Here you will find all available parts and drawings of the 'Bosch 0600841236 ( AHS55 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0600841236 ( AHS55 )
Spare parts list of model Bosch 0600841236 ( AHS55 )
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Housing Section | ||||
| 1 | 2605104512 | 35.58 | 43.05 | |
| No longer available, no replacement | ||||
| 2 | 2604220423 | |||
| No longer available, no replacement | ||||
| 3 | 2604010604 | |||
| Fan | ||||
| 3/60 | 2606610027 | 2.86 | 3.46 | |
| No longer available, no replacement | ||||
| 4 | 2607200316 | |||
| Power supply cord | ||||
| 5 | 2604460183 | 7.32 | 8.86 | |
| Grommet | ||||
| 6 | 2600703017 | 2.40 | 2.90 | |
| Grommet | ||||
| 6 | 2600703018 | 2.40 | 2.90 | |
| Grommet | ||||
| 6 | 2600703019 | 2.40 | 2.90 | |
| Cable Clip | ||||
| 7 | 1611035005 | 2.08 | 2.52 | |
| Manufacturer's nameplate | ||||
| 9 | 2601118397 | 2.87 | 3.47 | |
| Bushing | ||||
| 13 | 2600300077 | 2.00 | 2.42 | |
| groove ball bearing | ||||
| 14 | 2600905021 | 8.35 | 10.10 | |
| No longer available, no replacement | ||||
| 16 | 2609992625 | |||
| Torx Oval-Head Screw | ||||
| 18 | 2603490024 | 1.49 | 1.80 | |
| Screw | ||||
| 19 | 2603490022 | 1.00 | 1.21 | |
| Reference Plate | ||||
| 20 | 2601118342 | 1.24 | 1.50 | |
| Connecting Cable | ||||
| 21 | 2604448171 | 1.73 | 2.09 | |
| No longer available, no replacement | ||||
| 22 | 2604448162 | |||
| Torx Oval-Head Screw | ||||
| 23 | 2603490023 | 1.00 | 1.21 | |
| Contact Spring | ||||
| 26 | 2601329057 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 27 | 2604619013 | |||
| No longer available, no replacement | ||||
| 28 | 2600209003 | |||
| Shifter Rod | ||||
| 29 | 2608040076 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 30 | 2608001011 | |||
| Compression Spring | ||||
| 31 | 2604610028 | 1.49 | 1.80 | |
| Control Unit | ||||
| 32 | 2607230025 | 28.56 | 34.56 | |
| No longer available, no replacement | ||||
| 33/40 | 2603413032 | |||
| No longer available, no replacement | ||||
| 33/50 | 2915011006 | |||
| Straight Pin | ||||
| 34 | 2609002714 | 1.32 | 1.60 | |
| Socket-Terminal Strip | ||||
| 35 | 1901091101 | 5.61 | 6.79 | |
| O-Ring | ||||
| 36 | 1900210000 | 1.49 | 1.80 | |
| Shim | ||||
| 46 | 2600101617 | 1.49 | 1.80 | |
| Offset Screwdriver | ||||
| 654 | 1907950006 | 3.71 | 4.49 | |
| Hexagon Socket Screw Key | ||||
| 654 | 2610364015 | 3.44 | 4.16 | |
| No longer available, no replacement | ||||
| 701 | 1609200399 | |||
| Protective Glove | ||||
| 702 | 2607000134 | 0.83 | 1.00 | |
| No longer available, no replacement | ||||
| 724 | 2602025106 | |||
| Protective Shield | ||||
| 725 | 2607001192 | 6.96 | 8.42 | |
| No longer available, no replacement | ||||
| 753 | 2605411054 | |||
| Nameplate | ||||
| 808 | 160111A3H3 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 816/04 | 2607014005 | |||
| Ratchet Cap | ||||
| 816/06 | 2601322013 | 1.49 | 1.80 | |
| Connecting Cable | ||||
| 832/010 | 2604448173 | 1.24 | 1.50 | |
| Set of knives | ||||
| 833 | 2607001214 | 72.96 | 88.28 | |
| Bearing Bracket | ||||
| 838 | 2605807926 | 15.26 | 18.46 | |
| Overload Clutch | ||||
| 843 | 2606319901 | 43.21 | 52.28 | |
| Locking washer | ||||
| 845 | 2916080910 | 2.08 | 2.52 | |
