Here you will find all available parts and drawings of the 'Bosch 0600814103 (AHR1100)'. From here you can order all desired parts directly.Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:
Technical drawing of model Bosch 0600814103 (AHR1100)
Spare parts list of model Bosch 0600814103 (AHR1100)
| Pos. | Description | Price excl. VAT | Price incl. VAT | |
| Prices shown include VAT | ||||
| Upper Housing | ||||
| 1 | 1609350001 | 52.45 | 63.46 | |
| Roller | ||||
| 1/20 | 1609350003 | 9.67 | 11.70 | |
| Push-Button | ||||
| 1/30 | 1609350004 | 12.82 | 15.51 | |
| Compression Spring | ||||
| 1/40 | 1609350005 | 2.08 | 2.52 | |
| Manufacturer's nameplate | ||||
| 1/50 | 1601110972 | 3.44 | 4.16 | |
| Nameplate | ||||
| 3 | 1601118617 | 2.87 | 3.47 | |
| Raised ctsk Tapping Screw | ||||
| 6 | 1609350006 | 2.40 | 2.90 | |
| Oval-Head Screw | ||||
| 7 | 2910951162 | 4.94 | 5.98 | |
| Oval-Head Screw | ||||
| 8 | 1609350143 | 2.86 | 3.46 | |
| Sealing Cap | ||||
| 9 | 1609350092 | 4.18 | 5.06 | |
| Intermediate housing | ||||
| 10 | 1609350295 | 80.26 | 97.11 | |
| No longer available, no replacement | ||||
| 11 | 1609350415 | |||
| No longer available, no replacement | ||||
| 14 | 1609350416 | |||
| Motor Capacitor | ||||
| 17 | 1609350015 | 27.81 | 33.65 | |
| Plastic Tubing | ||||
| 18 | 1609350022 | 14.94 | 18.08 | |
| Tube Mounting | ||||
| 18/10 | 1609350023 | 14.94 | 18.08 | |
| Seal | ||||
| 18/20 | 1609350178 | 7.46 | 9.03 | |
| Flat Seal Ring | ||||
| 18/30 | 1609350179 | 2.40 | 2.90 | |
| Cup Seal | ||||
| 18/40 | 1609350180 | 14.94 | 18.08 | |
| Intermediate housing | ||||
| 19 | 1609350007 | 23.90 | 28.92 | |
| Power supply cord | ||||
| 20 | 1609350011 | 88.83 | 107.48 | |
| Tapping Screw | ||||
| 21 | 1609350142 | 1.49 | 1.80 | |
| Strain-Relief Clamp | ||||
| 22 | 1609350025 | 2.08 | 2.52 | |
| Oval-Head Screw | ||||
| 23 | 2912311150 | 1.00 | 1.21 | |
| Cord guard | ||||
| 24 | 1609350166 | 9.67 | 11.70 | |
| Spring retaining ring | ||||
| 28 | 1609350016 | 2.86 | 3.46 | |
| Fan Wheel | ||||
| 29 | 1609350017 | 4.94 | 5.98 | |
| Motor | ||||
| 30 | 1609350296 | 244.89 | 296.32 | |
| Splash Guard | ||||
| 31 | 1609350093 | 4.18 | 5.06 | |
| Repair Kit | ||||
| 40 | 1609350297 | 88.83 | 107.48 | |
| Thrust Needle Bearing | ||||
| 41 | 1609350020 | 27.81 | 33.65 | |
| Cylinder Block | ||||
| 42 | 1609350021 | 98.18 | 118.80 | |
| Parts Set | ||||
| 42/30 | 1609350309 | 52.45 | 63.46 | |
| Compression Spring | ||||
| 43 | 1609350027 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 44 | 1609350098 | |||
| Plug | ||||
| 45 | 1609350308 | 7.46 | 9.03 | |
| Parts Set | ||||
| 45/10 | 1609350081 | 7.46 | 9.03 | |
| Filter screen | ||||
| 47 | 1609350032 | 11.37 | 13.76 | |
| Retaining ring | ||||
| 48 | 1609350033 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 49 | 1609350035 | |||
| No longer available, no replacement | ||||
| 50 | 1609350036 | |||
| No longer available, no replacement | ||||
| 51 | 1609350038 | |||
| No longer available, no replacement | ||||
| 52 | 1609350039 | |||
| Cylinder Head | ||||
| 53 | 1609350028 | 52.45 | 63.46 | |
| Parts Set | ||||
| 54 | 1609350029 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 55 | 1609350037 | |||
| Parts Set | ||||
| 56/50 | 1609350065 | 2.08 | 2.52 | |
| Hex Socket Head Cap Screw | ||||
| 59 | 2910141218 | 2.40 | 2.90 | |
| Valve Housing | ||||
| 60 | 1609350298 | 98.18 | 118.80 | |
| Flow Throttle | ||||
| 62 | 1609350304 | 7.46 | 9.03 | |
| Pressure Modulation Valve | ||||
| 63 | 1609350305 | 14.94 | 18.08 | |
| Parts Set | ||||
| 63/10 | 1609350177 | 2.08 | 2.52 | |
| No longer available, no replacement | ||||
| 64 | 1609350306 | |||
| Parts Set | ||||
| 64/10 | 1609350140 | 6.73 | 8.14 | |
| No longer available, no replacement | ||||
| 65 | 1609350307 | |||
| Parts Set | ||||
| 65/10 | 1609350175 | 2.08 | 2.52 | |
| Plug | ||||
| 66 | 1609350308 | 7.46 | 9.03 | |
| Parts Set | ||||
| 66/10 | 1609350081 | 7.46 | 9.03 | |
| Hex Socket Head Cap Screw | ||||
| 68 | 2910141207 | 2.40 | 2.90 | |
| Housing Base | ||||
| 70 | 1609350041 | 23.90 | 28.92 | |
| No longer available, no replacement | ||||
| 70/20 | 1609350068 | |||
| Casing Foot | ||||
| 71 | 1609350069 | 3.44 | 4.16 | |
| Oval-Head Screw | ||||
| 72 | 2912311201 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 73 | 1609350044 | |||
| Repair Kit | ||||
| 74 | 1609350045 | 21.30 | 25.77 | |
| Packing Sleeve | ||||
| 76 | 1609350066 | 5.81 | 7.03 | |
| Parts Set | ||||
| 76/10 | 1609350065 | 2.08 | 2.52 | |
| Inlet Connector | ||||
| 78 | 1609350067 | 21.30 | 25.77 | |
| Handle | ||||
| 650 | 1609350199 | 173.95 | 210.48 | |
| Connecting Tube | ||||
| 650/12 | 1609350089 | 88.83 | 107.48 | |
| Tapping Screw | ||||
| 650/15 | 1609350142 | 1.49 | 1.80 | |
| Plastic Hose | ||||
| 650/18 | 1609350504 | 110.30 | 133.46 | |
| Parts Set | ||||
| 650/18/12 | 1609350074 | 9.67 | 11.70 | |
| No longer available, no replacement | ||||
| 650/18/17 | 1609350078 | |||
| Repair Kit | ||||
| 650/19 | 1609350080 | 9.67 | 11.70 | |
| Parts Set | ||||
| 650/20 | 1609350176 | 18.94 | 22.92 | |
| No longer available, no replacement | ||||
| 650/40 | 1609350198 | |||
| High Press Clean Nozzle | ||||
| 651 | 1609350292 | 98.18 | 118.80 | |
| Nozzle retaining nut | ||||
| 651/10 | 1609350145 | 16.79 | 20.32 | |
| No longer available, no replacement | ||||
| 651/11 | 1609350078 | |||
| Parts Set | ||||
| 651/20 | 1609350182 | 9.67 | 11.70 | |
| Parts Set | ||||
| 651/30 | 1609350181 | 9.67 | 11.70 | |
| Foam Spray Device | ||||
| 652 | 1609350047 | 34.82 | 42.13 | |
| Single-Orifice Nozzle | ||||
| 652/10 | 1609350104 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 652/60 | 1609350078 | |||
| Parts Set | ||||
| 652/90 | 1609350115 | 21.30 | 25.77 | |
| Cleaning Pin | ||||
| 653 | 1609350124 | 9.67 | 11.70 | |
| No longer available, no replacement | ||||
| 678 | 0600800001 | |||
| Gasket | ||||
| 678/10 | 1609351029 | 1.00 | 1.21 | |
| No longer available, no replacement | ||||
| 700 | 2609200276 | |||
| No longer available, no replacement | ||||
| 700/10 | 1609350078 | |||
| No longer available, no replacement | ||||
| 701 | 2607000190 | |||
| No longer available, no replacement | ||||
| 701/10 | 1609350300 | |||
| No longer available, no replacement | ||||
| 701/11 | 1609350301 | |||
| Connecting Tube | ||||
| 701/12 | 1609350302 | 155.51 | 188.17 | |
| No longer available, no replacement | ||||
| 701/13 | 1609350078 | |||
| Parts Set | ||||
| 701/20 | 1609350084 | 9.67 | 11.70 | |
| Parts Set | ||||
| 701/30 | 1609350184 | 14.94 | 18.08 | |
| No longer available, no replacement | ||||
| 702 | 1609350053 | |||
| No longer available, no replacement | ||||
| 702/80 | 1609350078 | |||
| No longer available, no replacement | ||||
| 703 | 1609350156 | |||
| Gasket | ||||
| 703/20 | 1609351002 | 2.40 | 2.90 | |
| Adapter | ||||
| 703/30 | 1609350159 | 7.46 | 9.03 | |
| No longer available, no replacement | ||||
| 703/40 | 1609350078 | |||
| No longer available, no replacement | ||||
| 704 | 1609350126 | |||
| Gasket | ||||
| 704/20 | 1609351002 | 2.40 | 2.90 | |
| Connecting Piece | ||||
| 704/30 | 1609351014 | 18.94 | 22.92 | |
| Adapter | ||||
| 704/40 | 1609350159 | 7.46 | 9.03 | |
| No longer available, no replacement | ||||
| 704/50 | 1609350078 | |||
| No longer available, no replacement | ||||
| 705 | 1609350054 | |||
| No longer available, no replacement | ||||
| 705/1 | 1609350055 | |||
| Pipe Nozzle | ||||
| 705/10 | 1609350137 | 58.03 | 70.22 | |
| Parts Set | ||||
| 705/20 | 1609350088 | 1.49 | 1.80 | |
| No longer available, no replacement | ||||
| 705/60 | 1609350078 | |||
| No longer available, no replacement | ||||
| 706 | 1609350056 | |||
| No longer available, no replacement | ||||
| 706/60 | 1609350078 | |||
| No longer available, no replacement | ||||
| 707 | 1609350057 | |||
| Nozzle retaining nut | ||||
| 707/10 | 1609350136 | 2.86 | 3.46 | |
| No longer available, no replacement | ||||
| 707/60 | 1609350078 | |||
| No longer available, no replacement | ||||
| 708 | 1609350119 | |||
| Clamp Screw | ||||
| 708/10 | 1609350120 | 12.82 | 15.51 | |
| Clamping Piece | ||||
| 708/20 | 1609350121 | 9.67 | 11.70 | |
| Wheel | ||||
| 708/30 | 1609350122 | 13.13 | 15.89 | |
| Sealing cap | ||||
| 708/40 | 1609350123 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 709 | 2607000191 | |||
| Nozzle-Holder Assembly | ||||
| 709/10 | 1609350146 | 9.67 | 11.70 | |
| Suction Connection Piece | ||||
| 709/11 | 1609350135 | 43.12 | 52.18 | |
| Connecting Tube | ||||
| 709/12 | 1609350303 | 39.14 | 47.36 | |
| No longer available, no replacement | ||||
| 709/13 | 1609350078 | |||
| Oval-Head Screw | ||||
| 709/20 | 2912311130 | 13.13 | 15.89 | |
| Hex Nut | ||||
| 709/30 | 2915011005 | 1.00 | 1.21 | |
| Tapping Screw | ||||
| 709/40 | 2912401005 | 1.00 | 1.21 | |
| Nozzle | ||||
| 709/50 | 1609350134 | 21.30 | 25.77 | |
| Parts Set | ||||
| 709/60 | 1609350074 | 9.67 | 11.70 | |
| Equipment Trolley | ||||
| 710 | 2608005050 | 1.00 | 1.21 | |
| Hex Socket Head Cap Screw | ||||
| 710/40 | 2910141203 | 1.49 | 1.80 | |
| Wing Nut | ||||
| 710/50 | 2915191106 | 1.49 | 1.80 | |
| Wheel | ||||
| 710/60 | 1609351088 | 11.37 | 13.76 | |
| No longer available, no replacement | ||||
| 711 | 1609350128 | |||
| Parts Set | ||||
| 711/10/10 | 1609350065 | 2.08 | 2.52 | |
| Repair Kit | ||||
| 711/20 | 1609350169 | 14.94 | 18.08 | |
| Dosing Unit | ||||
| 711/30 | 1609350170 | 14.94 | 18.08 | |
| Hose | ||||
| 711/40 | 1609350171 | 11.37 | 13.76 | |
| Hose Clamp | ||||
| 711/50 | 1609350172 | 3.44 | 4.16 | |
| No longer available, no replacement | ||||
| 712 | 1609350060 | |||
| Gasket | ||||
| 712/10 | 1609351002 | 2.40 | 2.90 | |
| No longer available, no replacement | ||||
| 713 | 1609350153 | |||
| No longer available, no replacement | ||||
| 714 | 1609350155 | |||
| No longer available, no replacement | ||||
| 715 | 1609350161 | |||
| No longer available, no replacement | ||||
| 716 | 1609350162 | |||
| No longer available, no replacement | ||||
| 717 | 1609350164 | |||
| No longer available, no replacement | ||||
| 717/60 | 1609350078 | |||
