20 | ||||
| 653 | 2607226277 | 55.25 | 66.85 | |
| Contact retainer | ||||
| 804 | 1609280425 | 12.41 | 15.02 | |
| Nameplate | ||||
| 808 | 1619P31789 | 1.94 | 2.35 | |
| Carbon-Brush Set | ||||
| 810 | 2610943623 | 9.53 | 11.53 | |
| Bearing Plate | ||||
| 830 | 2610945335 | 29.75 | 36.00 | |
| Toolholder | ||||
| 857 | 2610920684 | 18.19 | 22.01 | |
| Hook | ||||
| 870 | 2610945336 | 9.53 | 11.53 | |
| Rubber Buffer | ||||
| 883 | 3602391503 | 1.70 | 2.06 | |
