Here you will find all available parts and drawings of the 'Bosch 0601120503 (GBM16-2RE)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0601120503 (GBM16-2RE)
Spare parts list of model Bosch 0601120503 (GBM16-2RE)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motor Housing | ||||
| 1 | 3605108092 | 26.62 | 32.21 | |
| Armature | ||||
| 3 | 1619P13609 | 41.30 | 49.97 | |
| No longer available, no replacement | ||||
| 4 | 1607200075 | |||
| Grommet | ||||
| 6 | 1600703022 | 2.86 | 3.46 | |
| Fastening Clamp | ||||
| 7 | 1601302014 | 2.18 | 2.64 | |
| Manufacturer's nameplate | ||||
| 9 | 3601110514 | 2.18 | 2.64 | |
| No longer available, no replacement | ||||
| 11 | 1607328028 | |||
| Sealing Plate | ||||
| 12 | 1601015013 | 1.49 | 1.80 | |
| Switch | ||||
| 16 | 3607200000 | 17.60 | 21.30 | |
| Spiral Spring | ||||
| 18 | 1604652006 | 1.49 | 1.80 | |
| Tapping Screw | ||||
| 19 | 2910211006 | 1.00 | 1.21 | |
| Intermediate Ring | ||||
| 20 | 1600502011 | 2.40 | 2.90 | |
| Ball Bearing | ||||
| 21 | 2600905032 | 4.94 | 5.98 | |
| Sealing cap | ||||
| 22 | 3605500063 | 4.21 | 5.09 | |
| Air-Deflector Ring | ||||
| 23 | 1600502019 | 3.44 | 4.16 | |
| Intermediate Ring | ||||
| 24 | 1600300090 | 3.44 | 4.16 | |
| Bearing cover | ||||
| 27 | 3605500034 | 5.96 | 7.21 | |
| groove ball bearing | ||||
| 28 | 3600905131 | 10.90 | 13.19 | |
| Intermediate Ring | ||||
| 31 | 1600221003 | 2.40 | 2.90 | |
| Socket head cap screw | ||||
| 33 | 2910021118 | 1.00 | 1.21 | |
| Toothed Shaft | ||||
| 39 | 1606309063 | 45.52 | 55.08 | |
| Compression Spring | ||||
| 40 | 1604611022 | 1.49 | 1.80 | |
| Ball | ||||
| 41 | 1903230009 | 1.00 | 1.21 | |
| Cylindrical Gear | ||||
| 42 | 1606317074 | 31.42 | 38.02 | |
| Cylindrical Gear | ||||
| 43 | 1606317082 | 39.14 | 47.36 | |
| Needle bearing | ||||
| 44 | 1600910013 | 5.81 | 7.03 | |
| Pinion Shaft | ||||
| 45 | 1606309065 | 98.18 | 118.80 | |
| Cylindrical Gear | ||||
| 45/20 | 1606320077 | 22.88 | 27.68 | |
| Shim | ||||
| 46 | 1600100631 | 1.49 | 1.80 | |
| Shim | ||||
| 47 | 1600101647 | 2.08 | 2.52 | |
| Control Shaft | ||||
| 48 | 1606325025 | 2.86 | 3.46 | |
| Notched Plate | ||||
| 49 | 1601038025 | 1.49 | 1.80 | |
| Control Lever | ||||
| 50 | 1602026044 | 7.46 | 9.03 | |
| Control Shaft | ||||
| 51 | 1606325027 | 8.35 | 10.10 | |
| O-Ring | ||||
| 52 | 1900210105 | 1.49 | 1.80 | |
| Needle-Roller Bearing | ||||
| 54 | 2600910001 | 4.18 | 5.06 | |
| Drilling Spindle | ||||
| 56 | 3603523016 | 50.23 | 60.78 | |
| groove ball bearing | ||||
| 57 | 1900905162 | 16.79 | 20.32 | |
| Retaining clip | ||||
| 58 | 2916650006 | 1.49 | 1.80 | |
| Cylindrical Gear | ||||
| 60 | 1606317080 | 26.62 | 32.21 | |
| Compression Spring | ||||
| 63 | 1604613006 | 1.49 | 1.80 | |
| Connecting Cable | ||||
| 66 | 3604438027 | 9.67 | 11.70 | |
| Wire Guide | ||||
| 67 | 3601025003 | 1.49 | 1.80 | |
| Connecting Cable | ||||
| 68 | 3604460027 | 6.73 | 8.14 | |
| Torx Oval-Head Screw | ||||
| 69 | 2914201527 | 2.08 | 2.52 | |
| Lens Head Screw | ||||
| 71 | 3603435042 | 1.32 | 1.60 | |
| Socket head cap screw | ||||
| 72 | 2910021118 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 73 | 2910211019 | 1.00 | 1.21 | |
| Torx Oval-Head Screw | ||||
| 74 | 2914201507 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 75 | 2910211018 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 76 | 2910211019 | 1.00 | 1.21 | |
| Countersunk-Head Screw | ||||
| 77 | 2910501120 | 1.00 | 1.21 | |
| Connecting Cable | ||||
| 78 | 1604412053 | 4.58 | 5.54 | |
| Connecting Cable | ||||
| 79 | 3604412002 | 6.53 | 7.90 | |
| Connecting Cable | ||||
| 80 | 3604438022 | 7.32 | 8.86 | |
| Suppression Filter | ||||
| 81 | 3604503008 | 7.32 | 8.86 | |
| Suppression Filter | ||||
| 82 | 3604503007 | 8.48 | 10.26 | |
| Tab Washer | ||||
| 90 | 1601030022 | 1.49 | 1.80 | |
| Bushing | ||||
| 100 | 3600328033 | 6.53 | 7.90 | |
| Straight Pin | ||||
| 102 | 2917500121 | 1.00 | 1.21 | |
| Chuck | ||||
| 103 | 3608571003 | 82.63 | 99.98 | |
| Chuck Wrench | ||||
| 103/1 | 3607950018 | 8.48 | 10.26 | |
| Hex Nut | ||||
| 104 | 2915031057 | 1.00 | 1.21 | |
| Auxiliary Handle | ||||
| 650 | 3602025021 | 43.12 | 52.18 | |
| Auxiliary Handle | ||||
| 650/1 | 1612025022 | 0.83 | 1.00 | |
| No longer available, no replacement | ||||
| 650/2 | 1618040077 | |||
| Stud bolt | ||||
| 650/3 | 1613521001 | 5.81 | 7.03 | |
| Clamping Band | ||||
| 650/4 | 3601038048 | 16.79 | 20.32 | |
| Straight Pin | ||||
| 650/5 | 1613100012 | 2.40 | 2.90 | |
| Handle Bar | ||||
| 650/8 | 3602025022 | 16.79 | 20.32 | |
| Depth-Gauge | ||||
| 652 | 1613001008 | 8.35 | 10.10 | |
| Field | ||||
| 802 | 3604220118 | 75.38 | 91.21 | |
| Power supply cord | ||||
| 805 | 1607000391 | 18.94 | 22.92 | |
| Nameplate | ||||
| 808 | 160111A3H3 | 2.40 | 2.90 | |
| Carbon-Brush Set | ||||
| 810 | 3607014012 | 23.90 | 28.92 | |
| Handle | ||||
| 815 | 3605133015 | 20.39 | 24.67 | |
| Brush Holder | ||||
| 817 | 3604336012 | 5.81 | 7.03 | |
| Rotary shaft lip seal | ||||
| 835 | 3600290070 | 10.68 | 12.92 | |
| Intermediate Bearing | ||||
| 837 | 3607030437 | 102.63 | 124.18 | |
| Spindle Bearing | ||||
| 855 | 1605806368 | 82.63 | 99.98 | |
| Retaining snap ring | ||||
| 861 | 3607030355 | 16.79 | 20.32 | |
| Connecting Cable | ||||
| 866 | 1604438013 | 7.46 | 9.03 | |
| Wire Guide | ||||
| 867 | 3601025003 | 1.49 | 1.80 | |
| Wire Guide | ||||
| 867 | 1601025001 | 1.32 | 1.60 | |
| Connecting Cable | ||||
| 868 | 1604438012 | 7.46 | 9.03 | |
| Connecting Cable | ||||
| 880 | 3604460010 | 2.38 | 2.88 | |
