Here you will find all available parts and drawings of the 'Bosch 0601594303 (GHO26-82)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0601594303 (GHO26-82)
Spare parts list of model Bosch 0601594303 (GHO26-82)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Field | ||||
| 2 | 2604220480 | 20.39 | 24.67 | |
| Switch | ||||
| 4 | 1607200158 | 8.35 | 10.10 | |
| Power supply cord | ||||
| 5 | 1607000386 | 18.94 | 22.92 | |
| Grommet | ||||
| 6 | 2600703017 | 2.40 | 2.90 | |
| Manufacturer's nameplate | ||||
| 9 | 2609130771 | 2.18 | 2.64 | |
| Suppression Filter | ||||
| 12 | 2609120049 | 2.40 | 2.90 | |
| Carbon Brush Holder | ||||
| 16 | 2604449055 | 2.08 | 2.52 | |
| Cover | ||||
| 17 | 2609100087 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 19 | 2912401420 | 1.00 | 1.21 | |
| Screw | ||||
| 20 | 2609110155 | 1.00 | 1.21 | |
| Adjusting Nut | ||||
| 26 | 2609110131 | 4.18 | 5.06 | |
| Pulley | ||||
| 28 | 2609110268 | 2.86 | 3.46 | |
| Pulley | ||||
| 29 | 2609110267 | 4.18 | 5.06 | |
| Rotary Knob | ||||
| 30 | 2609100186 | 8.48 | 10.26 | |
| V-Belt | ||||
| 31 | 2609100410 | 8.48 | 10.26 | |
| Gear Cover | ||||
| 32 | 2609100024 | 3.44 | 4.16 | |
| Compression Spring | ||||
| 33 | 2609110077 | 2.40 | 2.90 | |
| Brush-Cover | ||||
| 35 | 2609100023 | 6.73 | 8.14 | |
| Cap-Handle | ||||
| 37 | 2609100140 | 4.58 | 5.54 | |
| Ratchet Disc | ||||
| 38 | 2609110162 | 2.40 | 2.90 | |
| Air-Deflector Ring | ||||
| 40 | 2609100028 | 2.40 | 2.90 | |
| Contact Strap | ||||
| 41 | 2601329053 | 1.49 | 1.80 | |
| Coiled Spring Pin | ||||
| 43 | 2917800053 | 2.08 | 2.52 | |
| Square Nut | ||||
| 44 | 2603320004 | 1.49 | 1.80 | |
| Ratchet Spring | ||||
| 47 | 2601254000 | 1.49 | 1.80 | |
| Handle Cover | ||||
| 49 | 2609100022 | 7.46 | 9.03 | |
| Connecting Cable | ||||
| 57 | 2604448181 | 2.08 | 2.52 | |
| Connecting Cable | ||||
| 58 | 2604448118 | 1.49 | 1.80 | |
| Deflector Pipe | ||||
| 60 | 2609100148 | 10.90 | 13.19 | |
| Planing Knife | ||||
| 74 | 2608635341 | 13.90 | 16.82 | |
| Accessory Set | ||||
| 75 | 2603340016 | 0.83 | 1.00 | |
| Gripping Wedge | ||||
| 76 | 2603111001 | 12.82 | 15.51 | |
| Knife Guard | ||||
| 80 | 2609100088 | 3.71 | 4.49 | |
| Spring | ||||
| 81 | 2609110109 | 2.52 | 3.05 | |
| Offset Screwdriver | ||||
| 654 | 1907950003 | 2.40 | 2.90 | |
| Stop Bracket | ||||
| 656 | 2608005015 | 10.90 | 13.19 | |
| Suction Connector | ||||
| 657 | 2605702023 | 5.61 | 6.79 | |
| O-Ring | ||||
| 657/1 | 1610210043 | 1.49 | 1.80 | |
| Plain Washer | ||||
| 657/2 | 2916011014 | 1.00 | 1.21 | |
| Wing Screw | ||||
| 657/3 | 2603480003 | 2.40 | 2.90 | |
| Stop Bracket | ||||
| 657/4 | 1601332018 | 3.44 | 4.16 | |
| Round-Head Bolt | ||||
| 657/5 | 2910281201 | 1.00 | 1.21 | |
| Wing Nut | ||||
| 657/6 | 2609199008 | 1.49 | 1.80 | |
| Motor Housing | ||||
| 801 | 2609199578 | 61.93 | 74.94 | |
| Armature | ||||
| 803 | 2609199269 | 39.14 | 47.36 | |
| Power supply cord | ||||
| 805 | 1607000227 | 23.90 | 28.92 | |
| Nameplate | ||||
| 808 | 160111A3H3 | 2.40 | 2.90 | |
| Carbon Brush | ||||
| 810 | 2609120398 | 10.90 | 13.19 | |
| groove ball bearing | ||||
| 813 | 2600905086 | 5.81 | 7.03 | |
| No longer available, no replacement | ||||
| 814 | 2600905052 | |||
| Bearing Flange | ||||
| 825 | 2609110175 | 37.50 | 45.38 | |
| groove ball bearing | ||||
| 827 | 2600905086 | 5.81 | 7.03 | |
| groove ball bearing | ||||
| 855 | 2600905064 | 10.90 | 13.19 | |
| Planer Head | ||||
| 870 | 2609110193 | 64.67 | 78.25 | |
