Here you will find all available parts and drawings of the 'Bosch 0601214003 (GGS6)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0601214003 (GGS6)
Spare parts list of model Bosch 0601214003 (GGS6)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motor Housing | ||||
| 1 | 3605108092 | 26.62 | 32.21 | |
| Armature | ||||
| 3 | 1619P13611 | 41.30 | 49.97 | |
| Fan | ||||
| 3/50 | 1606610122 | 2.86 | 3.46 | |
| Pan head screw | ||||
| 4/10 | 2910091120 | 1.00 | 1.21 | |
| Grommet | ||||
| 6 | 3600703011 | 2.86 | 3.46 | |
| Fastening Clamp | ||||
| 7 | 1601302013 | 1.49 | 1.80 | |
| Suppression Filter | ||||
| 11 | 3607328003 | 3.04 | 3.68 | |
| No longer available, no replacement | ||||
| 15 | 1605703065 | |||
| Threaded Ring | ||||
| 16 | 1603344005 | 27.81 | 33.65 | |
| groove ball bearing | ||||
| 17 | 1900900352 | 27.81 | 33.65 | |
| Spindle Bearing | ||||
| 18 | 3605806084 | 166.62 | 201.61 | |
| Grinding Spindle | ||||
| 19 | 3603160000 | 75.38 | 91.21 | |
| Rubber Ring | ||||
| 21 | 1600206029 | 2.40 | 2.90 | |
| Rotary shaft lip seal | ||||
| 22 | 3600290083 | 2.86 | 3.46 | |
| Rotary shaft lip seal | ||||
| 22 | 1600290016 | 2.40 | 2.90 | |
| Rotary shaft lip seal | ||||
| 22/1 | 3600290083 | 2.86 | 3.46 | |
| O-Ring | ||||
| 23 | 1600210031 | 1.00 | 1.21 | |
| Intermediate Ring | ||||
| 24 | 1600221003 | 2.40 | 2.90 | |
| Tapping Screw | ||||
| 27 | 2910211019 | 1.00 | 1.21 | |
| Round Nut | ||||
| 28 | 1603345034 | 0.83 | 1.00 | |
| Cover Plate | ||||
| 29 | 1601037007 | 1.49 | 1.80 | |
| Grommet | ||||
| 30 | 1600306001 | 2.40 | 2.90 | |
| Intermediate Ring | ||||
| 31 | 1600502011 | 2.40 | 2.90 | |
| Control Lever | ||||
| 32 | 1602026030 | 9.67 | 11.70 | |
| Felt Washer | ||||
| 32/8 | 1600205008 | 1.49 | 1.80 | |
| Retaining ring | ||||
| 33 | 2916600009 | 1.00 | 1.21 | |
| Seal | ||||
| 34 | 1600113013 | 1.49 | 1.80 | |
| Handle | ||||
| 35 | 3605132024 | 26.62 | 32.21 | |
| Cylindrical Gear | ||||
| 36 | 3606320015 | 67.98 | 82.26 | |
| Intermediate Ring | ||||
| 37 | 1600300090 | 3.44 | 4.16 | |
| groove ball bearing | ||||
| 38 | 3600905131 | 10.90 | 13.19 | |
| Woodruff Key | ||||
| 40 | 1900023006 | 2.40 | 2.90 | |
| Tapping Screw | ||||
| 41 | 1603435012 | 1.49 | 1.80 | |
| Compression Spring | ||||
| 43 | 1604613006 | 1.49 | 1.80 | |
| Ball Bearing | ||||
| 44 | 2600905032 | 4.94 | 5.98 | |
| Sealing Cord | ||||
| 45 | 1601014000 | 2.86 | 3.46 | |
| Socket head cap screw | ||||
| 47 | 2910021118 | 1.00 | 1.21 | |
| Spiral Spring | ||||
| 48 | 1604652006 | 1.49 | 1.80 | |
| Tapping Screw | ||||
| 49 | 2910211011 | 1.00 | 1.21 | |
| Torx Oval-Head Screw | ||||
| 50 | 2914201531 | 1.00 | 1.21 | |
| Plain Washer | ||||
| 51 | 2916011005 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 52 | 2910211006 | 1.00 | 1.21 | |
| Intermediate Bearing | ||||
| 53 | 3605820045 | 91.33 | 110.51 | |
| Intermediate Bearing | ||||
| 53 | 1607000FF6 | 64.67 | 78.25 | |
| Wire Guide | ||||
| 54 | 3601025003 | 1.49 | 1.80 | |
| Air-Deflector Ring | ||||
| 55 | 1600502019 | 3.44 | 4.16 | |
| Sticker | ||||
| 56 | 3601110124 | 6.22 | 7.53 | |
| Tab Washer | ||||
| 90 | 1601030022 | 1.49 | 1.80 | |
| Shrinkable Tube | ||||
| 150 | 3600707022 | 3.44 | 4.16 | |
| Blade terminal | ||||
| 152 | 1604477001 | 1.49 | 1.80 | |
| Connecting Cable | ||||
| 153 | 3604438029 | 8.48 | 10.26 | |
| Pin-Type Face-Wrench | ||||
| 650/1 | 1607950061 | 4.18 | 5.06 | |
| Pin-Type Face-Wrench | ||||
| 650/1 | F000632033 | 2.40 | 2.90 | |
| Holding Pin | ||||
| 650/2 | 3603101005 | 4.94 | 5.98 | |
| Offset Screwdriver | ||||
| 650/3 | 1907950007 | 4.94 | 5.98 | |
| Protective Cover | ||||
| 653 | 3605510030 | 26.62 | 32.21 | |
| No longer available, no replacement | ||||
| 653/5 | 2910141240 | |||
| Field | ||||
| 802 | 3604220134 | 50.23 | 60.78 | |
| No longer available, no replacement | ||||
| 804 | 1607000034 | |||
| Power supply cord | ||||
| 805 | 1607000228 | 23.90 | 28.92 | |
| Nameplate | ||||
| 808 | 160111A3H3 | 2.40 | 2.90 | |
| Carbon-Brush Set | ||||
| 810 | 3607014012 | 23.90 | 28.92 | |
| Cartridge bearing | ||||
| 820 | 3604441011 | 30.08 | 36.40 | |
| Sealing cap | ||||
| 826 | 3605500063 | 4.21 | 5.09 | |
| Sealing cap | ||||
| 826 | 3605500060 | 1.49 | 1.80 | |
| Brush Holder | ||||
| 839 | 3604336012 | 5.81 | 7.03 | |
| Connecting Cable | ||||
| 853 | 3604438001 | 6.53 | 7.90 | |
| Wire Guide | ||||
| 854 | 3601025003 | 1.49 | 1.80 | |
| Wire Guide | ||||
| 854 | 1601025001 | 1.32 | 1.60 | |
