Here you will find all available parts and drawings of the 'Bosch 3611B661E0 ( GBH12-52D )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 3611B661E0 ( GBH12-52D )
Spare parts list of model Bosch 3611B661E0 ( GBH12-52D )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Motor Housing | ||||
| 1 | 1615108172 | 37.50 | 45.38 | |
| Field 230V | ||||
| 2 | 160422023P | 82.63 | 99.98 | |
| Switch | ||||
| 4 | 1617200130 | 41.30 | 49.97 | |
| Power supply cord BR 220V 4,15m 2 x 1,0mm H07 RN- | ||||
| 5 | 1614460094 | 20.39 | 24.67 | |
| Grommet Ø9,7-Ø12x89 MM | ||||
| 6 | 1610703053 | 2.18 | 2.64 | |
| Fastening Clamp | ||||
| 7 | 1601302018 | 1.32 | 1.60 | |
| Manufacturer's nameplate | ||||
| 9 | 160111C065 | 2.18 | 2.64 | |
| Fan | ||||
| 15 | 1616610114 | 10.68 | 12.92 | |
| Clamp ring | ||||
| 16 | 1600A0015D | 2.18 | 2.64 | |
| Toolholder | ||||
| 20 | 1618597105 | 146.07 | 176.74 | |
| Protective Cap | ||||
| 21 | 1600A001XC | 4.58 | 5.54 | |
| Protection Sleeve | ||||
| 22 | 1610591054 | 7.32 | 8.86 | |
| Stop Sleeve | ||||
| 23 | 1610520007 | 10.68 | 12.92 | |
| Headed Bush | ||||
| 24 | 1610500026 | 5.27 | 6.38 | |
| Stopping Device | ||||
| 25 | 1612300025 | 7.32 | 8.86 | |
| Indexing Disk | ||||
| 26 | 1610290027 | 3.04 | 3.68 | |
| Air-Deflector Ring | ||||
| 27 | 1600591056 | 2.52 | 3.05 | |
| Compression Spring | ||||
| 28 | 1614621017 | 3.04 | 3.68 | |
| Damping Ring | ||||
| 31 | 1610290123 | 3.04 | 3.68 | |
| Control Bushing | ||||
| 37 | 1610322019 | 5.96 | 7.21 | |
| Covering hood | ||||
| 38 | 1600A004BM | 26.62 | 32.21 | |
| Brush-Cover | ||||
| 43 | 1615500447 | 9.47 | 11.46 | |
| Compression Spring | ||||
| 44 | 1614621016 | 3.04 | 3.68 | |
| Holding-Down-Appliance | ||||
| 45 | 1610591053 | 1.90 | 2.30 | |
| Gear Sleeve | ||||
| 47 | 1610300082 | 6.53 | 7.90 | |
| Clutch Sleeve | ||||
| 48 | 1619990179 | 8.48 | 10.26 | |
| Crown Gear | ||||
| 51 | 1616333053 | 91.33 | 110.51 | |
| Spacer Tube | ||||
| 54 | 1600A00218 | 3.71 | 4.49 | |
| Bearing Pedestal | ||||
| 59 | 1615805079 | 10.68 | 12.92 | |
| Grease Distributor | ||||
| 61 | 1600A0015E | 3.71 | 4.49 | |
| Rubber Ring | ||||
| 66 | 1600210246 | 1.90 | 2.30 | |
| Eccentric Shaft | ||||
| 67 | 1600A000XS | 13.90 | 16.82 | |
| Pickup Clip | ||||
| 68 | 1600A0015F | 1.00 | 1.21 | |
| Piston Pin | ||||
| 69 | 1613100040 | 1.90 | 2.30 | |
| Connecting Rod | ||||
| 70 | 1600A001Y6 | 20.39 | 24.67 | |
| Eccentric Cog Wheel | ||||
| 72 | 1616317622 | 26.62 | 32.21 | |
| Eccentric Bolt | ||||
| 74 | 1600A000XT | 4.58 | 5.54 | |
| Speed governor | ||||
| 80 | 1607233461 | 91.33 | 110.51 | |
| Auxiliary Handle | ||||
| 84 | 160202507H | 9.47 | 11.46 | |
| Support clamp | ||||
| 85 | 1618040097 | 7.32 | 8.86 | |
| Clamping Band | ||||
| 87 | 1611316038 | 7.32 | 8.86 | |
| Driving Pin | ||||
| 95 | 1613120025 | 4.58 | 5.54 | |
| Supporting Disc | ||||
| 99 | 1600A005BD | 6.53 | 7.90 | |
| Bushing | ||||
| 111 | 1615801027 | 4.58 | 5.54 | |
| Hex Nut | ||||
| 112 | 1613300009 | 1.90 | 2.30 | |
| Torx Oval-Head Screw | ||||
| 113 | 160343507A | 1.00 | 1.21 | |
| groove ball bearing 12x37x12 | ||||
| 116 | 1600905035 | 8.48 | 10.26 | |
| groove ball bearing | ||||
| 119 | 1600900041 | 4.58 | 5.54 | |
| Spacer bushing | ||||
| 120 | 1610190078 | 5.27 | 6.38 | |
| Plain bearing | ||||
| 121 | 1615805080 | 12.21 | 14.77 | |
| Spacer Ring | ||||
| 122 | 1610290122 | 2.52 | 3.05 | |
| Torx Oval-Head Screw | ||||
| 125 | 1613435040 | 1.90 | 2.30 | |
| Torx Oval-Head Screw 4x20 | ||||
| 126 | 2603490023 | 1.00 | 1.21 | |
| Cover | ||||
| 132 | 160550044M | 1.32 | 1.60 | |
| Felt | ||||
| 133 | 1610205016 | 1.90 | 2.30 | |
| Sealing Frame | ||||
| 138 | 1611015065 | 4.58 | 5.54 | |
| Shaft Seal | ||||
| 141 | 1610290119 | 3.71 | 4.49 | |
| Retaining ring | ||||
| 143 | 1614601071 | 1.90 | 2.30 | |
| Supporting Disc | ||||
| 144 | 1610101023 | 3.04 | 3.68 | |
| O-Ring | ||||
| 151 | 1610210236 | 1.00 | 1.21 | |
| Retaining ring | ||||
| 152 | 1614601022 | 2.18 | 2.64 | |
| Retaining ring DIN 7993-A32 | ||||
| 153 | 2916540018 | 3.04 | 3.68 | |
| Spring retaining ring DIN 472-68x2,5MM | ||||
| 154 | 2916660040 | 1.90 | 2.30 | |
| Spring retaining ring | ||||
| 155 | 1614601080 | 1.32 | 1.60 | |
| Spring retaining ring | ||||
| 156 | 160015001V | 2.52 | 3.05 | |
| O-Ring | ||||
| 157 | 1610210238 | 1.00 | 1.21 | |
| Rubber Ring | ||||
| 158 | 1610210239 | 1.32 | 1.60 | |
| Damping Ring | ||||
| 160 | 1610210240 | 2.52 | 3.05 | |
| Damping Ring | ||||
| 161 | 1610210241 | 11.02 | 13.33 | |
| O-Ring | ||||
| 162 | 1610210237 | 2.52 | 3.05 | |
| Seal Ring | ||||
| 163 | 1610210242 | 11.02 | 13.33 | |
| Seal Fastener | ||||
| 165 | 1600A000XU | 2.18 | 2.64 | |
| Cylindrical Roller | ||||
| 166 | 1613200022 | 1.32 | 1.60 | |
| Rotary shaft lip seal | ||||
| 167 | 1610290124 | 8.48 | 10.26 | |
| Seal Ring | ||||
| 168 | 1600A001XD | 2.52 | 3.05 | |
| Torx Socket Button Screw | ||||
| 170 | 1600A0015H | 1.00 | 1.21 | |
| Torx socket button screw | ||||
| 171 | 1613414026 | 2.18 | 2.64 | |
| Torx Oval-Head Screw | ||||
| 172 | 1613435041 | 1.32 | 1.60 | |
| Torx Oval-Head Screw M5x20 | ||||
| 173 | 1613490024 | 1.32 | 1.60 | |
| Torx Oval-Head Screw | ||||
| 175 | 160343507D | 1.00 | 1.21 | |
| Handle | ||||
| 189 | 161513213B | 22.88 | 27.68 | |
| Handle Cover | ||||
| 190 | 1615500438 | 13.90 | 16.82 | |
| Retaining Part | ||||
| 206 | 1612386007 | 1.32 | 1.60 | |
| Control Lever | ||||
| 209 | 1600A002ST | 3.04 | 3.68 | |
| Plug Housing | ||||
| 244 | 1600A0013J | 1.00 | 1.21 | |
| Armature assembly 230V | ||||
| 803 | 1607000C3Y | 262.05 | 317.08 | |
| Nameplate | ||||
| 808 | 160111A3H5 | 2.18 | 2.64 | |
| Carbon-Brush Set | ||||
| 810 | 1607000C3Z | 22.88 | 27.68 | |
| groove ball bearing | ||||
| 813 | 1607000C40 | 22.88 | 27.68 | |
| groove ball bearing | ||||
| 814 | 1607000C41 | 30.08 | 36.40 | |
| Tool Holder Set | ||||
| 820 | 1607000C42 | 234.56 | 283.82 | |
| Brush Holder | ||||
| 821 | 1607000C5H | 17.60 | 21.30 | |
| Hammer Pipe | ||||
| 835 | 1607000C43 | 166.62 | 201.61 | |
| Impact Mechanism Housing | ||||
| 840 | 1607000C44 | 262.05 | 317.08 | |
| Striker Pin | ||||
| 841 | 1607000C45 | 55.56 | 67.23 | |
| Control Fork | ||||
| 849 | 1607000C46 | 11.02 | 13.33 | |
| Guide Bushing | ||||
| 853 | 1607000C47 | 50.23 | 60.78 | |
| Hammer Piston | ||||
| 856 | 1607000C48 | 30.08 | 36.40 | |
| Striker | ||||
| 857 | 1607000C49 | 41.30 | 49.97 | |
| Bearing Pedestal | ||||
| 859 | 1607000C4A | 33.33 | 40.33 | |
| Spur Wheel Clutch | ||||
| 860 | 1607000C4B | 102.63 | 124.18 | |
| Eccentric | ||||
| 872 | 1607000C4C | 102.63 | 124.18 | |
| Housing Cover | ||||
| 873 | 1607000C4D | 55.56 | 67.23 | |
| Auxiliary Handle | ||||
| 884 | 1607000C4E | 37.50 | 45.38 | |
| Service package | ||||
| 899 | 1607000C4G | 75.38 | 91.21 | |
