Here you will find all available parts and drawings of the 'Bosch F016306803 ( CLASSICPETROL43S )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Bosch F016306803 ( CLASSICPETROL43S )

Spare parts list of model Bosch F016306803 ( CLASSICPETROL43S )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Protection cover LH
40/02 F016A75397 36.85 44.59
Side Cover RH
40/03 F016A75088 15.71 19.01
Protection cover
40/05 F016A75085 11.88 14.37
Cross Recessed-Head Screw M5
40/20 F016A57756 0.83 1.00
Screw M6
40/21 F016A58228 2.24 2.71
Screw M6
40/22 F016A58229 0.83 1.00
Spindle 17"
50/02 F016A75328 15.71 19.01
Ring
50/03 F016A57635 23.75 28.74
No longer available, no replacement
50/05 F016A75404
Set ring
50/21 F016A58860 1.70 2.06
Rivet Pin
50/22 F016A58178 3.31 4.01
Self-Cutting Screw 4x19 MM
50/27 F016T49429 0.83 1.00
Side Plate L/H
55/01 F016A75001 15.71 19.01
Side Plate R/H
55/02 F016A75002 26.84 32.48
Spacing Block
55/06 F016A75065 2.71 3.28
Cutter Cylinder
55/07 F016A58820 101.94 123.35
No longer available, no replacement
55/08/02 F016A58741
No longer available, no replacement
55/09 F016A58854
Sleeve
55/10 F016A58855 1.94 2.35
No longer available, no replacement
55/11 F016A58856
Toothed Gear
55/13 F016A57590 23.75 28.74
Adjusting Part
55/14 F016A57669 2.24 2.71
Adjusting Screw
55/15 F016A57713 1.94 2.35
Square Shaft
55/17 F016T41057 1.70 2.06
Nut 1/4 UNF
55/44 F016L06954 0.83 1.00
Screw M6x25 MM
55/45 F016T49288 0.83 1.00
Locking washer
55/47 F016L35389 0.83 1.00
Spring
55/49 F016T47205 1.70 2.06
Washer
55/50 F016T49443 3.31 4.01
Spindle 17"
60/02 F016L64555 33.45 40.47
Roller
60/03 F016T49531 4.70 5.69
Spacer Tube
60/06 F016A57834 1.94 2.35
Roller
60/07 F016L22149 4.10 4.96
Bushing
60/08 F016A57675 1.94 2.35
Pivot L/H
60/09 F016A57748 0.83 1.00
Cap
60/10 F016A57676 0.83 1.00
Spring
60/11 F016A57820 1.18 1.43
Spring
60/15 F016A57995 6.54 7.91
Spring Washer 5/16 SW SE
60/41 F016L35307 0.83 1.00
Plain Washer 8,5 MM
60/42 F016L35411 0.83 1.00
No longer available, no replacement
60/43 F016L35457
Hex Screw WAS 170
60/44 F016W25213 1.94 2.35
Control Lever
65/01/08 F016A58801 13.93 16.86
Self-locking nut M6
65/01/21 F016L35388 1.94 2.35
Screw M8
65/01/22 F016A75098 0.83 1.00
Plain Washer
65/01/26 F016L35302 0.83 1.00
Self-Cutting Screw M 4x35
65/01/27 F016L35303 1.18 1.43
Plain Washer
65/01/28 F016L10198 2.24 2.71
Sealing cap PCL89/QX
65/12 F016L62783 8.45 10.22
Fuel Pipe
65/13/01 F016103787 5.83 7.05
Pipe Clamp
65/13/03 F016A57982 0.83 1.00
Drive Shaft 17"
70/01 F016A57739 18.19 22.01
Pinion Shaft
70/02 F016102295 33.45 40.47
Bushing
70/03/05 F016A57762 4.10 4.96
No longer available, no replacement
70/05/02 F016A57761
Pulley 46 MM
70/06 F016A58726 2.71 3.28
Guide Roller
70/09 F016102815 15.71 19.01
No longer available, no replacement
70/10 F016A58728
V-Belt
70/11 F016A57941 40.61 49.14
Bushing
70/19/02 F016A57764 2.71 3.28
Spacer
70/21 F016A58315 2.24 2.71
Spring
70/22 F016A58316 1.70 2.06
Coupling
70/23 F016L09518 5.33 6.45
Support
70/24 F016L66172 2.71 3.28
Spacer
70/25 F016A57780 3.31 4.01
Ball Bearing
70/28 F016A57838 12.41 15.02
Torsion Spring
70/29 F016A58531 2.24 2.71
Spring
70/30 F016A58530 1.94 2.35
Spring
70/32 F016L08487 5.83 7.05
Pivot Pin
70/34 F016A58422 5.33 6.45
Pulley
70/35 F016L09227 0.83 1.00
Spring retaining ring
70/41 F016A57759 1.18 1.43
Washer
70/42 F016A57907 0.83 1.00
Washer M16
70/43 F016A58725 1.70 2.06
Self-locking nut M8
70/44 F016L11218 0.83 1.00
Plain Washer
70/45 F016L17849 0.83 1.00
Hex Screw M6x12
70/46 F016L18120 1.70 2.06
Lock Nut M12
70/47 F016L18605 0.83 1.00
Nut M12
70/48 F016L23210 2.24 2.71
Self-Cutting Screw M6
70/51 F016L35387 0.83 1.00
Washer
70/55 F016T42988 0.83 1.00
Trunnion
70/56 F016T48017 0.83 1.00
Plain Washer 8,5 MM
70/57 F016L35316 0.83 1.00
Spare Part L/H
75/03 F016L36720 0.83 1.00
Spare Part R/H
75/04 F016L36721 0.83 1.00
Control Lever
75/05 F016A75338 11.88 14.37
Control Lever
75/06 F016A75341 7.58 9.17
Support
75/08 F016L36717 4.10 4.96
Bushing
75/09 F016L36719 1.18 1.43
Securing Cap Ø8 MM BLACK
75/10 F016T48990 0.83 1.00
Cable control
75/11 F016A58035 10.73 12.98
Cable control
75/12 F016A58036 12.41 15.02
Support Rail
75/13 F016103130 5.83 7.05
Adjusting Part
75/24 F016A58040 12.41 15.02
Nut M6
75/25 F016L35329 1.18 1.43
Screw M5x32
75/26 F016L36722 0.83 1.00
Nut M5
75/27 F016L36836 0.83 1.00
Wing Nut
75/28 F016L66136 3.31 4.01
Catcher Container
80/02 F016103791 36.85 44.59
Hexagon-Socket Key
85/02/12 F016A58230 0.83 1.00
Cable Clip
85/02/14 F016T49524 1.18 1.43
Housing
840/01 F016103205 130.32 157.69
Roller 17"
850 F016103215 187.62 227.02
Bearing Holder
850/04 F016102966 3.31 4.01
Cassette
855 F016102962 342.01 413.83
Handle
855/03 F016102978 15.71 19.01
No longer available, no replacement
855/04 F016103771
No longer available, no replacement
855/05 F016101517
Bearing Holder
855/08 F016102805 10.73 12.98
Roller Carrier
860/01 F016S50042 36.85 44.59
Knob
860/12 F016102130 0.83 1.00
Coupling
865/01/02 F016A58602 33.45 40.47
Fuel Tank
865/11 F016102376 60.65 73.39
Gear Unit
870/03 F016102377 33.45 40.47
Pulley
870/04 F016103221 36.85 44.59
Toothed Gear
870/05 F016102379 9.53 11.53
Parts Set
870/07 F016102282 29.75 36.00
Gear Support S/A
870/13 F016102977 15.71 19.01
Guide Piece
870/14 F016102818 6.54 7.91
Beltfeeder
870/17 F016103154 6.54 7.91
Bearing Holder
870/18 F016103153 13.93 16.86
Holder
870/19 F016103210 11.88 14.37
Handle
875/01 F016102804 20.42 24.71
Support Tube
880/01 F016103783 23.75 28.74
Repair Kit
8756 F016L37700 23.75 28.74
