Here you will find all available parts and drawings of the 'Bosch 0611212662 ( 510 )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Bosch 0611212662 ( 510 )

Spare parts list of model Bosch 0611212662 ( 510 )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
Motor Housing BLUE
1 2605108014 20.42 24.71
Field 220-230V
2 2604220429 20.42 24.71
Fan BLACK
3/50 1616610072 1.70 2.06
Handle BLACK
17 1615133022 18.19 22.01
Air-Deflector Ring
18 1610522008 0.83 1.00
Intermediate Flange
20 1615700037 36.85 44.59
Ratchet Sleeve SDS-PLUS
21 1616490058 209.26 253.20
Cylindrical Gear Z=46
22 1616320007 5.83 7.05
No longer available, no replacement
23 1616320002
Toothed Shaft Z=6/10
24 1613060010 49.56 59.97
Hammer Piston
26 1618700052 10.73 12.98
Striker Pin
28 1613124026 2.24 2.71
Piston Pin
29 1613105012 2.71 3.28
Drive bearing
30 1615819005 26.84 32.48
Support Disc 0,8 MM THICK
31 1610100003 1.18 1.43
Clamp Handle BLACK
32 1612026023 1.94 2.35
Protective Cap L=17 MM, SDS-PLUS
34 1610508008 1.70 2.06
Rubber Ring
35 1610206021 1.18 1.43
Damping Bushing
37 1610390011 2.71 3.28
Supporting Disc
38 1610102022 1.70 2.06
Straight Pin
39 1613100013 1.70 2.06
Holding Spring
40 1614690001 0.83 1.00
Roller-Cage Assembly
41 1610920003 3.31 4.01
Compression Spring
44 1614633001 1.70 2.06
Compression Spring
45 1614614001 0.83 1.00
O-Ring 24,0x2,5 MM
54 1610210068 1.18 1.43
Seal Ring
55 1610206023 2.24 2.71
O-Ring 14,0x3,0 MM
56 1610210070 1.94 2.35
O-Ring 18,0x3,0 MM
58 1610210058 1.94 2.35
O-Ring 6,0x2,5 MM
59 1610210069 0.83 1.00
O-Ring 10,0x3,5 MM
60 1610210073 1.70 2.06
Rotary shaft lip seal
61 1610283017 5.83 7.05
Plain bearing
62 1610202026 4.10 4.96
No longer available, no replacement
65 1900900228
Bushing Ø30xØ37x15,7 MM
66 1610301000 1.94 2.35
No longer available, no replacement
67 1610910064
Ball DIN 5401-Ø7MM-III-ST
70 1903230013 1.70 2.06
Shim washer 1,2 MM THICK
71 1610101011 1.18 1.43
Retaining ring DIN 7993-A32
72 2916540018 2.71 3.28
Retaining ring DIN 9045-24
73 1614601009 0.83 1.00
Socket head cap screw DIN 84-AM4x25-5.8
74 2910011132 0.83 1.00
Tapping Screw ST-4,8x57,5-TORX,T20
76 1613435009 1.18 1.43
Tapping Screw ST3,9x19-TORX,T20
77 1603435050 1.18 1.43
Tapping Screw DIN 7971-ST3,9x16-F
78 2910211019 0.83 1.00
Tapping Screw DIN 7971-B 2,9x13
79 2910211206 0.83 1.00
Tapping Screw DIN 7971-ST2,9x9,5-F
79 2910211005 0.83 1.00
Cross Recessed-Head Screw DIN 7981-ST3,5x9,5-F
80 2603435015 1.70 2.06
Socket head cap screw M3x6,5-4.8
81 2603410001 1.18 1.43
Ball 5 MM V DIN 5401
83 1903230309 1.18 1.43
Spring Lock Washer DIN 128-A4-FST
84 2916690003 0.83 1.00
Retaining ring
87 160460102S 0.83 1.00
Connecting Cable L=145 MM GRAY
88 1614431018 1.70 2.06
Connecting Cable L=80 MM BLUE
89 1614431019 1.70 2.06
Change-Over Switch
90 2607200140 26.84 32.48
Detent Pin
94 1613120017 1.18 1.43
Auxiliary Handle
120 160202507H 8.45 10.22
Auxiliary Handle M8
120 1612025019 5.33 6.45
Support clamp Ø43 MM
121 1618040048 6.54 7.91
T-Head Bolt M8x40 MM
122 1613490002 3.31 4.01
Clamping Band Ø43 MM
123 1611316003 1.94 2.35
Clamping Band Ø43 MM
123 1611316006 1.94 2.35
Straight Pin
124 1613100012 1.94 2.35
No information available, not orderable
700 1617000132
Countersunk-Head Screw M6x27 LEFTHAND THREADS
700/20 2603421226 1.18 1.43
Chuck
701 1608571088 23.75 28.74
Chuck Wrench SG2
701/8 2607950007 5.33 6.45
No longer available, no replacement
711 1617000133
Retaining ring
711/10/2 2604601004 1.18 1.43
No longer available, no replacement
711/20 1608521004
No longer available, no replacement
711/30 2607000248
No longer available, no replacement
711/40 1608511020
Auxiliary Handle Ø43 MM
720 2602025070 11.88 14.37
Parts Set
720/8 1617000925 12.41 15.02
Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F
805 1607000227 20.42 24.71
Nameplate
808 160111A3H3 1.94 2.35
Carbon Brush
811 1617014114 7.58 9.17
Gear Housing BLACK
816 1615806077 40.61 49.14
Ratchet Sleeve
821 1617000931 271.34 328.32
Striker
827 1617000338 23.75 28.74
No longer available, no replacement
843 2601015047
groove ball bearing 9x24x7
863 1610905048 6.54 7.91
groove ball bearing 7x19x6
864 1610905025 5.33 6.45
