Here you will find all available parts and drawings of the 'Festool 494964 ( MFK700EQ230V-240V )'. From here you can order all desired parts directly. Many parts must be ordered from the manufacturer, depending on the brand, this takes one to four weeks. All the information we have is on our website, we cannot advise you on what you need, for that you will need to return the machine for repair. Please note the following when ordering:

Technical drawing of model Festool 494964 ( MFK700EQ230V-240V )

Spare parts list of model Festool 494964 ( MFK700EQ230V-240V )

Pos. Description Price excl. VAT Price incl. VAT
Prices shown include VAT
ARMATURE MFK 700 EQ 230V
1 495090 135.88 164.41
Field assembly DF 700 EQ 120V
2 10008029 63.28 76.57
FIELD COIL MFK 700 EQ 230V VOLLST.
2 495091 53.72 65.00
SWITCH PS 300 EQ
3 490200 14.04 16.99
plug it-kabel H05 RN-F-4
4 203914 25.62 31.00
Socket housing Ersatzteil
5 489927 8.38 10.14
Oval head screw PT-3,5x16-KT15
6 400584 1.39 1.68
Cap PS 300 EQ
7 451346 5.94 7.19
ELECTRONIC MFK 700 EQ ET-BG 230V
8 494933 99.10 119.91
BRUSH HOLDER PS 300 EQ ET-BG
9 490220 17.30 20.93
Motor frame PS 300 EQ
10 474364 11.22 13.58
Air guide washe PS 300 EQ
11 458964 1.39 1.68
Handle MFK 700 EQ
12 494886 7.73 9.35
Hexagon nut DIN 439-M6
13 200601 1.39 1.68
Clamping hood Ersatzteil
14 462575 6.00 7.26
Threaded bolt M6x40,5
15 728985 12.34 14.93
Oval head screw PT-3,0x12-KT10
16 219069 1.39 1.68
Solenoid ring RO 2 E
17 444018 2.11 2.55
Ball bearing 626 DD M5MTLY 121
18 228672 4.49 5.43
LEVER PS 300 EQ
19 453490 1.39 1.68
Fan OF 900 E
20 440171 2.11 2.55
Switch linkage PS 300 EQ
21 465089 1.39 1.68
Slide switch PS 300 E
22 451347 1.39 1.68
Circlip DIN 471-17x1
23 401191 1.39 1.68
Air plate Ersatzteil
24 462347 1.39 1.68
Casing OFK 700 EQ
25 495094 79.74 96.49
Dust cover Ersatzteil
26 462656 1.39 1.68
Oval head screw PT-3,5x50-KT15
27 400005 1.39 1.68
Compr. spring DIN 2098-0,70x7,50x14,7
28 444754 1.39 1.68
Bolt KF 4 E
29 436305 9.17 11.10
CAP OF 1000 EB
30 450206 1.39 1.68
Screw OFK 700 E
31 10019108 9.96 12.05
Disc DIN 125-A-8,4-140 HV
32 761517 1.39 1.68
Spring washer DIN 137-A-8
33 761524 1.39 1.68
Plate OFK 700 EQ
34 517018 24.32 29.43
Ch. head screw DIN 7984-M5x10
35 207729 1.39 1.68
Disc DIN 125-A-5,3-140 HV
36 761515 1.39 1.68
Spring washer DIN 137-A-5
37 200587 1.39 1.68
Clamping screw OFK 700 E
38 462895 5.88 7.11
Mounting plate MFK 700 EQ ET-BG
39 495757 67.88 82.13
Round guide KF 4 E
40 451754 6.60 7.99
TASTVOET OFK 700 EQ KPL. ET-BG
41 491845 33.76 40.85
Ball bearing 6003 DDW CM DIN 625 NSK
42 462795 9.64 11.66
Dowel pin DIN 1481-2x12-ST
43 200747 1.39 1.68
Cover OFK 700 EQ
44 473550 6.79 8.22
Countersink M4x10-TAPTITE-T15
45 228581 1.39 1.68
Collet
46 488755 56.51 68.38
Clamping screw OFK 700 EQ
47 462891 5.81 7.03
Compression spr 1,0Cx6,3x10
48 462230 1.39 1.68
Cover plate OFK 700 EQ
49 462229 6.53 7.90
Carrier OFK 700 EQ
50 491850 100.55 121.67
Carrier OFK 700 EQ
50 491846 85.43 103.37
Thrust piece OFK 700 EQ
51 528994 3.10 3.75
No information available, not orderable
52 491683
Rotary knob OF2000 EB D 23 M6x16 bl
53 444633 2.04 2.47
Hexagon nut DIN 934-M6-10
54 228689 1.39 1.68
TABLE MFK 700 EQ ET-BG
55 495369 75.99 91.95
Binding post MFK 700 EQ
56 471748 13.07 15.81
Spindle MFK 700 EQ
57 471749 21.05 25.47
Adjusting wheel OF 1010 EB
58 457351 3.30 3.99
Oval head screw M4x10-TAPTITE-T15
59 228582 1.39 1.68
SUPPORT PLATE MFK 700 EQ
60 471750 4.88 5.90
PIVOT FRAME OFK 700 EQ
61 491848 130.08 157.40
PIVOT FRAME OFK 700 EQ
61 491849 113.86 137.77
Table,complete 1.5 degree
62 529095 151.49 183.30
FREESTAFEL FT-OFK/MFK/0
62 491427 122.03 147.66
Slideway lining OFK 700 EQ
63 462228 26.26 31.77
Brush PS 300 EQ ET-BG
64 490219 17.30 20.93
Cover OFK 700 EQ
65 494788 13.67 16.54
Angle piece MFK 700 EQ
66 471659 38.84 47.00
EXTRACTION HOOD VS 500 GE
67 467328 11.92 14.42
Ch. head screw DIN 84-M4x10-4.8
68 200525 1.92 2.32
Angular slide EFH 36-E9
69 841467 2.83 3.42
RUBBER DUST COV MFK 700 EQ
70 471751 9.96 12.05
O-ring 5x1,5-NBR-70SHORE
71 200052 1.39 1.68
Rotary knob SF-OF D 23 M6x23 blau
72 486243 2.18 2.64
PTC resistor MFK 700 EQ
73 474618 9.43 11.41
Scanning shoe MFK 700 EQ ET-BG
74 495368 63.16 76.42
Crosshd. guide MFK 700 EQ
75 471743 29.64 35.86
Countersink M4x8-TAPTITE-KT15
76 228737 1.39 1.68
Fine adjustment MFK 700 EQ ET-BG
77 495371 59.17 71.60
Base MFK 700 EQ
78 495673 184.65 223.43
Stop angle MFK 700 EQ
79 495704 67.88 82.13
Rotary knob MFK 700 EQ D 23 M6x20 bl
80 471744 7.99 9.67
Rotary knob OF2000 EB D 23 M6x16 bl
81 444633 2.04 2.47
SPANNER 19ml SW 19 DIN894
82 772049 8.78 10.62
